  • Page 1 5 2 0 3 B E x S o l e n o i d / A l a r m D r i v e r N o . 5 2 0 3 B V 1 0 5 - U K F r o m s e r .
  • Page 2 PR electronics A/S tilbyder et bredt program af analoge og digitale signalbehandlingsmoduler til industriel automation. Programmet består af Isolatorer, Displays, Ex-barrierer, Temperaturtransmittere, Universaltransmittere mfl. Vi har modulerne, du kan stole på i selv barske miljøer med elektrisk støj, vibrationer og temperaturudsving, og alle produkter opfylder de strengeste internationale standarder.

  • Page 3: Table Of Contents

    Ex SOLENOID / ALARM DRIVER PRepower 5203B Table of contents Warning ....................... Symbol identification ................Safety instructions ................. How to demount system 5000 ............Application ....................Technical characteristics ..............Mounting / installation ................. Application ....................Electrical specifications................ DIP-switch programming ..............10 Connections ....................

  • Page 4: Warning

    General mounting, connection and disconnection of wires. Troubleshooting the device. Repair of the device and replacement of circuit breakers must be done by PR electronics A/S only. WARNINg To keep the safety distances, the relay contacts on the device must not be connected to both hazardous and non-hazard ous volt ages at the same time.

  • Page 5: Symbol Identification

    SyMBOL IDENTIFIcATION Triangle with an exclamation mark: Warning / demand. Potentially lethal situations. The cE mark proves the compliance of the device with the essential requirements of the directives. The double insulation symbol shows that the device is protected by double or reinforced insulation.
  • Page 6 LIABILITy To the extent the instructions in this manual are not strictly observed, the custom er cannot advance a demand against PR electronics A/S that would otherwise exist according to the concluded sales agreement. 5203BV1 0 5- UK...

  • Page 7: How To Demount System 5000

    HOW TO DEMOUNT SySTEM 5000 First, remember to demount the connectors with hazardous voltages. Picture 1: By lifting the bottom lock, the device is detached from the DIN rail. Picture 2: Then, by lifting the upper lock and pulling the front plate simultaneously the PCB is removed.

  • Page 8: Application

    Ex SOLENOID / ALARM DRIVER PRepower 5203B • 1- or 2-channel version • 3- / 5-port 3.75 kVAC galvanic isolation • Solenoid driver for Ex area • Digitally controlled voltage supply for Ex area • Universal supply by AC or DC Application • Driver with safety barrier for the control of ON / OFF solenoids mounted in...

  • Page 9: Application

    APPLIcATION Valve Digital input Supply Digital input Supply Acoustic alarm Digital input Supply 5 20 3 B V1 0 5 -UK...

  • Page 10: Electrical Specifications

    Order: 5203B Type Input Ex barrier Channels [EEx ia] type : F Single 5203B Switch [EEx ia] type : H Single [EEx ia] type : I Double Electrical specifications Specifications range ..........-20°C to +60°C common specifications: Supply voltage universal ........21.6...253 VAC 50...60 Hz...
  • Page 11 Inputs: NPN and mechanical switch: Trig level LOW ............≤ 4.0 VDC Trig level HIGH ............≥ 7.0 VDC Max. external voltage ..........28 VDC Input impedance ............3.48 kΩ PNP: Trig level LOW ............≤ 4.0 V Trig level HIGH ............≥ 7.0 V Max.

  • Page 12: Dip-Switch Programming

    gOST R approval: VNIIM & VNIIFTRI, Cert. no........See www.prelectronics.com Observed authority requirements: Standard: EMC 2004/108/EC ..........EN 61326-1 LVD 2006/95/EC ............EN 61010-1 PELV/SELV ..............IEC 364-4-41 and EN 60742 ATEX 94/9/EC ............EN 50014, EN 50020 and EN 50281-1-1 UL ...................

  • Page 13: Connections

    cONNEcTIONS Supply: Digital inputs: Switch Switch Ex outputs: ON / OFF valve Acoustic alarm ON / OFF valve Acoustic alarm 5 20 3 B V1 0 5 -UK...

  • Page 14: Block Diagram

    BLOcK DIAgRAM 5203BV1 0 5- UK...
  • Page 15 APPENDIX control Drawing No. 5203QU01 5 20 3 B V1 0 5 -UK...

  • Page 16: Control Drawing 5203Qu01

                                      ≥     ≥ ...
  • Page 17 Displays Programmable displays with a wide selection of inputs and outputs for display of temperature, volume and weight, etc. Feature linearization, scaling, and difference measurement functions for programming via PReset software. Ex interfaces Interfaces for analog and digital signals as well as HART signals between sensors / I/P converters / frequency ®...
  • Page 18  www.prelectronics.se  sales-se@prelectronics.com  www.prelectronics.co.uk  sales-uk@prelectronics.com  www.prelectronics.com  sales-us@prelectronics.com  www.prelectronics.cn  sales-cn@prelectronics.com Head office Denmark www.prelectronics.com PR electronics A/S sales-dk@prelectronics.com Lerbakken 10 tel. +45 86 37 26 77 DK-8410 Rønde fax +45 86 37 30 85...
