This equipment has been tested and found to comply with the limits of a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. There is no guarantee that interference
will not occur in a particular installation.
The vendor makes no representations or warranties with respect to the contents here and
specially disclaims any implied warranties of merchantability or fitness for any purpose. Further
the vendor reserves the right to revise this publication and to make changes to the contents here
without obligation to notify any party beforehand.
Duplication of this publication, in part or in whole, is not allowed without first obtaining the
vendor's approval in writing.
The content of this user's manual is subject to be changed without notice and we will not be
responsible for any mistakes found in this user's manual. All the brand and product names are
trademarks of their respective companies.
FCC Information and Copyright
Dichiarazione di conformità sintetica
Ai sensi dell'art. 2 comma 3 del D.M. 275 del
30/10/2002
Si dichiara che questo prodotto è conforme
alle normative vigenti e soddisfa i requisiti
essenziali richiesti dalle direttive
2004/108/CE, 2006/95/CE e 1999/05/CE
quando ad esso applicabili
Short Declaration of conformity
We declare this product is complying with the
laws in force and meeting all the essential
requirements as specified by the directives
2004/108/CE, 2006/95/CE and 1999/05/CE
whenever these laws may be applied
Advertisement
Table of Contents
Related Manuals for Biostar EIH11-SWA
Summary of Contents for Biostar EIH11-SWA
-
Page 1: Fcc Information And Copyright
FCC Information and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 2: Table Of Contents
EIH11-SWA User’s Manual Table Of Contents FCC Information and Copyright ������������������������������������������������������������������������������� 1 Chapter 1: Introduction ������������������������������������������������������������������������������������������� 3 1.1 Before You Start ........................3 1.2 Specifications ........................4 1.3 Rear Panel Connectors ......................5 1.4 Motherboard Layout ......................6 Chapter 2: Hardware installation ����������������������������������������������������������������������������� 7 2.1 Central Processing Unit (CPU) ..................... -
Page 3: Chapter 1: Introduction
EIH11-SWA User’s Manual Chapter 1: Introduction 1�1 Before You Start Thank you for choosing our product. Before you start installing the motherboard, please make sure you follow the instructions below: • Prepare a dry and stable working environment with sufficient lighting. -
Page 4: Specifications
EIH11-SWA User’s Manual 1.2 Specifications Supports Intel® Skylake & Kabylake processor Socket 1151 for Intel® Core i7 / i5 / i3 / Pentium / Celeron processor Maximum CPU TDP (Thermal Design Power): 65 Watt Chipset Intel H110 Chipset Integrated Intel® HD Graphics engine... -
Page 5: Rear Panel Connectors
EIH11-SWA User’s Manual 1�3 Rear Panel Connectors COM1: Serial port Connectors (RS-232/RS422/RS485) RS-232 (Default) RS-422* RS-485* Pin Assignment Carrier detect (DCD) 422 TXD- 485 DATA- Received data (RXD) 422 TXD+ 485 DATA+ Transmitted data (TXD) 422 RXD+ Data terminal ready (DTR) 422 RXD-... -
Page 6: Motherboard Layout
EIH11-SWA User’s Manual 1.4 Motherboard Layout Note » » represents the 1st pin. 6 | Chapter 1: Introduction... -
Page 7: Chapter 2: Hardware Installation
EIH11-SWA User’s Manual Chapter 2: Hardware installation 2.1 Central Processing Unit (CPU) Step 1: Locate the CPU socket on the motherboard Note » » Remove Pin Cap before installation, and make good preservation for future use. When the CPU is removed, cover the Pin Cap on the empty socket to ensure pin legs won’t be damaged. » » The motherboard might equip with two different types of pin cap. Please refer below instruction to remove the pin cap. Step 2: Pull the socket locking lever out from the socket and then raise the lever up. - Page 8 EIH11-SWA User’s Manual Step 4: Hold processor with your thumb and index fingers, oriented as shown. Align the notches with the socket. Lower the processor straight down without tilting or sliding the processor in the socket. Note » » Ensure that you install the correct CPU designed for LGA1151 socket.
-
Page 9: Install A Heatsink
EIH11-SWA User’s Manual 2.2 Install a Heatsink Step 1: Place the CPU fan assembly on top of the installed CPU and make sure that the four fasteners match the motherboard holes. Orient the assembly and make the fan cable is closest to the CPU fan connector. -
Page 10: Connect Cooling Fans
EIH11-SWA User’s Manual 2.3 Connect Cooling Fans These fan headers support cooling-fans built in the computer. The fan cable and connector may be different according to the fan manufacturer. Connect the fan cable to the connector while matching the black wire to pin#1. - Page 11 EIH11-SWA User’s Manual Step 1: Unlock a DIMM slot by pressing the retaining clips outward. Align a DIMM on the slot such that the notch on the DIMM matches the break on the slot. Step 2: Insert the DIMM vertically and firmly into the slot until the retaining clips snap back in place and the DIMM is properly seated.
