  • Page 1 All manuals and user guides at all-guides.com Owner’s Guide Mitsubishi Plasma Display PD-5050 & PD-6150...

  • Page 2: Read Before Operating Equipment

    All manuals and user guides at all-guides.com IMPORTANT SAFETY INSTRUCTIONS (PD-5050/PD-6150) Read before operating equipment 1. Read these instructions. 17. Tilt/Stability - All televisions must comply with 2. Keep these instructions. recommended international global safety standards for 3. Heed all warnings.

  • Page 3: Warnings And Safety Precautions

    All manuals and user guides at all-guides.com Important Information Precautions Warnings and Safety Precautions Please read this manual carefully before using your Mitsubishi The Mitsubishi plasma display is designed and plasma display and keep the manual handy for future reference. manufactured to provide long, trouble-free service.
  • Page 4 *ORBITER - Uneven phosphor aging/burn-in reduction feature. To minimize the risk of uneven phosphor aging/burn-in when displaying still images, the Mitsubishi PD-5050 and PD-6150 offers a built-in feature known as ORBITER. The ORBITER feature intermittently shifts the screen image horizontally and vertically in small increments. This intermittent screen movement is usually not evident in full motion video.
  • Page 5 All manuals and user guides at all-guides.com WARNING: Do not leave stationary or letterbox images on-screen for extended periods of time. Mix types of pictures shown. Uneven phosphor aging is NOT covered by your warranty. The normal use of a TV should include a mixture of TV Still or stationary images may be received from broadcasters, picture types.

  • Page 6: Cleaning Safeguards

    All manuals and user guides at all-guides.com Cleaning Safeguards Plasma Display Screen & Cabinet Please follow the cleaning safeguards listed below to prevent damage to your Plasma Display and retain this document for future reference. IMPORTANT: No Abrasives! DO NOT use any kind of abrasive cloth or cleaner or ammonia on the Plasma Display’s screen or cabinet.

  • Page 7: The Features You'll Enjoy Include

    Contents of the Package PD-6150 Plasma Displays Plasma display Power cord Mitsubishi’s PD-5050/PD-6150 plasma displays are a Remote control with two AAA Batteries seamless blend of cutting-edge visual technology and Owner’s guide sophisticated design. The displays sleek techno-art lines blend Registration Card in well with most environments.
  • Page 8 All manuals and user guides at all-guides.com �������� ������������ ������������������������������������������������������ � �������������������������� ������������������������������������ �� Adjusting the Position, Size, Fine Picture, Picture Adj ..�� �������������������� �������������������������������������������������� � �������������������� ���������������������������������������������� �� ����������������������������������������������� ����������� � Setting the language for the menus ......�� �������������������������������������������������������...
  • Page 9 All manuals and user guides at all-guides.com...
  • Page 10 All manuals and user guides at all-guides.com ������������ �������������������� CAUTION This device needs to be attached to a stand or other mounting hardware. Be sure to use a stand or other mounting hardware that is designed specifically for this product. DO NOT USE THE BOTTOM CARTON AS A TEMPORARY OR PERMANENT STAND.
  • Page 11 All manuals and user guides at all-guides.com ����������������������� ���������� ������������� ���������� ������ ������ ������� ���������� ����� � ������ � ���������� ������ ���������� ������������� � � � � � � � � POWER � LEFT/– and RIGHT/+ Push this button to turn the display’s main power on or Functions as the ADJUST ( ) buttons in the On- �/...
  • Page 12 All manuals and user guides at all-guides.com ��������� ��������� A AC IN F RGB2 / COMPONENT2 Connect the included power cord here. COMP2: You can connect DVDs, High Definition sources, Cable Boxes, etc. B EXT SPEAKER L and R here. Connect speakers (optional) here.
  • Page 13 All manuals and user guides at all-guides.com �������������� � ADJUST (� / � / �/ � � Use these buttons to select items or settings and to adjust settings or switch the display patterns. � EXIT Press this button to exit the MAIN MENU. Press this button during the display of the sub menu to return to the previous menu.
  • Page 14 All manuals and user guides at all-guides.com Operating Range ����������������������������� * Use the remote control within a distance of about 7 m/ Battery Installation and Replacement 23ft. from the front of the display’s remote control sensor and at horizontal and vertical angles of up to approximately Insert the 2 “AAA”...
  • Page 15 All manuals and user guides at all-guides.com ����������� ������������������������ �������� � ������������������ ������������������ ���������������� ����������� ���������������������� ������������������������ ��������������� ������������������� ������������������������ ���������������������������������������������������� ��������������������������������� �������������� ������������...
  • Page 16 All manuals and user guides at all-guides.com ���������������������������������������� ������������������� Connecting your PC or Macintosh computer to your plasma Use common RCA cables* (not provided) to connect your display will enable you to display your computer’s screen VCR to your plasma display. To make these connections, image for an impressive presentation.
  • Page 17 All manuals and user guides at all-guides.com ������������������������ ��������������������������������� MonitorLink and MonitorLink Control ������������������������������� ��������� 1. Connect a HDMI to HDMI cable from the MONLINK OUTPUT of a Mitsubishi HD-6000 Receiver/Controller to the MONLINK input on the plasma display. A HDMI 10 9 to HDMI cable and a RS-232C cable are included in 15 14 13 12 11...
  • Page 18 All manuals and user guides at all-guides.com ���������������� Using the cable clamps provided with the plasma display Back of the unit bundle and attach the signal and audio cables to the back panel. mounting hooks/mounting holes To attach To detach �����...

