Big League Lawns CheckMate Lawn Striping Kit Installation Manual

For ferris fw25

1125 Mak Tech Dr C

Lansing, MI 48906

800.411.0150

www.bigleaguelawns.com

CheckMate™ Lawn Striping Kit For Ferris FW25 Installation Guide

Important

Big League Lawns, LLC warrants their products to be free of defects in material and workmanship.

This warranty does not cover defects due directly or indirectly to misuse, abuse, normal wear and tear,

failure to properly maintain the product or used for a purpose other than that for which it is intended.

The duration of this warranty is expressly limited to one year parts and labor beginning from the date

of delivery to the original customer.

The obligation of Big League Lawns, LLC is limited solely to the repair or replacement, at our option,

at its factory or authorized repair agent of any part that should prove deficient. Purchaser must

maintain the product under normal operating conditions at all times. Prior to operation, become

familiar with the attachment and any disconnect features. This product is not intended to be used in a

transport position or to be backed over curbs. When not in use, the product should be removed from

the mower and transported in a safe manner. Failure to follow these instructions will void the

warranty.

Table of Contents

Do you have a question about the CheckMate Lawn Striping Kit and is the answer not in the manual?

Page 1 The obligation of Big League Lawns, LLC is limited solely to the repair or replacement, at our option, at its factory or authorized repair agent of any part that should prove deficient. Purchaser must maintain the product under normal operating conditions at all times.
Page 2 US Patent 6,962,039 B2, US Patent 6,993,894 B2 Mounting Instructions Ferris FW25 Series Mowers Congratulations on your new purchase! You are just steps away from creating a beautifully patterned lawn using your new CheckMate™ lawn striping roller. To ensure a long life of both your mower and roller, please be sure to follow the mounting recommendations below.
Page 3 Directions Unit is shipped with two 3/8" to 3/8" Coupler Nuts. To install, you must reverse the noted bolt (circled) on each side of your mower so that the threads point outward towards the tires. You will then re-secure the bolt by attaching the 3/8" coupler nut. The opposite end of the coupler nut will have the 3/8"...