-
Page 12: Expansion Slots
EIH11-SWA User’s Manual 2.5 Expansion Slots PEX16_1: PCI-Express x16 Slot (x16 speed) • PCI-Express 3.0 compliant. • Theoretical maximum bandwidth using two slots simultaneously is 16GB/s for each slot, a total of 32GB/s. PEX1_1: PCI-Express x1 Slot • PCI-Express 2.0 compliant. -
Page 13: Jumper & Switch Setting
EIH11-SWA User’s Manual 2.6 Jumper & Switch Setting Jumper Setting The illustration shows how to set up jumpers. When the jumper cap is placed on pins, the jumper is “close”, if not, that means the jumper is “open”. Pin opened... -
Page 14: Headers & Connectors
EIH11-SWA User’s Manual 2.7 Headers & Connectors ATXPWR1: ATX Power Source Connector For better compatibility, we recommend to use a standard ATX 24-pin power supply for this connector. Make sure to find the correct orientation before plugging the connector. Assignment Assignment +3.3V... - Page 15 EIH11-SWA User’s Manual JDIO1: Digital I/O Connector This connector offers digital I/O functions and address is set in BIOS. Pin Assignment VCC5 SATA3_1/2/3: Serial ATA 3.0 Gb/s Connectors (1*7 Pin) The connector supports the thin Serial ATA cable for primary internal storage devices.
- Page 16 EIH11-SWA User’s Manual F_USB1: USB 2.0 Header The mainboard provides USB 2.0 pin header. Each header allows you to connect 2 additional USB 2.0 ports. Pin Assignment Pin Assignment +5V(fused) +5V(fused) USB - USB - USB + USB + Ground Ground F_USB2X: USB 2.0 Header...
- Page 17 EIH11-SWA User’s Manual JSEL1(JCOM1A) RS-232 RS-422 RS-485 1-3 (Default) 2-4 (Default) 7-9 (Default) 9-11 9-11 8-10 (Default) 10-12 10-12 JSEL2(JCOM1A) 1-2 (Default) RS-232 RS-422 RS-485 JP1/2: Serial Port Voltage Switch Jumper for JCOM1/2 Pin 1-2 Close: Pin9=Ring(Default) Pin 3-4 Close: 5V...
-
Page 18: Chapter 3: Bios Setup
EIH11-SWA User’s Manual Chapter 3: BIOS Setup Introduction The purpose of this manual is to describe the settings in the AMI UEFI BIOS Setup program on this motherboard. The Setup program allows users to modify the basic system configuration and save these settings to NVRAM. -
Page 19: Main Menu
EIH11-SWA User’s Manual 3�1 Main Menu Once you enter AMI UEFI BIOS Setup Utility, the Main Menu will appear on the screen providing an overview of the basic system information. BIOS Information Shows system information including UEFI BIOS version, model name, marketing name, built date, etc. -
Page 20: Advanced Menu
EIH11-SWA User’s Manual 3.2 Advanced Menu The Advanced Menu allows you to configure the settings of CPU, Super I/O, Power Management, and other system devices. Note » » Beware of that setting inappropriate values in items of this menu may cause system to malfunction. » » The options and default settings might be different by RAM or CPU models. CPU Configuration Intel (VMX) Virtualization Technology This item enables or disables Intel Virtualization Technology. When enabled, a VMM can utilize the additional hardware capabiliteies provided by Vanderpool Technology. - Page 21 EIH11-SWA User’s Manual SATA Configuration SATA Controller(s) This item enables or disables SATA Device. Options: Enabled (Default) / Disabled SATA Mode Selection This item determines how SATA controller(s) operate. This PCH SKU dosen’t support RST feature. Options: AHCI (Default) SMART Self Test This item run SMART Self test on all HDDs during post.
- Page 22 EIH11-SWA User’s Manual Trusted Computing ACPI Settings Enable ACPI Auto Configuration This item enables or disables BIOS ACPI Auto Configuration. Options: Disabled (Default) / Enabled Enable Hibernation This item enables or disables system ability to hibernate (OS/S4 sleep state)/ This option may be not effective with some OS.
- Page 23 EIH11-SWA User’s Manual S3 Video Repost This item enables or disables S3 Video Repost. Options: Disabled (Default) / Enabled EuP Control When EuP is enabled, the system will meet EuP requirement. Options: Disabled (Default) / Enabled Ring-In Wake up from S5 This item enables the system to wake from S5 using Ring-In event.
- Page 24 EIH11-SWA User’s Manual Smart Fan Control CPU Smart Fan1 This item allows you to set CPU Fan control function. Options: Auto (Default) / Disabled CPU Fan1 Calibrate Press [ENTER] to calibrate CPU Fan1 speed. Control Mode This item provides several operation modes of the fan.
- Page 25 EIH11-SWA User’s Manual Super IO Configuration Serial Port 1 Configuration Serial Port This item enables or disables Serial Port (COM). Options: Enabled (Default) / Disabled Change Settings This item selects an optimal setting for Super IO device. Options: Auto (Default) / IO=3F8h; IRQ=4 / IO=3F8h; IRQ= 3,4,5,6,7,9,10,11,12 / IO=2F8h; IRQ= 3,4,5,6,7,9,10,11,12 / IO=3E8h;...
