  • Page 1: Fcc Information And Copyright

    FCC Information and Copyright This equipment has been tested and found to comply with the limits of a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 2: Table Of Contents

    Table Of Contents FCC Information and Copyright ������������������������������������������������������������������������������� 1 Chapter 1: Introduction ������������������������������������������������������������������������������������������� 3 1.1 Before You Start ........................3 1.2 Specifications ........................4 Chapter 2: Hardware installation ����������������������������������������������������������������������������� 8 2.1 Install Central Processing Unit (CPU) .................. 8 2.2 Install a Heatsink ....................... 10 2.3 Connect Cooling Fans .......................
  • Page 3: Chapter 1: Introduction

    EIB7B-AXI User’s Manual Chapter 1: Introduction 1�1 Before You Start Thank you for choosing our product. Before you start installing the motherboard, please make sure you follow the instructions below: •  Prepare a dry and stable working environment with sufficient lighting.
  • Page 4: Specifications

    10% ~ 90% (non-condensing) EMI/ESD Contact with 4Kv, Air with 8Kv, EMI: Class A Win7, Win10, Ubuntu OS Support Biostar reserves the right to add or remove support for any OS with or without notice. 4 | Chapter 1: Introduction...
  • Page 5 EIB7B-AXI User’s Manual 1�3 Rear Panel Connectors COM1/COM2 Connector RS-232 (Default) RS-422 RS-485 Pin Assignment Carrier detect (DCD) Received data (RXD) Transmitted data (TXD) Data terminal ready (DTR) Signal ground (GND) Data set ready (DSR) Request to send (RTS) Clear to send (CTS)
  • Page 6 VGAL: VGA Connector This header is for VGA power. Pin 1-2 Close: Disabled (NC) Pin 1-2 Close: Enabled (Dummy Load) 6 | Chapter 1: Introduction...
  • Page 7 EIB7B-AXI User’s Manual 1�4 Motherboard Layout Note »  »  represents the 1st pin. Chapter 1: Introduction | 7...
  • Page 8: Chapter 2: Hardware Installation

    Chapter 2: Hardware installation 2.1 Install Central Processing Unit (CPU) Step 1: Locate the CPU socket on the motherboard Note »  » Remove pin cap before installation, and make good preservation for future use. When the CPU is  removed, cover the pin cap on the empty socket to ensure pin legs won’t be damaged. »  » The motherboard might equip with two different types of pin cap. Please refer below instruction to  remove the pin cap. Step 2: Pull the socket locking lever out from the socket and then raise the lever up. Step 3: Remove the Pin Cap.
  • Page 9 EIB7B-AXI User’s Manual Step 4: Hold processor with your thumb and index fingers, oriented as shown. Align the notches with the socket. Lower the processor straight down without tilting or sliding the processor in the socket. Step 5: Hold the CPU down firmly, and then lower the lever to locked position to complete the installation.
  • Page 10: Install A Heatsink

    2.2 Install a Heatsink Step 1: Place the CPU fan assembly on top of the installed CPU and make sure that the four fasteners match the motherboard holes. Orient the assembly and make the fan cable is closest to the CPU fan connector. Step 2: Press down two fasteners at one time in a diagonal sequence to secure the CPU fan assembly in place.
  • Page 11: Connect Cooling Fans

    EIB7B-AXI User’s Manual 2.3 Connect Cooling Fans These fan headers support cooling-fans built in the computer. The fan cable and connector may be different according to the fan manufacturer. Connect the fan cable to the connector while matching the black wire to pin#1.
  • Page 12: Installing System Memory

    2.4 Installing System Memory DDR3_A1/ DDR3_A2/ DDR3_B1/ DDR3_B2: Memory Module (240pin LONG-DIMM) Note »  » If the DIMM does not go in smoothly, do not force it. Pull it all the way out and try again. 1. Align a DIMM on the slot such that the notch on the DIMM matches the break on the Slot. 2. Insert the DIMM firmly into the slot until the retaining chip snap back in place and the DIMM is properly seated.
  • Page 13: Jumper & Switch Setting

    EIB7B-AXI User’s Manual PEX16_1: PCI-Express Gen3 x16 Slots •  PCI-Express 3.0 compliant. •  PCI-E x16 Gen3 Data transfer bandwidth up to16GB/. PEX4_1: PCI-Express Gen2 x4 Slots •  PCI-Express 2.0 compliant. •  PCI-E x4 Gen2 Data transfer bandwidth up to 2GB/s.
  • Page 14 JUSBPWR1U (Upper Layer)/ JUSBPWR1L (Lower Level): 5V/ 5V_DUAL Power Switch Header for USB Connector This header is for switching between 5V and 5V dual power. Pin 1-2 Close: VCC5 (Default) Pin 2-3 Short: 5V Dual JUSBPWR2U (Upper Layer)/ JUSBPWR2L (Lower Level): 5V/ 5V_DUAL Power Switch Header for USB Connector This header is for switching between 5V and 5V dual power.
  • Page 15: Headers & Connectors

    EIB7B-AXI User’s Manual 2.7 Headers & Connectors ATXPWR1: ATX Power Source Connector (24-pin) This connector allows user to connect 24-pin power connector. Assignment Assignment +3.3V +3.3V +3.3V -12V Ground Ground PS_ON Ground Ground Ground Ground Ground PW_OK Standby Voltage +5V...
  • Page 16 TPM1: Trusted Platform Module Header This header allows you to store cryptographic keys that protect information. Assignment Assignment PCLK_TPM Ground L_FRAME# PCIRST VCC5 LAD3 LAD2 VCC3 LAD1 LAD0 Ground SMB_CLK SMB_DATA 3V3_DUAL SER_IRQ Ground CLK_RUN# SUS_STAT LDRQJ1 SATA1: Serial ATA 6.0 Gb/s Connectors SATA2/ SATA3/ SATA4/ SATA5/ SATA6: Serial ATA 3.0 Gb/s Connectors These connectors support the thin Serial ATA cable for primary internal storage devices.
  • Page 17 EIB7B-AXI User’s Manual F_USB3: Header for USB 2.0 Ports at Front Panel This header allows user to add additional USB ports on the PC front panel, and also can be connected with a wide range of external peripherals. Assignment Ground F_USB4: USB 2.0 Header for vertical type A Connector...
  • Page 18 JPRNT1: Printer Port Connector This header allows you to connect printer port on the PC. Pin Assignment Pin Assignment PRD0 ERROR# PRD1 INIT PRD2 SLIN PRD3 Ground PRD4 Ground PRD5 Ground PRD6 Ground PRD7 Ground ACK# Ground BUSY Ground Ground SCLT JDIO1: Digital I/O Connector This connector offers digital I/O functions and address is set in BIOS.
  • Page 19 EIB7B-AXI User’s Manual JP3/ JP4/ JP5/ JP6: Pin 9 Switch Headers for COM5/COM6 Pin 1-2 Short: Pin9 = RING (Default) Pin 3-4 Short: Pin9 = 5V Pin 5-6 Short: Pin9=12V Chapter 2: Hardware installation | 19...
