Summary of Contents for Ropox FlexiElectric 30-66 2 Series
- Page 1 QR code to mounting video FlexiElectric 30-66XXX-2 User Manual Mounting Instructions Keep this folder with product at all times! TF 200.0066_uk / Rev 006 / 08-02-2024...
-
Page 2: Table Of Contents
Mounting of distance plates for skirting board ................... 18 Mounting the flexible water connections and waste hoses ................18 Mounting the support arms 30-67642/30-67643 ..................19 Mounting the Bluetooth Adapter for Ropox Connect App ................19 Downloading the Ropox Connect App ......................20 PERFORMANCE TEST ............................ 20 LIST OF COMPONENTS .......................... -
Page 3: Introduction
Introduction You have chosen Flexi, the multi-flexible, height-adjustable, easy-to-mount frame. The frame may be used separately or in combination with Diagonal or Verti, the adjustable system for wall cupboards. The frame has no inconvenient fascia and, consequently, the adjustment of the working height from 65 to 95 cm + worktop thickness may be fully utilised. -
Page 4: Technical Data Flexi
Max. 10 % conform to 2 min. active / 18 min. pause Speed: Approx. 32 Lifting time stroke 30 cm: Approx. 10 sec. Temperature: 5-45°C Air humidity: 5-85% (non-condensing) Complaints: See section, complaints Manufacturer: Ropox A/S, DK-4700 Naestved, Phone.: +45 55 75 05 00 TF 200.0066_uk / Rev 06 Page 4... -
Page 5: Installation Information
Installation information Minimum area for reinforcement of wall. Wall material must be suitable for screw mounting. Area for electric and plumbing installations. Max. load 150 kg / 330 lb evenly distributed over the worktop up to 300 cm / 118.1 inches in width, according to DS/EN 12182. - Page 6 Power 50-70cm/19.7-27.5in 50-70cm/19.7-27.5in It is advisable to place water supply and waste within the hatched area. Also, it is important to use flexible hoses for water supply and waste to ensure that the Flexi will move freely without obstacles within the height adjustment range 65-95 cm / 25.6-37.4 in excl. worktop. It is advisable to place the water supply and waste close to the sink.
- Page 7 Warning! When mounting a hob in the tabletop, remain aware of the dangers hereby: Gas hob – Always be aware of the movement of the table together with the gas hoses. If these are obstructed during the movement, this can lead to gas leakage, which can be deadly! Induction hob –...
-
Page 8: Flexi Electric Quickstart Guide
Strip / Smartbox2 should be used for each frame. Recommendations: ➢ Ropox recommendation is to always make use of fascias on all 3 sides Start-up: ➢ The frame must move freely and unimpeded throughout height adjustment. Check all connections of flexible hoses, cables etc. to make sure none of these parts or other items are trapped when frame is operated Troubleshooting: - No movement –... -
Page 9: Mounting Instructions
Mounting instructions The equipment should always be assembled by competent personnel Prior to assembly check that all parts have been provided. See list of components, from page 21. If supporting feet have been ordered, follow assembly of these under paragraph for mounting of accessories first. - Page 10 7.1.5 All support arms, but 2, may be pushed into the aluminium profile from 7.1.6 The left hand side support arm may the right hand side to the required be pushed into the profile, positioned position and fastened with two screws direct on top of the left leg, and on each support.
