拉腰机
Waistband setter
（MB2003D-KS-1509P）
使用说明书
Instruction Manual
常州智谷机电科技有限公司
CHANGZHOU WISDOM & VALLEY ELECTRICAL TECHNOLOGY CO.,LTD
在使用本设备之前请先阅读本使用说明书.
Please read the operation manual of the touch
screen interface before using the device
请将本使用说明书放在便于查阅的地方保管
版本信息/ Version
Please keep this operation manual of touch screen
2022.04.03
interface in convenient place for reference
Advertisement
Table of Contents
Related Manuals for IMB MB2003D-KS-1509P
Summary of Contents for IMB MB2003D-KS-1509P
- Page 1 拉腰机 Waistband setter （MB2003D-KS-1509P） 使用说明书 Instruction Manual 常州智谷机电科技有限公司 CHANGZHOU WISDOM & VALLEY ELECTRICAL TECHNOLOGY CO.,LTD 在使用本设备之前请先阅读本使用说明书. Please read the operation manual of the touch screen interface before using the device 请将本使用说明书放在便于查阅的地方保管 版本信息/ Version Please keep this operation manual of touch screen 2022.04.03...
- Page 2 在使用此机器之前，请仔细阅读以下的说明，这样可以更好地帮到您了解此机器的相关 操作。 这些说明是根据现行的条例明确阐述了正确的工作方法。 Thank you for purchasing this industrial sewing machine from IMB Before using this automatic unit, please read the following instructions, which will help you to understand how the machine operates. These instructions illustrate the correct working methods to comply with current regulations.
- Page 3 ENGLISH...
-
Page 4: Table Of Contents
Catalog 1、Basic information of equipment ......................1 2、Technical parameters of equipment ....................2 3、Safety precautions ..........................3 4、Key function .............................. 5 4.1 Key function description ......................5 5、Operating instructions ......................... 7 5.1 Preparation before operation ....................7 5.2 Description of operation process ................... 7 6、Debugging method ............................ -
Page 5: 1、Basic Information Of Equipment
1、Basic information of equipment 1：KS-1509P machine head； 2：Touch screen； 3：Control box； 4：Table； 5：Pedal； 6：Puller... -
Page 6: 2、Technical Parameters Of Equipment
2、Technical parameters of equipment MB2003D Waistband setter Machine head KS-1509P Maximum sewing speed/rpm 4000 Working voltage/V Pressure/Mpa Stitch length /mm 2—5 waist width range /mm 30-43 Suitable fabric Denim waist type Straight/Curve Size/mm 1300L×570W×1300H Weight/kg... -
Page 7: 3、Safety Precautions
3、Safety precautions Considerations for safe use of automata 1. In order to prevent accidents caused by electric shock, please do not open the cover of the electrical box of the motor or touch the parts in the electrical box when the power is connected. 1. - Page 8 16. When the power switch is turned off during the foot press action, please be careful not to pinch your fingers. 17. During folding operation, please be careful not to clip the cylinder to your finger when putting your finger into the folding machine. * important safety information: √...
-
Page 9: 4、Key Function
4、Key function 4.1 Key function description （1） ：Power switch: press the power switch to position 1, and the equipment is powered on and ventilated。 （2） ：Foot pedal: front step sewing, back step presser foot lift。 （3） ：Pressure reducing valve: adjust the cylinder pressure of the front tugboat on the... - Page 10 left side, and adjust the cylinder pressure of the rear tugboat on the right side。 （4） ：Hand slide valve --- when the presser foot is raised, the sliding hand slide valve controls the lifting and landing of the front tug, and the front tug normally falls down （5）...
-
Page 11: 5、Operating Instructions
5、Operating instructions 5.1 Preparation before operation √ When the operator checks, the machine head should be in the stop state √ Check that the stitches have been correctly fitted √ Check whether the needle has been installed √ Clean up the sundries on the machine table to ensure that there are no sundries hindering the operation of the machine √... - Page 12 b. Curved： The sewing procedure is the same as straight waist 。 3 Shut down Press the power switch To position 0, the device is shut down，...
