KWIK GOAL 2J102 Assembly Instructions page 3

6. Mark field location for posts.
+
Post
Post
30
Approx.
41 1/4"
10"
Minimum
This goal has been designed to be used for the game of rugby only. Goal posts must be anchored
AT ALL TIMES and shall be secured against overturning. Do not climb on the goal framework at
anytime! All fastenings must be checked to insure they are fully tightened before and after each
use of this product. Goal posts not in use must be disassembled and properly stored in a safe,
secure area. Assembled goal posts should not be left unattended. Do not use this equipment
during the threat of high winds. Goal posts should be checked for safety before and after each
use. All warning and safety labels included with this product must be visible at all times. Any
modifications to this or any Kwik Goal product will void any and all warranties.
111-3/4"
(2.83 m)
Face of goal NOT beyond this point
5" Below Surface
Ground Sleeve
24" Minimum
Center of Goal Line
223-1/2"
(5.66 m)
Playing Field
Concrete 7. Dig holes a minimum of 51 1/4" deep and 24"
across. Fill bottom of holes with 1" diameter stone
until the hole is 41 1/4" in depth and top of ground
sleeve is 5" below field surface. NOTE: The stone
base allows water and small debris to flow
through the hole located in the bottom of
ground sleeve.
1" diameter
stone for
drainage
***CAUTION***
+
Post
NZ343 Rev. 07/17/17
