- Page 1 PROGRAMMABLE CONTROLLER FPΣ CC-Link Slave Unit FPO CC-Link Slave Unit Technical Manual WUME-FP0CCLINK-06 2024.4 industry.panasonic.com/...
- Page 2 It could lead to an electric shock. Copyright / Trademarks -This manual and its contents are copyrighted. Panasonic -You may not copy this manual, in whole or part, without written consent of Industry Co., Ltd. -Windows is a registered trademark of Microsoft Corporation in the United States and other countries.
-
Page 3: Table Of Contents
Table of Contents Precautions before Using CC-link Slave Unit 1 Functions of CC-Link Slave Unit ......................... 1 1.1 Unit Functions ........................................1 1.2 Unit Type ..........................................1 1.3 Unit Connection ........................................2 2 Part Names and Functions .......................... 3 2.1 Part Names and Functions ...................................3 3 Allocation of Input/Output and Shared Memory.................. -
Page 4: Precautions Before Using Cc-Link Slave Unit
Precautions before Using CC-Link Slave Unit - Mounting plate - Note that the types of mounting plates used for FPΣand FP0 are different. Unit name (including CPU) Mounting plate to be used FPΣCC-Link slave unit Slim type 30 FP0 mounting plate AFP0811 FP0 CC-Link slave unit Slim type FP0 mounting plate... -
Page 5: Functions Of Cc-Link Slave Unit
I/O points exchanged with CC-Link Product No. Note3 master station 256 points Max. 224 points Max. Σ FPG-CCLS (Input: 128) (Input: 112, Output 112) AFPG7943 CC-Link slave unit (Output: 128) 16-word data read/write (Max.) 192 points Max. 32 points Max. -
Page 6: Unit Connection
1.3 Unit Connection - Limitations in unit number and position - FPΣCC-Link slave unit Up to 4 expansion units (including other FPΣexpansion unit and FPΣhigh-performance unit) can be installed. - FP0 CC-Link slave unit Up to 3 expansion units (including other FP0 expansion unit and FP0 high-performance unit) can be installed. -
Page 7: Part Names And Functions
2 Part Names and Functions 2.1 Part Names and Functions - FPΣCC-Link slave unit (FPG-CCLS) AFPG7943 - FP0 CC-Link slave unit (FP0-CCLS) AFP07943 ①Operating monitor LEDs ②Number of occupied stations (Available only for FPΣCC-Link slave unit) ③Station No. selector switch ④Baud rate selection switch... - Page 8 ① Operating monitor LEDs : Turns ON when communication is normal. : Turns ON when a switch setting error has occurred. Flashes when a switch setting is changed while the power is ON. : Turns ON when data is being transmitted. : Turns ON when data is being received.
- Page 9 ⑥ Fixing screw for a detachable terminal block ⑦ Expansion connector occupied station No. selection switch (Available only for FPΣ CC-Link slave unit) Number of occupies station SW. No. 1 station 2 stations 3 stations 4 stations Note: These switch settings are available only for FPΣCC-Link slave unit.
-
Page 10: Allocation Of Input/Output And Shared Memory
3 Allocation of Input/Output and Shared Memory 3.1 FPΣCC-Link Slave Unit Communication with FPΣcontrol unit In the CC-Link slave unit, CC-Link remote input/output is allocated to the I/O area, and CC-Link remote register is allocated to the shared memory area. The number of remote words varies depending on the CC-Link station No. - Page 11 3.1.1 Expansion Unit I/O Allocation Remote input (FPΣside output) Note 2 ΣCC-Link I/O (installation position) No. of CC-Link occupied Area Points Expansion Expansion Expansion Expansion master stations remote I/O unit 1 unit 2 unit 3 unit 4 User Y100-Y10F Y180-Y18F Y260-Y26F Y340-Y34F RX00-RX0F...
- Page 12 3.1.2 Shared Memory Allocation Slot No. Note) FPΣexpansion unit No. Shared memory slot No. Note: The expansion units closer to the control unit have the lower expansion unit number. (Expansion unit 1, 2, 3 and 4 in the diagram on the left) Error information and status (All the data cannot be updated.) Shared memory address (word unit:...
