General Pump DHRHC50150SS Manual

GENERAL PUMP
FEATURES / BENEFITS
• Direct hand-crank rewind with locking pin
• Stainless steel construction
• 150' Capacity for 3/8" hose
PARTS LIST
No. Part No.
1 2103152
2 2203017
3 2203413
4 2200166
5 DHR50150SS Hose Reel, 1/2"x150', SS
1 2100580
5 DHR50150SS Hose Reel, 1/2"x150', SS
2660216
General Pump
is a member of
the Interpump Group
A member of the Interpump Group
SPECIFICATIONS
DHRHC50150SS PART LIST
Description
Frame Kit, Hand Carry, SS
Nut, M10, Nylok, SST
Washer, Flat, M10
Bolt, M10X25, SS
Replacement Parts / Kits
Collapsible Frame Kit, SS
Handle Grip, Ø 32 mm
DHRHC50150SS
PART NUMBER
3/8" Hose Capacity
Pressure Rating
Inlet
Outlet
Max. Temp
Weight
• 5,000 PSI
• Stainless steel swivel
Qty.
1
4
8
4
1
1
1
1
No. Part No.
1 2103169
2 2203415
3 2530025
4 2720043
5 2203438
6 DSW9012SS Swivel, 1/2" NPT-F Ball Bearing
7 2520227
8 2520247
9 2660335
10 2103165
11 2702106
12 2103167
13 2103237
6 DSW9012SS Swivel, 1/2" NPT-F Ball Bearing
2103170
Industrial Hose Reel
DHRHC50150SS
150 ft.
5,000 PSI
1/2" NPT-M
1/2" NPT-F
250° F
23.35 lbs
DHR50150SS PARTS LIST
Description
Arm Assy, 150' SS
Washer
Bushing
Spring, ID 44, SS
Washer, Swivel, SS
Adapter, 1/2"NPT-M X 3/8"NPT-F, SS
Adapter, 1/2" NPT-F X 3/8"NPT-F
Cap, G1/2"
Flange Plate Assy, SS
Hose Guard, 150'
Handle Kit, Folding, Brass
Assy, Clamp, Hose
Replacement Parts / Kits
Pin Lock Kit, SS
Ref 301128 Rev C
04-23
Qty.
1
2
2
1
1
1
1
1
1
1
1
1
1
1
