VoIP Paging Gateway
The CyberData VoIP Paging Gateway
enables access to existing paging
speakers through a VoIP phone system.
The interface is designed to use an
existing analog zone controller with a
TAM interface and supports paging up to
99 zones from a VoIP phone.
The gateway has an FXO port that
connects to the FXS port on the zone
controller.
Features
SIP RFC 3261 compatible
Dual speed 10/100 Mbps
Configurable DTMF tones to Zone
Controller
Web-based configuration
Web-based firmware upgradeable
Power-over-Ethernet (PoE 802.3af)
enabled
Connector for optional external power
supply (not included)
Small footprint
IGMP
CyberData Corporation
VoIP Paging Gateway Specifications
Protocol
Ethernet I/F
Power Input
Payload Types
Regulatory Compliance
Dimensions
Warranty
Part Number
CyberData Corporation
2555 Garden Road
(831) 373-2601
(831) 373-4193
www.cyberdata.net
CyberData Corporation
SIP RFC 3261 Compatible
10/100 Mbps
PoE 802.3af or 48VDC
G711
FCC Class B, UL 60950, CE
6.11"L x 4.05"W x 1.15"H
2 years limited
010846
Monterey, California 93940
930149C/070802
Advertisement
Related Manuals for CyberData VoIP Paging Gateway
Summary of Contents for CyberData VoIP Paging Gateway
- Page 1 VoIP Paging Gateway The CyberData VoIP Paging Gateway enables access to existing paging speakers through a VoIP phone system. The interface is designed to use an existing analog zone controller with a TAM interface and supports paging up to 99 zones from a VoIP phone.
- Page 2 VoIP Paging Gateway Typical Installation – FXO VoIP Paging Gateway Generic PoE Hub IP Phone Paging Speakers FXO Port FXS Port IP-PBX Server Existing Zone Controller Typical Installation – Single Zone VoIP Paging Gateway Generic PoE Hub Paging Speakers IP Phone...
