Room actuator N 568/81, 24-fold
5WG1568-1AB81
A6V14731160_en--_a
2024-03-06
Main characteristics
●
Room actuator with 24 outputs to switch and control solar protection (AC/DC),
on/off valve, and ventilation functions
●
Standard 35 mm DIN rail mounting, DIN EN 60 715
●
Direct operation for efficient installation with output status indication
●
Powered via KNX bus
ETS configuration functions
●
Switch electrical loads such as lighting, sockets etc.
●
Control max. 12 AC 230 V or 2 DC blinds, shutters or awnings
●
Control 3-speed fan
●
Control valve drives for heating or cooling via 3-point operation, PWM or 2-point
operation
Smart Infrastructure
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Siemens 5WG1568-1AB81
Summary of Contents for Siemens 5WG1568-1AB81
- Page 1 Room actuator N 568/81, 24-fold 5WG1568-1AB81 Main characteristics ● Room actuator with 24 outputs to switch and control solar protection (AC/DC), on/off valve, and ventilation functions ● Standard 35 mm DIN rail mounting, DIN EN 60 715 ● Direct operation for efficient installation with output status indication ●...
- Page 2 Relay contact position selection after bus voltage recovery ● Relay contact position selection after bus voltage failure ● Relay contact position after download ● Direct operation of switching outputs ● Control of thermal actuators (without controller) Siemens A6V14731160_en--_a Smart Infrastructure 2024-03-06...
- Page 3 Normal operation: Manual fan control, e.g., via panel, etc. ● Max. two control values can be evaluated and monitored ● Parameterizable startup and switch-off behavior ● State feedback, e.g., automatic operating state, fan level status, fan speeds, etc. Siemens A6V14731160_en--_a Smart Infrastructure 2024-03-06...
- Page 4 Manual or automatic valve flushing with status signal Type summary Product no. Stock no. Description Operating voltage N 568/81 5WG1568-1AB81 Room actuator, 24-fold DC 21... 30 V, powered over KNX bus Ordering When ordering, specify product number/stock number and name: e.g. N 568/81 (5WG1568-1AB81) Room Actuator, 24-fold.
- Page 5 Environmental product declaration A5W00269576A Related documents such as the environmental declarations, declarations of conformity, etc., can be downloaded from the following Internet address: www.siemens.com/bt/download Technical documentation and ETS application can be downloaded at http://www.siemens.com/gamma-td (S-Mode). To search for the technical documentation, you can enter the product type in http://www.siemens.com/gamma-td.
- Page 6 Flashing green LED indicates that the device application layer operates normal A red LED indicates active programming mode ④ Programming button Switch to programming mode ⑤ Direct operation button Switch output ⑥ Output LED Indicates output status Siemens A6V14731160_en--_a Smart Infrastructure 2024-03-06...
- Page 7 Delete all personal data and dispose of the item(s) at separate collection and recycling facilities in accordance with local and national legislation. For additional details, refer to Siemens information on disposal. If a device is defective, contact the local sales office. Technical data...
- Page 8 General data Dimensions in mm （w × h × d） 216 × 90 × 64 Weight without/with package 711 / 854 g Materials and colors Housing: Plastic, light grey The documents can be downloaded from https://siemens.com/bt/download. Siemens A6V14731160_en--_a Smart Infrastructure 2024-03-06...
- Page 9 Diagrams Connection terminals Siemens A6V14731160_en--_a Smart Infrastructure 2024-03-06...
- Page 10 On for direct operation, and Off for bus operation. ⑥ ⑦ Programming button and LED indicator: This button switches over to programming mode. The status LED is red. ⑧ KNX bus connection terminals Siemens A6V14731160_en--_a Smart Infrastructure 2024-03-06...
- Page 11 – If channels 21/22/23/24 are used for DC curtains, channels 15/16/17/18/19/20 cannot be connected to high voltage. ● In the ETS product database configuration, each output offers a range of functions. Wiring of loads must be consistent with ETS database configuration. Siemens A6V14731160_en--_a Smart Infrastructure 2024-03-06...
- Page 12 Regulatory compliance information European Union conformity Contact for regulatory topics: (EU) Siemens AG, Berliner Ring 23, DE-76437 Rastatt United Kingdom conformity assessed Contact for regulatory topics: (GB) Siemens plc, Sir William Siemens House, Princess Road, Manchester, M20 2UR Support ●...
