- Page 1 KS-05 OFFICE AND HOME AUDIO SYSTEM N Instruction manual...
- Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.
-
Page 3: Exemption Of Liability
The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use. -
Page 4: Installation And Connection
DESCRIPTION Easy to install audio system for small P.A. or household installations. INSTALLATION AND CONNECTION ACCESSORIES INCLUDED 1.- Make two 135 mm Ø holes in the drop ceiling or plaster tiles to install the loudspeakers. It is recommended that the loudspeakers are placed with a distance of 2.5 or 3 metres between them. 2.- Pass the loudspeaker cables from where the amplifier has been installed to the loudspeaker holes. - Page 5 4.- Connect the other end of the cables to the loudspeaker output on the amplifier. Each loudspeaker is connected to a different channel (L left, R right), respecting polarity. Connect the power cables to the power supply terminals on the amplifier. Before connecting them, make sure that the mains has been disconnected to avoid electric shocks.
- Page 6 AMPLIFIER CONTROLS AND FUNCTIONS ON/OFF: amplifier on/off switch. LCD information display. EQ: equalization button. For choosing between the different equalizations available: normal, rock, pop, classic and jazz. 7/VOL-: in USB or bluetooth mode, a short quick press of this button selects the previous song to the one being listened to at that moment.
-
Page 7: Remote Control
10.- Select the playback mode from between REPEAT ALL and REPEAT ONE (repeat one song). 11.- Number buttons for choosing the desired track. SPECIFICATIONS KS-05 CHARACTERISTICS Wall amplifier and ceiling speakers. COMPONENTS Compact Hi-Fi stereo amplifier, 2 x 5 W maximum with flush mount box 2.0 bluetooth receiver... -
Page 8: Declaration Of Conformity
This product has been tested and has passed the corresponding quality control prior to being put on the market. FONESTAR guarantees the suitability of the product for its specified use during a period of 2 years from the delivery date and commits itself to repair or substitute the goods as expressed in the Spanish law ‘La Ley General para la Defensa de los...
