Summary of Contents for Amate Audio RB-S
- Page 1 User’s manual Manual de usuario RB-S Flying bar for S6L, S6LP, S26, S26P, S10, S10P, S46, S46P, N12A6, N12P7 Perfil colgado para S6L, S6LP, S26, S26P, S10, S10P, S46, S46P, N12A6, N12P7 March 2024...
- Page 2 (orientación vertical). Remove the M8 locking screw (A)(B) and the front M4 screw (D) from the main RB-S structure. Release the threated bar (C). ~ Desenrosque el tornillo de seguridad M8 (A)(B) y el tornillo frontal pequeño M4 (D) de la estructura principal RB-S.
- Page 3 RB-S Mar 2024 S6L / S6LP S26 / S26P S46 / S46P S10 / S10P Amate Audio...
- Page 4 Set the RB-S bar as per the drawing below. Block it with the two indicated M8 screws. Use point A and B. ~ Colocar la barra RB-S tal como se muestra en el dibujo y blocar los puntos A y B mediante los dos tornillos de M8 suministrados en el kit.
- Page 5 RB-S Mar 2024 S46 / S46P S10 / S10P N12P7 / N12A6 Amate Audio...
- Page 6 RB-S Mar 2024 Remove the self-locking nut (F), metal washer (G) and nylon washer (H) from the threated bar. ~ Quitar la tuerca autoblocante (F), arandela de metal (G) y arandela de nylon (H) del perno de colgado. Set the threated bar onto the flying column. Block it with the self-locking nut (F), metal washer (G) and nylon washer (H).
- Page 7 RB-S Mar 2024 Join the cabinet with the threated bar (1). a) Firstly, put the front safety screw M4 (2)(D). b) Use the bar holes to tilt the cabinet as per your desired inclination (3). c) Put the locking M8 screw and self-locking nut (A)(B).
- Page 8 RB-S Mar 2024 S6L / S6LP Amate Audio...
- Page 9 RB-S Mar 2024 S26 / S26P Amate Audio...
- Page 10 RB-S Mar 2024 S46 / S46P Amate Audio...
- Page 11 RB-S Mar 2024 S10 / S10P Amate Audio...
- Page 12 RB-S Mar 2024 N12P7 / N12A6 Amate Audio...
