Summary of Contents for Werner FireguardPRO 34539000
- Page 1 Loft Ladder 3 Section Fireguard PRO™ Installation Instructions...
-
Page 2: Table Of Contents
CONTENTS Safety & Operation . . . . . . . . . . . . .1 Use . . . . . . . . . . . . . . . . . . . . . . . . .1 Safety Warning . -
Page 3: Safety & Operation
SAFETY & OPERATION IMPORTANT! Please read all these installation instructions before starting to install your loft ladder. If a separate ladder is being used to aid with the Pre-Use and periodic checks: installation of this loft ladder, then the ladder should be •... -
Page 4: Installation Requirements
INSTALLATION REQUIREMENTS Two persons are required to install this product . Tools Required: Additional Components Required: To temporarily support the ladder during installation, we recommend the use of two suitable timber batterns or planks . Each supporting batten or plank should be able to be fitted securely across the full width of the loft opening and capable of supporting the full weight of the assembled ladder . -
Page 5: Product Contents
PRODUCT CONTENTS Three Section Ladder, Loft Casing and Door Architrave Strips x4 Support Arm Bracket Screws x4 Springs x2 Chain Linkages x2 Spring Hooks x2 Ø6 x 40mm Torx 30 Pole Hook Screw x1 Feet Screws x2 Door Lock Set Screws x3 Pole Hook x 1 Ø4 x 25 Door Lock Set x 1... -
Page 6: Pre-Installation
PRE-INSTALLATION Hatch Opening Adjustments (if required) Minimum / recommended hatch opening size: 1.15 x 0.57 (m) We recommend that you wear goggles, gloves and a mask for protection from falling dust and other particles from the loft. Remove all items of furniture from the work area. -
Page 7: Installation
INSTALLATION To ensure that the product is assembled and fitted correctly, these instructions should be followed carefully. If you have any difficulties, contact an expert for installation advice. WARNING: DO NOT DISMANTLE the loft ladder once it has been assembled. NB! For models in which the ladder is fixed to the trapdoor. - Page 8 INSTALLATION Attaching the Loft Ladder Using a separate ladder, one fitter goes up into the loft, taking all the tools they need. The other fitter remains below. Lift the loft ladder up into the loft. Before lowering the loft ladder into the opening from above, attach two supporting planks under the ceiling opening.
- Page 9 INSTALLATION During step 1 the wood screws must be fitted manually using a screwdriver – DO NOT use power tools. STEP 1 STEP 2 DO NOT overtighten the wood fixing screws. Overtightening of the wood fixing screws may cause them to become loose resulting in the detachment of the parts and cause a serious injury.
- Page 10 INSTALLATION During step 3b the wood screws must be fitted manually using a screwdriver – DO NOT use power tools. STEP 3a STEP 3b...
- Page 11 INSTALLATION STEP 4 It is strongly recommended that ROCKWOOL Insulation is used in the space between the loft ladder casing and ceiling joists, due to its fire-resistant properties. You must fill the entire space from top to bottom with this material, leaving no gaps. STEP 5...
- Page 12 INSTALLATION STEP 6 DO NOT adjust the L Support Bracket Screws that attach into the hatch door. They are factory fitted and set to the correct torque. STEP 7 STEP 8 DO NOT use the loft ladder if all sections of the ladder are not aligned.
- Page 13 INSTALLATION During step 9, 10 and 11 the wood screws must be fitted manually using a screwdriver – DO NOT use power tools. STEP 9 STEP 10 STEP 11 DO NOT overtighten the wood fixing screws. Overtightening of the wood fixing screws may cause them to become loose resulting in the detachment of the parts and cause a serious injury.
- Page 14 INSTALLATION STEP 12 Fireguard PRO™ THE INSTALLATION OF YOUR WERNER IS NOW COMPLETE.
-
Page 15: Care & Maintenance
Material - means a material or component used by Guarantee includes faults arising from defects in workmanship or materials except for - Werner UK Sales & Distribution Ltd. in the manufacture of the product. • Ordinary wear and tear of the product. - Page 16 Werner UK Sales & Distribution Ltd. Blackwater Trading Estate, The Causeway, Maldon, Essex, CM9 4LJ WernerCo Hungary. Kft. 6000 Kecskemét, Szt. Istvan Krt. 19 Hungary +44 (0)1621 745900 uk.customercare@wernerco.com wernerco.co.uk PN130028-01 R1-91120 0224 ©WernerCo Rev. A...
