HARLEY DAVIDSON SPORTSTER 883
M
O
U
REF 21053
1 Person
20 min
EASY
ID
PIEZA/PART
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
V1.07/21
N
T
I
N
G
SEMIFAIRING BATWING SML SPORT MODEL
DESCRIPCIÓN
Semicarenado
Cúpula Sport
Soporte izquierdo superior
Soporte derecho superior
Soporte izquierdo inferior
Soporte derecho inferior
Tornillo Allen ANSIB 18.3 CLASE 12.9 UNC 3/8"x51
Casquillo Ø10,5x Ø16x 15
Silentblock M5
Arandela nylon M5x1
Tornillo Allen M5x16 Ø11 ISO 7380
Tapón tornillo M5 ISO 7380
Tornillo Allen M4x12 ISO7380
Arandela nylon M4x0,5
Tuerca autoblocante M4
Tapón tuerca M4
Brida cable
Casquillo Ø13x Ø8,5x 3,5mm
I
N
S
T
R
U
DESCRIPTION
Semifairing
Sport screen
Upper left support
Upper right support
Lower left support
Lower right support
ANSIB 18.3 CLASE 12.9 UNC 3/8"x51 Allen screw
Ø10,5 xØ16 x15 spacer
M5 silentblock
M5x1 nylon washer
M5x16 Ø11 ISO 7380 Allen screw
M5 ISO 7380 screw cap
M4x12 ISO 7380 Allen screw
M4x0,5 nylon washer
M4 nut
M4 cap nut
Cable ties
Ø13xØ8,5 x3,5mm spacer
Pg. 1/4
C
T
I
O
N
S
TORX T45
QTY
1
1
1
SOP4P9SLBTM0001
1
SOP4P9SRBTM0001
1
SOP4P9ILBTM0001
1
SOP4P9IRBTM0001
2
TORNI-ANSIB-846
2
CASQUI------845
4
SILENBTM5-046/1
4
4
TORNI-I7380-493
4
TAPON--------85
3
6
ARNV00000000311
3
3
1
ABR-00101100539
2
CASQUI------775
Illustrations and layout by: www.ciandisseny.com
Nº 7
Nº 14
ALLEN
Nº22,5
Nº 2,3
REF
10897N
10899