- Page 26 EIH11-SWA User’s Manual Serial Port 2 Configuration Serial Port This item enables or disables Serial Port (COM). Options: Enabled (Default) / Disabled Change Settings This item selects an optimal setting for Super IO device. Options: Auto (Default) / IO=2F8h; IRQ=3 / IO=3F8h; IRQ= 3,4,5,6,7,9,10,11,12 / IO=2F8h; IRQ= 3,4,5,6,7,9,10,11,12 / IO=3E8h;...
- Page 27 EIH11-SWA User’s Manual Change Settings This item selects an optimal setting for Super IO device. Options: Auto (Default) / IO=378h; IRQ=5; DMA=3 / IO=378h; IRQ=5, 6, 7, 9, 10, 11, 12; DMA=1, 3 / IO=278h; IRQ=5, 6, 7, 9, 10, 11, 12; DMA=1, 3 / IO=3BCh; IRQ=5, 6, 7, 9, 10, 11, 12;...
- Page 28 EIH11-SWA User’s Manual Network Stack Configuration Network Stack This item enables or disables UEFI Network stack Options: Enabled (Default) / Disabled IPv4 PXE Support This item enables or disables IPv4 PXE boot support. If disabled IPv4 PXE boot support will not be available.
- Page 29 EIH11-SWA User’s Manual CSM Configuration CSM Support This item enables or disables CSM Support Options: Enabled (Default) / Disabled GateA20 Active Upon Request – FA20 can be disabled using BIOS services. Always – do not allow disabling GA20; this option is useful when any RT code is executed above 1MB...
- Page 30 EIH11-SWA User’s Manual USB Configuration Legacy USB Support This item enables Legacy USB support.AUTO option disables legacy support if no USB devices are connected. Disable option will keep USB devices available only for EFI applications. Options: Auto (Default) / Enabled / Disabled XHCI Hand-Off This is a workaround for OSes without XHCI hand-off support.
- Page 31 EIH11-SWA User’s Manual Device power-up delay in seconds Delay range is 1 ~ 40 seconds, in one second increments. Options: 5 (Default) USB FLASH DRIVE PMAP “Auto” enumerates devices according to their media format. Optical drives are emulated as ‘CDROM’ , drives with no media will be emulated according to a drive type.
-
Page 32: Chipset Menu
EIH11-SWA User’s Manual 3�3 Chipset Menu This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed of the CPU itself uses when communicating with its own special components. - Page 33 EIH11-SWA User’s Manual Graphics Configuration Primary Display This item selects which of IGFX/PEG/PCI Graphics device should be Primary Display or select SG for Switchable Gfx. Options: Auto (Default) / IGFX / PEG / PCI / SG Internal Graphics This item keep IGFX enabled based on the setup options.
- Page 34 EIH11-SWA User’s Manual LCD Control Primary IGFX Boot Display This item allows you to select the video device which will be activated during POST. This has no effect if external graphics present. Secondary boot display selection will appear based on your selection.
- Page 35 EIH11-SWA User’s Manual HD Audio Confuguration HD Audio Control Detection of the HD-Audio device. Disabled = HDA will be unconditionally disabled. Enabled = HDA will be unconditionally enabled. Auto = HDA will be enabled if present, disabled otherwise. Options: Disabled (Default) / Enabled / Auto...
- Page 36 EIH11-SWA User’s Manual Onboard LAN2 This item enables or disables Onboard LAN2. Options: Disabled (Default) / Enabled Note » » The following items appear only when you set the Onboard LAN2 function to [Enabled]. Onboard LAN2 Option ROM This item enables or disables Onboard LAN2 Option ROM. Options: Disabled (Default) / Enabled 36 | Chapter 3: BIOS Setup...
-
Page 37: Security Menu
EIH11-SWA User’s Manual 3.4 Security Menu Administrator Password This item sets Administrator Password. User Password This item sets User Password. Secure Boot Secure Boot Secure Boot can be enabled if 1. System running in user mode with enrolled Platform Key(PK) 2.CSM function is disabled. - Page 38 EIH11-SWA User’s Manual Restore Factory Keys Force System to User Mode. Configure NVRAM to contain OEM-defined factory default Secure Boot keys. Key Management Restore Factory Keys This item Force system to user mode. Configure NVRAM to contain OEM-defined factory default Secure Boot keys.
-
Page 39: Boot Menu
EIH11-SWA User’s Manual 3.5 Boot Menu This menu allows you to setup the system boot options. Setup Prompt Timeout This item sets number of seconds to wait for setup activation key. Options: 5 (Default) Bootup NumLock State This item selects the keyboard NumLock state. - Page 40 EIH11-SWA User’s Manual USB Support If Disabled, all USB devices will NOT be available until after OS boot. If Partial Initial, USB Mass Storage and specific USB port/device will NOT be available before OS boot. If Enabled, all USB devices will be available in OS and Post.
-
Page 41: Save & Exit Menu
EIH11-SWA User’s Manual 3.6 Save & Exit Menu This menu allows you to load the optimal default settings, and save or discard the changes to the BIOS items. Discard Changes and Exit Abandon all changes made during the current session and exit setup.
