- Page 1 User’s manual Manual de usuario UB-L Universal wall-bracket Soporte pared universal June 2018...
- Page 2 UB-L June 2018 The UB-L is an optional accessory for wall mounting (horizontal orientation). El UB-L es un accesorio opcional para el colgado en pared (horizontal). Locking screw (left) Tornillo para bloqueo (izquierda) Locking block (right) Cilindro para bloqueo (derecha)
- Page 3 UB-L June 2018 1- Put the locking block inside the 35-mm top hat’s hole (except in JK12MA) Coloque el cilindro dentro del agujero del vaso de 35mm (menos en la JK12MA) 2- Remove the top M8 screw. Put the new locking screw...
- Page 4 UB-L June 2018 JK12 / JK12A KEY12 / KEY12A JK15 / JK15N / JK15A / JK15NA KEY15 / KEY15A KEY8 X15T/X15D Amate Audio...
- Page 5 UB-L June 2018 X14T JK12MA N26 / N26P N12 / N12P N15 / N15P Amate Audio...
- Page 6 UB-L June 2018 3- Remove the screw from the locking block and place it on the following M8 hole (only in JK12MA) Desenrosque el cilindro de coloque conjunto sobrante (tornillo y arandelas) en el punto indicado con una flecha (sólo para JK12MA)
- Page 7 UB-L June 2018 JK10MA KEY10 / KEY10A JK12 / JK12A KEY12 / KEY12A Amate Audio...
- Page 8 UB-L June 2018 JK15 / JK15N / JK15A / JK15NA KEY15 / KEY15A KEY8 X15T/X15D Amate Audio...
- Page 9 UB-L June 2018 X14T JK12MA N26 / N26P N12 / N12P Amate Audio...
- Page 10 UB-L June 2018 N15 / N15P 5- Place the supplied template on the wall and mark the fixing points in the correct location, according to each model. Coloque la plantilla de papel en la pared y marque los puntos de fijación...
- Page 11 UB-L June 2018 KEY15 / KEY15A / JK15 / JK15N / JK15A / JK15NA (701mm) X15T/ X15D (733mm) X14T / N12 / N12P (638mm) N26 / N26P (552mm) Amate Audio...
- Page 12 UB-L June 2018 N10 (558mm) N15 / N15P (748mm) 6- Drill some corresponding pilot holes on the wall and fix the bracket using the wall plugs and the six DIN7505B 5x30 screws supplied in the kit Realice los taladros en la pared y cuelgue el soporte con tornillería adecuada y de alta resistencia (tacos M6 y tornillos DIN7505B 5x30 suministrados en el “kit”)
- Page 13 UB-L June 2018 Choose desired tilt angle block cabinet with the M8 lateral screws. Use the Allen tool. Dar la inclinación necesaria y blocar tornillos laterales Use la llave Allen. 9- You can use the safety cable around the ACRM8 eyebolts. In this case, fix the safety cable on a secondary external point.
