Summary of Contents for SULO ORWAK 3115
- Page 1 Edition 4.6, From serial no. 150252- Publ. no 4870132-00 OM 3115, 2023-02 ORWAK 3115 ORIGINALNA NAVODILA ZA UPORABO ORIGINAL OPERATING INSTRUCTIONS...
-
Page 3: Table Of Contents
Slovenščina English VSEBINA CONTENTS Varnostne informacije.. Safety information..Deli stroja....Parts of the machine..Varnost......Safety......Kontrolna plošča..Control panel ....Navodila za Operating instruction..upravljanje....Installation ....Vgradnja..... Weekly inspection and Tedenski pregled in maintenance ....vzdrževanje....Technical specification.. Tehnične specifikacije.. - Page 4 Slovenščina OPOZORILA IN DOLŽNOSTI UPRAVLJAVCA Ta priročnik mora biti vedno na voljo v bližini stiskalnice. Vsak upravljavec mora v celoti prebrati in upoštevati vsa navodila v tem priročniku, preden dobi dovoljenje za uporabo naprave. Vsi upravljavci morajo nujno preučiti in v celoti razumeti uporabniški priročnik, pri čemer morajo biti še posebej pozorni na razdelek z varnostnimi postopki.
-
Page 5: Deli Stroja
Slovenščina DELI STROJA Držalo za trak Zaustavljanje v nujnem primeru Nadzorna plošča Plošča za prešo Zgornja vrata Vrata Preklopni pokrov za vrata Hidravlična enota Držalo za trak... -
Page 6: Varnost
Slovenščina VARNOST Prosimo, da pred začetkom uporabe stroja preberete navodila za upravljanje. Za uveljavljanje garancije za izdelek je potrebno naslednje: • da upoštevate navodila in da ne izvajate nikakršnih predelav ali sprememb. • da uporabljate originalne rezervne dele in hidravlična olja in maziva, ki jih priporoča proizvajalec stroja. - Page 7 Slovenščina PODROČJE UPORABE Ta stroj je hidravlična stiskalnica za stiskanje materiala, kot je karton, papir in prožna plastika. Stroj lahko uporabljate samo v prostorih, ki so pokriti streho, so zaščiteni pred vetrom in imajo normalno osvetlitev. Stroj je namenjen uporabi znotraj temperaturnega razpona -10 do +40 °C. Pri temperaturah pod +5 °C morate uporabljati olje za nizke temperature in/ali grelnik.
- Page 8 Slovenščina NAVODILA ZA UPORABO Paper Paper 4872303-00 (VG9) 4865268-00 (LW) OPOZORILO! V delovnem območju stroja se lahko zadr- žuje samo upravljavec! Plastic Plastic 4872248-00 (VG13) 4865269-00 (MW) Namestitev trakov 1 Zaslonke trakov in zgornja vratca do konca odprite. Valje trakov postavite v predal za trak in trakove vstavite v usmernike trakov.