- Page 13 Remote device (Addresses are indicated in a decimal number.) Σ Master station remote Number of occupied station shared memory address register Instruction Word address (Hexadecimal) RWw0 Available Available Available Available RWw1 Available Available Available Available RWw2 Available Available Available Available RWw3 Available Available...
-
Page 14: Fp0 Cc-Link Slave Unit
3.2 FP0 CC-Link Slave Unit Communication with FP0 control unit Only one FP0 CC-Link slave unit can be installed on the extreme right in the expansion unit(s). In the FP0 CC-Link slave unit; ･CC-Link remote I/O and remote register are allocated to the expansion unit I/O 1 word and 2 word (or later), respectively. - Page 15 3.2.1 Expansion Unit I/O Allocation Remote input (FP0 side output) FP0 CC-Link I/O CC-Link No. of Note1 master (installation position) occupied Area Points remote I/O stations Expansion Expansion Expansion Note2 unit 1 unit 2 unit 3 Y20-2F Y40-4F Y60-6F RX00-0F Register RWr 0 Register...
-
Page 16: Wiring
4 Wiring For details, refer to “CC-Link Cable Wiring Manual” which can be downloaded from the Web site of CC-Link Partner Association free of charge. For your reference: CC-Link Partner Association (“Precautions before Using CC-link Slave Unit” of this manual.) English: https://www.cc-link.org/eng/index.html Japanese: https://www.cc-link.org... -
Page 17: If An Error Occurs
5 If an Error Occurs 5.1 Troubleshooting Error Item Confirmation Are any cables broken? Check the cable status visually or by the line test. Are terminal resistors properly connected to the stations at the Connect terminal resistors (provided for the master station) to the both ends? stations at the both ends. -
Page 18: Err/Alarm Led
5.2 ERR/ALARM LED CC-Link slave unit status Cause of the FP0/∑ control unit (I/O point, station No., baud rate, ERR/ALARM status ALARM occupied number of stations, etc) Station No. setting Flashing Normal Operation is not affected. change Error flag can be checked in the master station. -
Page 19: Specifications
6 Specifications 6.1 Specifications - General specifications Item Description 24V DC Rated voltage 21.6 to 26.4V DC Operating voltage range CC-Link unit: 40 mA or less/24V DC Rated current consumption Increase amount in the control unit when expansion units are added: 40 mA or less/24V DC Allowed momentary power off 10 ms... - Page 20 - CC-Link communication specifications Item Description Version CC-Link Ver. 1.10 Communication method Broadcast polling method Communication speed 10Mbit/s, 5Mbit/s, 2.5Mbit/s, 625kbit/s, 156kbit/s (Baud rate) Ver. 1.10 CC-Link cable CC-Link high-performace CC-Link cable cable 10Mbit/s 100m 100m 5Mbit/s 160m 150m Maximum 2.5Mbit/s 400m 200m...
-
Page 21: Dimensions
6.2 Dimensions Σ - FP CC-Link slave unit (FPG-CCLS) AFPG7943 - FP0 CC-Link slave unit (FP0-CCLS) AFPO7943... - Page 23 Record of changes Manual No. Date Description of Changes ARCT1F380E APR.2003 First edition ARCT1F380E-1 JUL.2005 2nd edition ARCT1F380E-2 NOV.2008 3rd edition - Change in Corporate name ARCT1F380E-3 AUG.2011 4th edition - Change in Corporate name ARCT1F380E-4 JUL.2013 5th edition - Change in Corporate name WUME-FP0CCLINK-06 Apr.2024 6th edition - Change in Corporate name...
- Page 26 Panasonic Industry Co., Ltd. 1006, Oaza Kadoma, Kadoma-shi, Osaka 571-8506, Japan https://industry.panasonic.com/ Please visit our website for inquiries and about our sales network. © Panasonic Industry Co., Ltd. 2003-2024 April, 2024 WUME-FP0CCLINK-06...
