Performance Tool W1609 Owner's Manual

Performance Tool W1609 Owner's Manual

2 ton 12 volt electric scissor jack

Advertisement

Quick Links

2 TON 12 VOLT ELECTRIC
SCISSOR JACK
Item Number W1609
OWNER'S MANUAL
WARNING
It is the owner and/or operators' responsibility to study all WARNINGS, operating, and maintenance
instructions contained on the product label and instruction manual prior to operation of this product.
The owner/operator shall retain product instructions for future reference.
The owner and/or operator are responsible for maintenance, maintaining all decals or warning
labels and while in use, maintaining the unit in good working order. If the owner and/or operator are
not fluent in English, the product warnings and instructions shall be read and discussed with the
operators' native language by the purchaser/owner or his designee. Make sure that the operator
comprehends its contents. Safety information shall be emphasized and understood prior to usage.
The product shall be inspected per the operating instructions.
Users of this product must fully understand these instructions. Each person operating this product
must also be of sound mind and body and must not be under the influence of any substance that
might impair their vision, dexterity or judgment.
Protect yourself and others by observing all safety information.
Failure to comply with instructions could result in personal injury and/or property damage!
If you encounter any problems or difficulties, please contact our customer service department at:
1-800-426-1262 between 6:30 a.m. and 4:30 p.m. Pacific time.

Advertisement

loading
Need help?

Need help?

Do you have a question about the W1609 and is the answer not in the manual?

Questions and answers

Summary of Contents for Performance Tool W1609

  • Page 1 2 TON 12 VOLT ELECTRIC SCISSOR JACK Item Number W1609 OWNER’S MANUAL WARNING It is the owner and/or operators’ responsibility to study all WARNINGS, operating, and maintenance instructions contained on the product label and instruction manual prior to operation of this product.
  • Page 2: Specifications

    SPECIFICATIONS Capacity: ...............4000 lb. extended 14 in. or more ..................2400 lb. extended 10 in. or more ...................1600 lb. extended 8 in. or more ...................1200 lb. extended 6 in. or more Minimum Lift Height: .................. 4.33 in. (11cm) Maximum Lift Height: ................13.38 in. (34cm) Base Length X Base Width: ..................
  • Page 3: Important Safety Information

    Ensure that no personnel pass under- These carry important information. If unread- neath load until load is securely supported by able or missing, contact Performance Tool for jack stands. Be sure all personnel are clear of a replacement. load before lowering load.
  • Page 4: Care And Maintenance

    CARE & MAINTENANCE Monthly maintenance is recommended. Lubrication is critical to jacks as they support heavy loads. Any restriction due to dirt, rust, etc. can cause either slow movement or cause extremely rapid jerks, damaging the internal components. The following steps are designed to keep the jack maintained and operational.
  • Page 5 JACK PLACEMENT For proper jack placement: 1. Place the jack near the tires at the designated points ONLY. DO NOT place the jack in the center of of the vehicle. PLACE HERE PLACE HERE PLACE HERE PLACE HERE 2. Place the jack so that it is facing toward the vehicle.
  • Page 6 NOTES...
  • Page 7: Limited Warranty

    After 90 days and up to one year from date of purchase, PERFORMANCE TOOL® will replace at no charge any parts which our examination shall disclose to be defective and under warranty.
