- Page 1 User’s manual Manual de usuario RB-L/GT Flying bar with hook for S12, S12P, S15, S15P, X14FD, X102FD Perfil colgado con garfio para S12, S12P, S15, S15P, X14FD, X102FD March 2024...
- Page 2 The RB-L/GT is an optional accessory for hanging on truss (vertical orientation). El RB-L/GT es un accesorio opcional para el colgado en truss (orientación vertical). Remove the M8 ball lock pin (A) and the front M4 screw (C) from the main RB-L structure.
- Page 3 RB-L/GT Mar 2024 S12 / S12P S15 / S15P X14FD Amate Audio...
- Page 4 RB-L/GT Mar 2024 X102FD Set the RB-L bar as per the drawing below. Block it with the two indicated M8 screws. Use point A and B. ~ Colocar la barra RB-L tal como se muestra en el dibujo y blocar los puntos A y B mediante los dos tornillos de M8 suministrados en el kit.
- Page 5 RB-L/GT Mar 2024 X14FD X102FD Set the hook onto the truss. ~ Colocar el garfio en el truss. Amate Audio...
- Page 6 RB-L/GT Mar 2024 Join the cabinet with the hook adapter (1). a) Firstly, put the front safety screw M4 (2)(C). b) Use the bar holes to tilt the cabinet as per your desired inclination (3). c) Put the locking M8 ball lock pin (A).
- Page 7 RB-L/GT Mar 2024 S12 / S12P Amate Audio...
- Page 8 RB-L/GT Mar 2024 S15 / S15P Amate Audio...
- Page 9 RB-L/GT Mar 2024 X14FD Amate Audio...
- Page 10 RB-L/GT Mar 2024 X102FD Amate Audio...