  • Page 19: Basic Operations

    All manuals and user guides at all-guides.com Basic Operations POWER INFO To check the settings: 1. Plug the power cord into an active AC power outlet. 1. The screen changes each time the INFO button is pressed. 2. Press the Power button located underneath the right side of the front panel.

  • Page 20: Sleep/Off Timer

    All manuals and user guides at all-guides.com SLEEP/OFF TIMER To cancel the off timer: To set the off timer: 1. Press the SLEEP button twice in a row. The off timer can be set to turn the power off after 30, 60, 2.

  • Page 21: Format Sizes

    All manuals and user guides at all-guides.com Format Sizes Format Operation EXPAND screen size (manual) With this function, you can select one of six screen sizes. When viewing videos or digital video discs 1. Press the FORMAT button on the remote control. 2.

  • Page 22: Format Operation With Computer Signals

    All manuals and user guides at all-guides.com Format Operation with Computer Information Signals Supported resolution Switch to the wide screen mode to expand the 4 : 3 image See page 34 for details on the display output of the to fill the entire screen. various VESA signal standards supported by the display.

  • Page 23: Menu Controls

    All manuals and user guides at all-guides.com Menu Controls Menu Operations The following describes how to use the menus and the selected items. 1. Press the MENU/ENTER button on the remote control to display the MAIN MENU. MAIN MENU SET UP PICTURE AUDIO FUNCTION...
  • Page 24 All manuals and user guides at all-guides.com ��������� ��������� :Shaded areas indicate the default value. :Shaded areas indicate the default value. button to adjust. The default value is at the center. : Press the ���� � � button to adjust. The default value is at the center. : Press the ����...
  • Page 25 All manuals and user guides at all-guides.com Main menu Sub menu Sub menu 2 Sub menu 3 Sub menu 4 RESET PAGE # REFERENCE FUNCTION POWER MGT. ON←→OFF INPUT SKIP ON←→OFF LONGLIFE MANUAL/AUTO PEAK BRIGHT 100%/75%/50%/25% ORBITER AUTO1/AUTO2/OFF INVERSE/WHITE OFF/INVERSE/WHITE SOFT FOCUS OFF/1-4 ORBITER MENU...

  • Page 26: Picture Settings Menu

    All manuals and user guides at all-guides.com Picture Settings Menu Adjusting the picture The contrast, brightness, sharpness, color and tint can be Storing picture settings adjusted as desired. This function allows you to store in memory the current input signal and PICTURE menu settings and to recall Example: Adjusting the contrast these settings when necessary.

  • Page 27: Reducing Noise In The Picture

    All manuals and user guides at all-guides.com Reducing noise in the picture Use these settings if the picture has noise due to poor reception or when playing video tapes which have poor picture quality. Example: Setting “NR-3” Press MENU/ENTER button to access MAIN MENU. ▲...

  • Page 28: Setting The Color Temperature

    All manuals and user guides at all-guides.com Setting the color temperature Changing the Gamma Curve Use this procedure to set color tone produced by the plasma This feature adjusts the brightness of the midtone areas display. while keeping shadows and highlights unchanged. Example: Setting “HIGH”...

  • Page 29: Film Mode

    All manuals and user guides at all-guides.com Adjusting the pedestal level (black level) FILM Mode This feature adjusts the video black level in a video image. Press MENU/ENTER button to access MAIN MENU. ▲ ▼ buttons to select the PICTURE menu and Example: Setting “3.75%”...

  • Page 30: Image Adjust Settings Menu

    All manuals and user guides at all-guides.com Audio Settings Menu Image Adjust Settings Menu Adjusting the treble, bass and left/right Adjusting the Position, Size, Fine Picture, Picture Adj balance and audio input select The position of the image can be adjusted and flickering The treble, bass and left/right balance can be adjusted to of the image can be corrected.

  • Page 31: Set Up Settings Menu

    All manuals and user guides at all-guides.com SET UP Settings Menu Setting high definition images to the suitable screen size Setting the language for the menus DO NOT CHANGE THIS SETTING. 1080I is the US The menu display can be set to one of eight languages. digital broadcast standard.
  • Page 32 All manuals and user guides at all-guides.com Setting the video signal format ����������� ������������������������������� Use these operations to set the color systems of composite ����������� � RGB SELECT modes video signals or Y/C input signals. ���������������������������������������������������������� ������������������ ����������������������������������� One of these 7 modes must be selected in order to Example: Setting the color system to “3.58 NTSC”...

  • Page 33: Setting The Screen Size For S1/S2 Video Input

    All manuals and user guides at all-guides.com Setting the gray level for the sides of the screen Turning the display menu on/off Use this procedure to set the gray level for the parts on the When this is set to OFF, the menu will not be displayed screen on which nothing is displayed when the screen is even if you press the MENU/ENTER button.

