全自动热转移印标机
Automatic heat transfer marking machine
（MB4006A）
使用说明书
Instruction Manual
常州智谷机电科技有限公司
CHANGZHOU WISDOM & VALLEY ELECTRICAL TECHNOLOGY CO.,LTD
在使用本设备之前请先阅读本使用说明书.
Please read the operation manual of the touch
screen interface before using the device
请将本使用说明书放在便于查阅的地方保管
版本信息/ Version
Please keep this operation manual of touch screen
2022.04.03
interface in convenient place for referenc
Advertisement
Table of Contents
Related Manuals for IMB MB4006A
Summary of Contents for IMB MB4006A
- Page 1 全自动热转移印标机 Automatic heat transfer marking machine （MB4006A） 使用说明书 Instruction Manual 常州智谷机电科技有限公司 CHANGZHOU WISDOM & VALLEY ELECTRICAL TECHNOLOGY CO.,LTD 在使用本设备之前请先阅读本使用说明书. Please read the operation manual of the touch screen interface before using the device 请将本使用说明书放在便于查阅的地方保管 版本信息/ Version Please keep this operation manual of touch screen 2022.04.03...
- Page 2 We are happy to receive suggestions and/or indications on ways we could improve this manual. 本机介绍说明分为二部分，具体请参照《MB4006A 全自动热转移印标机-使用说明书》 、 《MB4006A 全自动热转移印标机-零件手册》 、 《MB4006A 全自动热转移印标机-触摸屏操 作说明》 。 The introduction of this machine is divided into three parts. For details, please refer to 《MB4006A Operation manual》 and 《MB4006A Parts Manual》 《MB4006A Touch screen interface operation instructions》...
- Page 3 ENGLISH...
-
Page 4: Table Of Contents
Catalog 1、Basic information of equipment ......................1 2、Technical parameters of equipment ....................2 3、Safety precautions ..........................3 4、Key function .............................. 5 4.1 Button function description ..................... 5 5、Operating instructions ......................... 7 5.1 Preparation before operation ....................7 5.2 Operation process description ....................7 6、debugging .............................. -
Page 5: 1、Basic Information Of Equipment
1、Basic information of equipment 1：Label absorbing mechanism； 2：Heating unit； 3：Light；4：Worktable； 5：rotating stand； 6：Loader 7：Touch screen... -
Page 6: 2、Technical Parameters Of Equipment
2、Technical parameters of equipment MB4006A Heating device Heater HP-16P-XT Size/mm Maximum160*160 Working voltage/V Working pressure/Mpa 0.3-0.6 Machine power：1.8 Power/kw Heater power:1.1 Temperature/℃ 0-195 Noise/ dB <80 Protection level IP44 Size/mm 2500L×1850W×1650H... -
Page 7: 3、Safety Precautions
3、Safety precautions Considerations for safe use of automata 1. In order to prevent accidents caused by electric shock, please do not open the cover of the electrical box of the motor or touch the parts in the electrical box when the power is connected. 1. - Page 8 16. When the power switch is turned off during the foot press action, please be careful not to pinch your fingers. 17. During folding operation, please be careful not to clip the cylinder to your finger when putting your finger into the folding machine. ** important safety information: √...
-
Page 9: 4、Key Function
4、Key function 4.1 Button function description （1） ：Power switch -- turn the power switch to on at 90 ° to power and ventilate the equipment。 （2） ：Manual switch - press left and right at the same time, the machine runs a station。 。 （3）... - Page 10 a. Boot interface b. Main interface...
-
Page 11: 5、Operating Instructions
5、Operating instructions 5.1 Preparation before operation √ When the operator checks, the machine head should be in the stop state √ Check whether the sewing thread is properly put on √ Check whether the needle has been installed √ Clean up the debris on the machine table to ensure that there will be no debris obstructing the operation of the machine √... - Page 12 5.2.3 Pressing a) Process parameter setting: set pressing parameters in 5.2.2 benchmarking interface(see mb4006a automatic heat transfer marking machine - touch screen operation instructions for details) b) Turn on the function according to the demand c) Set the temperature according to step 6.4 and wait for heating。...
-
Page 13: 6、Debugging
6、debugging 6.1 Label paper placement Screw stack handle Horizontal dimension adjustment: manually move the spherical handle forward to increase the left and right spacing, and move the spherical handle backward to reduce the left and right spacing Longitudinal dimension adjustment: manually loosen the embossing hand screw to move the stack position forward and backward。... -
Page 14: Origin Adjustment
6.2 Origin adjustment screw switch Manually rotate the adjusting screw clockwise to move the proximity switch to the left, and rotate the adjusting screw counterclockwise to move the proximity switch to the right。 After each adjustment, you need to click the button in the benchmarking interface to make the connecting rod swing once ，The final debugging result is shown in the figure below... -
Page 15: Cleaning Of Fan Filter Element
6.3 Cleaning of fan filter element handle When the fan is overheated or cleaned according to the specified cycle： Manually remove the two plum handle, take out the filter element, clean it up, and then reassemble. If there is overheating protection, you need to wait for the fan temperature to decrease before the machine can operate normally。... -
Page 16: 7、Electrical Wiring
7、Electrical wiring 7.1 Electronic control... -
Page 17: Air Control
7.2 Air control... -
Page 18: 8、Optional Devices
8、optional devices 8.1 stacker(large) The stacker has its own descending function. After automatically collecting a certain amount of fabric, it needs to collect them manually. After receiving, it needs to manually rotate the plum blossom handle clockwise to reset the stacker。 stacker handle... -
Page 19: Stacker(Small)
8.2 stacker(small) screws According to the different size of the fabrics, the position of the collecting suction cup is set to be adjustable ： Loosen the three fixed nuts of the suction cup, move the position of the suction cup in the waist groove to make the three suction cups fall on the cutting piece, and then tighten... -
Page 20: 9、Common Problems And Solutions
the fixed nuts of the suction cup。 screws Adjustment of the position of the receiving frame relative to the ironing machine： When there is a deviation between the overall position of the suction cup and the cutting position, loosen the two fixed screws of the receiving frame to adjust the distance between the receiving frame and the main body。... -
Page 21: 10、Daily Maintenance Requirements
10、Daily maintenance requirements 10.1. The equipment maintenance list and requirements are shown in the table below Frequency Project Description Half Daily Weekly Monthly year Dust Remove dust from equipment surface √ removal and parts Clean up the oil stains on the Clean up the √... -
Page 22: 11、Knowledge Product Protection Statemen
11、Knowledge product protection statemen MB4006Awas designed by Changzhou wisdom & valley Electric Technology Co., Ltd.。The intellectual property rights of this achievement belong to Changzhou wisdom & valley Electric Technology Co., Ltd. and are protected by national intellectual property laws and regulations.
