Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following image indicates the location of the intrusion switch and provides a visual representation of the installation
procedure.
Figure 71. Installing the intrusion switch
Steps
1. Insert the intrusion switch into its slot and slide the switch to secure it into the slot.
2. Route the intruder switch cable through the routing guide and connect the intruder cable to the connector on the system
board.
Next steps
1. Install the air shroud.
NOTE: For systems with 500W/1000W PSU only.
2. Install the side cover.
3. Follow the procedure in

Internal speaker

Removing the internal speaker

CAUTION: The information in this removal section is intended for authorized service technicians only.
after working inside your computer.
Removing and installing Field Replaceable Units (FRUs) 99