-
Page 9: Tedenski Pregled In Vzdrževanje
Slovenščina NAMESTITEV Svetsaregatan 4 576 33 Sävsjö Sweden Type Date Product No Weight Serial No Temperature range of use (standard oil): +5°C to +40°C +40 °C Temperature range of use (special oil): -10°C to +40°C +5 °C -10 °C ** MAKS. -
Page 10: Transport
Slovenščina TEHNIČNE SHEMA DIMENZIJ SPECIFIKACIJE (490 3115-00) SPLOŠNI PODATKI Skupna teža: 380 kg Transportna višina: 1.990 mm Mere: Višina: 1.990 mm Širina: 940 mm Globina: 790 mm Globina z odprtimi vratci: 1.535 mm Priporočen prostor za delujoč stroj (delovno območje): Višina: 2.000 mm Širina:... - Page 11 Slovenščina IZJAVA O SKLADNOSTI ES Družba Orwak AB Svetsaregatan 4 S-576 33 Sävsjö, Sweden Švedska Tel: 46-382-15700 pod lastno odgovornostjo izjavlja, da je model izdelka, 4903115-00 – 4903115-99 4903115-S001 – 4903115-S999 na katerega se nanaša ta izjava, skladen z naslednjimi standardi ali drugimi normativi glede na določbe direktive 2006/42/EGS (Direktiva o strojih) 2014/30/EU (Direktiva o elektromagnetni združljivosti)
-
Page 12: Safety
English OPERATOR WARNING & DUTY This manual must be available permanently near the baler. Each operator must read and follow the full instruction of this manual before being authorize. All operator must absolutely study and fully understand the operator’s manual, specifically pay a particular attention to the safety procedure section. -
Page 13: Control Panel
English Strap holders Emergency stop Control panel Press plate Shutter Strap slots Door Door flap Hydraulic unit Strap guide... - Page 14 English SAFETY Please read the operating instructions BEFORE operating the machine. Our warranty/product responsibility requires that: instructions are followed, and that no conversion or modification is carried • out. • original spare parts, and hydraulic oils and lubricants recommended by the machine manufacturer are used.
- Page 15 English RANGE OF APPLICATION The machine is a hydraulically operated baler intended for compacting bulky materials such as cardboard, paper and plastic. The machine may only be used in areas that have a roof, protection against wind, and normal lighting. The machine is intended for use within the temperature range -10°C to +40°C.
-
Page 16: Operating Instruction
English OPERATING INSTRUCTIONS Paper Paper 4872303-00 (VG9) 4865268-00 (LW) WARNING! Only the operator is allowed in the working area of the machine! Plastic Plastic 4872248-00 (VG13) 4865269-00 (MW) Mounting the straps 1 Open the strap shutters and the upper door all the way. Place the strap rolls in the strap holder compartment and insert the straps into the strap funnels. -
Page 17: Installation
English INSTALLATION Svetsaregatan 4 576 33 Sävsjö Sweden Type Date Product No Weight Serial No Temperature range of use (standard oil): +5°C to +40°C +40 °C Temperature range of use (special oil): -10°C to +40°C +5 °C -10 °C ** Oil- level 4-6 mm... -
Page 18: Technical Specification
English TECHNICAL DIMENSIONAL DIAGRAM SPECIFICATIONS (490 3115-00) GENERAL DATA Total weight: 380 kg Transport height: 1,990 mm Dimensions: Height: 1,990 mm Width: 940 mm Depth: 790 mm Depth with open door: 1,535 mm Recommended space for machine in operation (working area): Height: 2,000 mm Width:... - Page 19 English EC DECLARATION OF CONFORMITY Orwak AB Svetsaregatan 4 S-576 33 Sävsjö, Sweden Sweden Tel: 46-382-15700 declare under our sole responsibility that the product model 4903115-00 – 4903115-99 4903115-S001 – 4903115-S999 to which this declaration relates is in conformity with the following standards or other normative documents in accordance with the provisions of Directives 2006/42/EEC (Machinery Directive) 2014/30/EU (EMC Directive)
- Page 20 4876345-50 idravlična sHema ydraulic diagram Ø2 0,1-10,1V 90-250 bar 2.5 cc 1.6 cc Description Item Svenska English Deutsch Français Español 1 Elmotor Electrical motor Elektrischer Motor Moteur électrique Motor eléctrico 2 Dubbelpump Double pump Doppelpumpe Double pompe Doble bomba 3 Sugfilter Suction filter Saugsieb Filtre...
- Page 21 lektrična sHema lectrical diagram...
- Page 22 lektrična sHema lectrical diagram...
- Page 24 COMPACTION SOLUTIONS FOR MOST TYPES OF WASTE ORWAK develops solutions for sorting and recycling waste ORWAK develops solutions for sorting and recycling waste materials that improve business efficiency, contribute to a materials that improve business efficiency, contribute to a cleaner working and natural environment to provide the best cleaner working and natural environment to provide the best total waste handling economy.
