- Page 1 Remote Controller Operation Manual .. Move and scrap the air conditioning ..24 Accessories.......... 25 AB140S5SR1FA No.0150570827 Keep this operation manual for future reference.
- Page 2 Service indicator; Read technical Read the operator's manual manual The installation and service of this product shall be carried out by professional personnel, who have been trainedand certified by national training organizations that areaccredited to teach the relevant national competency standards that may be set in legislation. Mechanical connectors used indoors shall comply with ISO 14903.
- Page 3 •A brazed, welded, or mechanical connection shall be made before opening the valves to permit refrigerant to flow between the refrigerating system parts. A vacuum valve shall be provided to evacuate the interconnecting pipe and/or any uncharged refrigerating system part. •The maximum working pressure is 4.3 MPa.
-
Page 4: Disposal Requirements
DISPOSAL REQUIREMENTS: IMPORTANT INFORMATION REGA- Your air conditioning product is marked with this symbol.This RDING THE REFRIGERANT USED means that electrical and electronic products shall not be mixed with unsorted household waste.Do not try to dismantle the system yourself: the dismantling of the air conditioning system,treatment of the refrigerant,of Contains fluorinated greenhouse gases oil and of other part must be done by a qualified... -
Page 8: Functional Description
Remote Controller Operation Manual External View of Remote Controller Functional description Remote Controller function description 1.ON/OFF Button: This remote Controller is a general remote Turning on the units:Press the button to turning on the Controller, and some functions are valid according to the adaptable model. - Page 9 Remote Controller Operation Manual 16.CLOCK Up-and-down SWING Angle Each time you press the button , Remote control display Press the button, the time displayed on the remote controller cycle sequence: HEAT MODE: flashes. Then Press the button once, the time increases or decreases by one minute.
- Page 12 For AB140S5SR1FA LED flash times Contents of I.R.Receiver Possible reasons of indoor PCB digital display Malfunction LED6 LED1 Malfunction of indoor Sensor disconected or broken,or unit ambient temper- at wrong position,or short circuit ature sensor Malfunction of indoor Sensor disconected...
- Page 13 When there is too much dust Use ventilation fan or directly spray the detergent special for kitchen ware on the air inlet grille,10 minutes later use water to clean (5).Install air inlet grille Referring to procedure 3. (6).Install the air filter Referring to "Clean the air filter"...
- Page 16 8/3.. 8/3.. 8/3.. 8/3.. AB140S5SR1FA...
- Page 17 840(indoor unit) AB140S5SR1FA...
- Page 20 Connect and fix the power supply cable,indoor-outdoor connection cable as following:...
- Page 21 REFRIGERANT PIPING(As for outdoor piping, please refer to installation Manual of outdoor unit.) Pipe size Mod e Liquid side Gas side AB140S5SR1FA Ø Ø 9.52mm 19.05mm...
- Page 22 (minimum) Model rated capacity (A) breaker(A) current(mA) AB140S5SR1FA POWER SUPPLY & INDOOR-OUTDOOR CONNECTION: Make wiring to supply power to the outdoor unit, so that the power for the indoor unit is supplied by outdoor unit terminal blocks. 1 2 3...
- Page 23 For solid core wiring (or F-cable) For strand wiring...
- Page 24 Panel installation (M6*20) ;<=>...
- Page 25 < <...
- Page 26 JNMLP OUMQT KMTU SVR...
- Page 27 3/4 Brass nut(gas side) Screw Spare parts Felt Spare parts...
-
Page 28: Customer Care
To view full terms and conditions, visit www.haier.com.au/warranty or www.haier.co.nz/warranty. The warrantor is: Fisher & Paykel Australia Pty Ltd, Level 1, 1 Eden Park Drive, Macquarie Park, NSW 2113. Phone Customer Care: 1300 729 948 Email: customer.care@haier. com.au...
