Button sewer indexer
（MB6006A）
使用说明书
Instruction Manual
常州智谷机电科技有限公司
IMB AUTOMATION CO.,LTD
在使用本设备之前请先阅读本使用说明书.
Please read the operation manual of the touch
screen interface before using the device
请将本使用说明书放在便于查阅的地方保管
版本信息/ Version
Please keep this operation manual of touch screen
2020.07
interface in convenient place for reference
Advertisement
Table of Contents
Related Manuals for IMB MB6006A
Summary of Contents for IMB MB6006A
- Page 1 Button sewer indexer （MB6006A） 使用说明书 Instruction Manual 常州智谷机电科技有限公司 IMB AUTOMATION CO.,LTD 在使用本设备之前请先阅读本使用说明书. Please read the operation manual of the touch screen interface before using the device 请将本使用说明书放在便于查阅的地方保管 版本信息/ Version Please keep this operation manual of touch screen 2020.07 interface in convenient place for reference...
-
Page 2: Table Of Contents
Catalog [1] Main interface description ................错误！未定义书签。 [2] Style settings modification ................错误！未定义书签。 [3] User parameters ..........................6 A、 button feeding mode setting ....................8 B、 stacking setting ........................8 C、 vibrator setting ........................9 D、 thread breakage setting ..................... 9 E、 PANEL AND DISPLAY ......................10 F、... -
Page 3: Main Interface Description
[1] Main interface description The title bar at the top of the interface will display the current interface name (the name of the current button will be displayed when clicking the button), the USB flash drive prompt area (if a USB flash drive is inserted, the USB flash drive logo will be displayed in the title bar), the date, and the current version number in sequence function Description... - Page 4 Suction mode Switch the current suction mode between continuous and intermittent modes. You need to turn on the suction switch to operate this button Fabric detection Switching the functional status of the fabric detection module switch Thread breakage Click to switch the status of the disconnection detection function detection Secondary thread...
- Page 5 1. The left list is a style list. By selecting a style from this list, the right interface will switch to display data based on the selected style； 2. The right area shows the details of style settings Function Description Pattern No Display the currently selected pattern Pattern name...
-
Page 6: User Parameters
Modify Select the position of the nail buckle spacing spacing that needs to be modified, individual button and enter the modified interval value through the keypad 。After modifying the corresponding settings in the interface according to the requirements, you need to choose to press the OK button in the bottom right corner to save the settings, otherwise press the Exit button in the bottom left corner to cancel the modification. - Page 7 button feeder arm move down timing button feeder damp open timing button feeder damp receive button delay time button feeder damp receive button overtime thread losing timing right two stage presser foot work timing...
-
Page 8: A、Button Feeding Mode Setting
SECOND LEVEL PARAMETER PANEL AND DISPLAY OTHER PARAMETERS feeding setting Buzzer Sound Setting Change language feeding speed PANEL LUMINANCE SETTING Power On Password feeding motor startup speed PANEL LUMINANCE AUTO feeding motor accelerate EMBED COMMUNICATION CLOSE SWITCH speed WAITING TIME BEFORE PANEL feeding motor ratio LUMINANCE CLOSE sewing placket maximum... -
Page 9: C、Vibrator Setting
C、vibrator setting D、thread breakage setting... -
Page 10: E、Panel And Display
E、PANEL AND DISPLAY F、OTHER PARAMETERS... -
Page 11: G、Feeding Setting
G、feeding setting H、Modified Select the modified settings at the bottom to view the user parameters that have been modified in the current system. You can modify the parameters again by directly clicking the corresponding parameter button, or by checking the box on the right side of the button to reset the parameters and restore them to factory parameters。... -
Page 12: A、Time Date
[4] System functions Select Settings "to enter the system settings interface, where you can adjust the upper computer control board。 A、Time Date Select and click on the time and date in the system function, and enter the correct password to enter the time modification interface. In this interface, you can configure the date and clock of the upper compute。... - Page 13 B、Software upgrade Select and click on the software upgrade option in the system function, and enter the correct password verification to enter the software upgrade interface. The upgrade file selected for this option needs to be selected from the USB flash drive, and the USB flash drive and upgrade file need to be prepared in advance Function Description...
- Page 14 screen program is BCPanel.bin Main control board program Select the LCD screen program upgrade file in the USB flash drive with this option. After selecting the file, click OK. When prompted to restart, restart the LCD screen to complete the upgrade.
-
Page 15: D、Parameter Backup And Recovery
C、Second level password modification and third level password repair After clicking, verify the corresponding level password to enter the corresponding password modification interface. Enter the corresponding information in this interface and click OK to complete the password modification D、Parameter backup and recovery Click to verify the password and enter the backup and recovery interface。... - Page 17 There are four types of parameter backup and recovery in this interface. User parameters and one click switch require a USB flash drive as a container for storing and retrieving backup files, while initial parameters only support recovery。 data type Description User parameters Back up the current model parameters to a USB flash drive or restore the...
- Page 18 screen without the need for a USB flash drive Initialization You can select the parameter file of the corresponding model in the LCD screen and restore the parameters to this program. This function can only be used for recovery and cannot be backed up click You can save the data used in this program as a file and then restore it on replacement...
- Page 19 E、Output Log Settings In this setting, the operation logs of the LCD screen and the main control board can be output, and the level of log information can be set. The output logs of the LCD screen can only be saved in the USB flash drive, while the output methods of the main control board can be saved through jLink, USB flash drive, and serial port.
-
Page 20: Factory Mode
levels Output warning level and above logs Output log information for fatal, severe, and warning levels Output ordinary level and above logs Output log information except for debugging and scanning levels Output debug level and above logs Output log information except for scan level Output scan level and above logs Output all log information [5] Factory mode... -
Page 21: C、Output Signal
B、Input signal Select and click the input signal button to view the current input signal. This interface displays all the input signals that will exist for this machine. The color of the square after the text can be used to determine whether there is a signal coming in. White represents no signal input, and green represents signal input。... - Page 22 The content of the output signal can be customized, and the type of output signal and parameter settings at the top can be controlled through the bottom Function Description Perform an output signal state switch, and change the current output state at this time, regardless of the duration and number of executions 0&1...
-
Page 23: D、Single Axis Testing
D、Single axis testing Select and click the single axis test button to enter the single axis test interface. At this time, all axes are not selected. Select and press the axis that needs to be modified, and the button will change. -
Page 24: F、Alarm Record
F、Alarm Record Select Factory Mode "Alarm Record to enter the alarm record interface, where you can see the historical record of the equipment's alarm information. Each alarm record has its error code and the current number of production pieces You can select the serial number of the error message and press the button to view the problem represented by the current error code。... -
Page 25: G、Lcd Detection
G、LCD detection Select Factory Mode: LCD detection starts the LCD screen detection mode. At this time, the LCD screen enters a solid color display state, and clicking can switch colors. At this time, it is necessary to self detect whether there are any bad points in the LCD screen。 H、Functional testing Select Factory Mode "function test to enter the testing interface and test various functions of the machine... - Page 26 Function Description channel select Select one of the four channels for testing Start/Stop Start or stop the vibration disk test Function Description...
- Page 27 Last step Perform the previous action Next step Perform the next step Reset Perform a reset operation to restore the machine to its initial position Function Description Stacking motor Click on the data location to enter working time modification mode, where you can modify the execution time of the material receiving motor Delayed...
