CheckMate™ Lawn Striping Kit Installation Guide: Snapper
Rear Engine Rider
Important
Big League Lawns, LLC warrants their products to be free of defects in material and workmanship.
This warranty does not cover defects due directly or indirectly to misuse, abuse, normal wear and tear,
failure to properly maintain the product or used for a purpose other than that for which it is intended.
The duration of this warranty is expressly limited to one year parts and labor beginning from the date
of delivery to the original customer.
The obligation of Big League Lawns, LLC is limited solely to the repair or replacement, at our option,
at its factory or authorized repair agent of any part that should prove deficient. Purchaser must
maintain the product under normal operating conditions at all times. Prior to operation, become
familiar with the attachment and any disconnect features. This product is not intended to be used in a
transport position or to be backed over curbs. When not in use, the product should be removed from
the mower and transported in a safe manner. Failure to follow these instructions will void the
warranty.