  • Page 34: Resetting To The Default Values

    All manuals and user guides at all-guides.com Resetting to the default values Use these operations to restore all the settings (PICTURE, AUDIO, IMAGE ADJUST, SET UP, etc) to the factory default values. Refer to pages 15 & 16 for items to be reset. Press MENU/ENTER button to access the MAIN MENU.

  • Page 35: Function Settings Menu

    All manuals and user guides at all-guides.com Function Settings Menu Setting the Input Skip When this is ON, signals which are not present will be Setting the power management for computer skipped over and only pictures whose signals are being images transmitted will be displayed.

  • Page 36: Peak Bright

    All manuals and user guides at all-guides.com PEAK BRIGHT INVERSE/WHITE Use this to activate the brightness limiter. Use this to set the inverse mode or to display a white screen. Example: Setting “PEAK BRIGHT” to “75%” Example: Setting “INVERSE/WHITE” to “WHITE” Follow the instructions given in the “Reducing burn-in of Follow the instructions given in the “Reducing burn-in of the screen”...

  • Page 37: Signal Information Menu

    All manuals and user guides at all-guides.com Signal Information Menu ORBITER MENU Checking the frequencies, polarities of input Use this to set menu shift. signals, and resolution Example: Setting “ORBITER MENU” to “OFF” Use this function to check the frequencies and polarities Follow the instructions given in the “Reducing Burn-in of the signals currently being input from a computer, etc.

  • Page 38: Monitorlink Control

    All manuals and user guides at all-guides.com MonitorLink Control Application These specifications cover the communications control of MonitorLink Control Codes (Reference) the plasma monitor by external equipment. FUNCTION CODE DATA Use a crossed (reverse) cable. Power ON 9FH 80H 60H 4EH 00H CDH 9FH 80H 60H 4FH 00H CEH Type of connector: D-Sub 9-pin male Input Switch INPUT1 (BNC)

  • Page 39: Troubleshooting

    All manuals and user guides at all-guides.com Troubleshooting If the picture quality is poor or there is some other problem, check the adjustments, operations, etc., before requesting service. Symptom Checks Remedy Picture moves intermittently around Is ORBITER ON (AUTO1)? • Default seting for ORBITER is ON (AUTO1). the screen.
  • Page 40 All manuals and user guides at all-guides.com *1 Overheat protector If the display becomes too hot, the overheat protector will be activated and the display will be turned off. If this happens, turn off the power to the display and unplug the power cord. If the room where the display is installed is particularly hot, move the display to a cooler location and wait for the display to cool for 60 minutes.
  • Page 41 All manuals and user guides at all-guides.com PD-5050 Specifications Screen Size 43.5"(H) 24.5"(V) inches 1106(H) 622(V) mm 1.6" 2.3" diagonal 50" (41) 48.1" (1222) (58) Aspect Ratio 16 : 9 Resolution 1365(H) 768(V) pixels 43.5" (1106) Pixel Pitch 0.032"(H) 0.032"(V) inches 0.81(H) 0.81(V) mm...
  • Page 42 All manuals and user guides at all-guides.com PD-6150 Specifications Screen Size 53.2"(H) 29.9"(V) inches 1351(H) 760(V) mm 1.9" 2.9" diagonal 61" (48) 57.9" (1470) (74) Aspect Ratio 16 : 9 Resolution 1365(H) 768(V) pixels 53.2" (1351) Pixel Pitch 0.039"(H) 0.039"(V) inches 0.99(H) 0.99(V) mm Color Processing 4,096 steps, 68.7 billion colors...
  • Page 43 All manuals and user guides at all-guides.com �������������������������� �������������������������� �������������������� �������������������� • When the screen mode is NARROW, each signal is converted to a 1024 dots�768 lines signal. (Except for * • When the screen mode is NARROW, each signal is converted to a 1024 dots�768 lines signal. (Except for * 2, 3, 4 2, 3, 4 •...
  • Page 44 All manuals and user guides at all-guides.com *1 Only when using a graphic accelerator board that is capable of displaying 852 480. *2 This signal is converted to a 1024 dots 640 lines signal. *3 The picture is displayed in the original resolution. *4 The aspect ratio is 5:4.

  • Page 45: To Obtain Warranty Service

    All manuals and user guides at all-guides.com Mitsubishi Plasma Display Panel Limited Warranty MITSUBISHI DIGITAL ELECTRONICS AMERICA, INC. (“MDEA”) warrants to the original purchaser of this Plasma Display Panel that if purchased from an authorized MITSUBISHI Audio/Video Dealer, should it prove defective by reason of improper workmanship and/or material: a.

  • Page 46: Declaration Of Conformity

    Type of Product: Plasma Display Equipment Classification: Class B Peripheral Models: PD-5050/PD-6150 We hereby declare that the equipment specified above conforms to the technical standards as specified in the FCC Rules. Mitsubishi Digital Electronics America 9351 Jeronimo Road Irvine, CA 92618...