-
Page 13: 6、Debugging Method
6、Debugging method 6.1 signal detection Click the test button in 4.1 - (5) - B monitoring interface Enter the following interface Laser：Cover reflective paper, corresponding button turn green ，laser normal Other signals ： Click ， Turn green ， The solenoid valve reacts and the electricity is normal 6.2 Parameter setting 1. - Page 14 P-01 Sewing speed: adjust the maximum speed of the motor； P-02 Cutter working remain time: adjust the completion time of cutter cylinder action； P-03 Rear roller pressing stitches：Adjust the rear roller pressing time； P-04Needle cooler opening stitches：Adjust the up blowing time。 P-05/P-06 Intermittent Blower opening/closing stitches：A loose thread is needed in the middle of the sewing，The number of stitches can be set according to the distance，There is no need to set the parameter to 0。...
- Page 15 2.2 Motor speed control button (same as P-01 in 6.2.1 setting menu)。 2.3 Blower, cutting stitches：Click the number to change the corresponding parameter value。 Blow 1 Blow 2 Blow 3 Blow 4 Blow 1&2：Blowing operation, bottom line off line，When the pants cover the first piece of reflective paper, stop blowing according to the number of delayed stitches;...
-
Page 16: Front And Rear Roller Pressure
Blow 3&4：Blowing operation, bottom line off line，When the pants piece leaves the first piece of reflective paper, the blowing starts according to the number of delayed stitches； Rear cut：The pants piece leaves the second piece of reflective paper and starts cutting according to the number of delayed stitches。... -
Page 17: Speed Ratio Between Roller And Feed Dog
6.4 Speed ratio between roller and feed dog 1.Feed dog：Refer to the manual of machine head，Adjust the eccentricity at the position Eccentricity shown in the figure，The eccentricity is adjusted according to the required needle pitch。 2.Lower roller：Adjust the position of both ends of the connecting rod in the figure below to adjust the speed of the lower roller；... -
Page 18: Position Of Upper And Lower Roller Baffle
The speed of lower tug, front tug and feed dog should be synchronized 3.Rear roller：Adjust the relative position between the nut and the right crank of the front roller to ensure that the fabric is flat when the cutter is running 。... -
Page 19: Cutter Change
○ 2 6.6 Cutter change 1) Remove the two fixing screws ○ in the figure above, and take out the cutter device 2) Remove the upper cutter fixing screw ○ ， Remove the upper cutter, replace the new cutter, and install the fixing screw ○ and tighten；... -
Page 20: 7、Electrical Wiring
7、Electrical wiring 7.1 Electronic control... -
Page 21: Pneumatic Control
7.2 Pneumatic control... -
Page 22: 8、Optional Devices
8、Optional devices 8.1 Stacker ：It is mainly suitable for continuous waist cutting。... - Page 23 序号/No. 图号/Parts No. 名称/Description 数量/Qty 01200320106000 托盘底座 02200320105600 杆 1 02200320105700 杆 2 02200320105800 杆 3 02200320105200 连杆抱箍 02200320105000 腰带托盘 02200320105100 托盘固定块 02200320105400 导向杆 02200320105300 导向杆抱箍 02200320105500 过布杆 050200501013 脚轮调整块 01200320106100 托盘架 012003230003 底座用支架 CLTB10 060202000043 内六角圆柱头螺钉 M4×16 060204000047 内六角平端紧定螺钉 M4×4 060202000040 内六角圆柱头螺钉...
-
Page 24: 9、Accessory Box Details
9、Accessory box details ITEM 《instruction manual》 《Parts Manual》 Machine head accessory Front roller (curved) Thread stand cover Head cover plate... -
Page 25: 10、Common Problems And Solutions
10、Common problems and Solutions phenomenon Picture Cause analysis Solutions 1. Adjust the adjusting screw of lower cutter Waist cut according to steps Cutter wear constantly 6.6-3 and 6.6-4 2. Replace the upper and lower cutters according to 6.6 There is Refer to "mb2003d deviation in waist pulling... -
Page 26: 11、Daily Maintenance Requirements
11、Daily maintenance requirements 11.1. Equipment maintenance list and requirements are shown in the table below 11.2. For other maintenance requirements of the machine head, please refer to the manual of the sewing machine head Frequency Project Requirment Half Daily Weekly Monthly year Clean up the Remove dust on equipment surface... -
Page 27: 12、Knowledge Product Protection Statement
12、Knowledge product protection statement MB2003D waistband setter was designed by Changzhou wisdom & valley Electric Technology Co., Ltd.。The intellectual property rights of this achievement belong to Changzhou wisdom & valley Electric Technology Co., Ltd. and are protected by national intellectual property laws and regulations.