-
Page 11: Mounting The Frame On The Wall
7.1.11 Move the stop rings on the spindle to both sides, so that the stop ring always faces the leg. Secure it by fastening the screw in the stop rings. Where you have an adjustable leg always position a support arm directly over it. Do not adjust the tilting of the arm supports that are positioned on top of the legs (see 7.5). -
Page 12: Mounting Of Fittings For Front Fascia
Mounting of fittings for front fascia 7.3.1 Fittings for mounting of the wooden 7.3.2 On the outermost support arms we front fascia are provided, recommend pointing the front corresponding to the number of fascia fittings towards the middle of support arms. Place the front fascia the frame to prevent them from fittings on the side of the support arm conflicting with the side fascia. -
Page 13: Adjusting The Worktop/Support Arms
Adjusting the worktop/support arms 7.5.2 By means of the two lower screws of each support arm the ”tilting” may be adjusted. Start by loosening the two screws 7.5.1 After placing the worktop on the fastening the support arm to the frame you may have to compensate aluminium profile and adjust the two for the weight of the worktop if the... -
Page 14: Mounting The Side Fascia
Mounting the side fascia 7.7.2 It’s recommended to mount 7.7.1 Furniture fittings are provided with the frame to keep the side fascia flush with the wooden side fascia up against worktop to avoid entrapment. the worktop. Mounting the control unit Warning ALWAYS switch off mains voltage during assembly Check national regulations to determine the correct location of the control unit. -
Page 15: Mounting The Operating Unit
Connections to Control box Power Cable Adapter cable Safety strip (option) Split cable for safety strip Cable for control 7.8.2 Mount all cable connections as illustrated. Note that the safety strip is mounted in S2. For connection sequence see start-up procedure on page 20. Mounting the operating unit 7.9.1 The control switch for the height adjustment must be fitted in the wooden front fascia. -
Page 16: Mounting Of Distance Plates
7.10 Mounting of distance plates 7.11 Mounting of covers 7.10.1 In case of skirting boards, you can use the 1 cm / 0.4 in deep distance plate to pack the frame out from the 7.11.1 Place the 2 endcaps on wall istance between backside of standard cover and push... -
Page 17: Mounting Of Accessories
Mounting of accessories Mounting the supporting feet 8.1.2 Fit the foot and the extension to the leg with the screws provided and 8.1.1 Remove the adjusting screw tighten the screws. from the leg. Mounting the covers for the legs 8.2.2 Lift up the upper/outside cover and press the snap lock into the hole of the leg. -
Page 18: Mounting Of Distance Plates For Skirting Board
Mounting of distance plates for skirting board 8.3.3 After fitting the press pad, fasten 8.4.1 In case of skirting boards, you the cable under the worktop with can use the 1 cm / 0.4 in cable bearers so that it does not deep distance plate to pack sag. -
Page 19: Mounting The Support Arms 30-67642/30-67643
4.5 cm 4.5 cm 1.8 in 1.8 in Mounting the Bluetooth Adapter for Ropox Connect App 8.7.2 Insert the split-cable in the plug ”HS” 8.7.1 Determine the placement of the adapter, then grab the Bluetooth in the control box. Then, insert the... -
Page 20: Downloading The Ropox Connect App
Downloading the Ropox Connect App As an option to operate certain Ropox products, it’s possible to download the free Ropox Connect App, which makes it possible to operate the product wirelessly. The Ropox Connect App allows you to operate the product upwards or downwards and has the option of saving height settings, allowing users to easily change from a standing height to a sitting height. -
Page 21: List Of Components
List of components Legs, Electric standard height 65-95 cm/25.6-37.4in. 30-67607: Length of worktop = 60-204 cm / 23.6-80.3 in 2 legs Length of worktop = 205-300 cm / 80.7-118.1 in 3 legs The legs comprise: 30-67681 Spacers (0.15 cm / 0.06 in) 3 pcs./leg For misalignment 30-67680 Distance plates (1 cm / 0.4 in) - Page 22 230 V Control box, fast (26.5x10.5x3.7 cm / 10.4x4.1x1.4 in): Control box for 1 motor : 30-67859 1 pc. Worktop length = 60-104 cm / 23.6-40.9 in Control box for 2 motors: 30-67877 Worktop length = 105-300cm / 41.3-118.1 in incl.
-
Page 23: Options For Flexi
Options for Flexi Support arm for worktop depth 68-72 cm / 26.7-28.3 in 30-67621: Length of worktop = 60-104 cm / 23.6-40.9 in 2 pcs. Length of worktop = 105-204 cm / 41.3-80.3 in 4 pcs. Length of worktop = 205-254 cm / 80.7-100 in 5 pcs. - Page 24 1 pc. British standard 3-pin plug 30-67879: with 200 cm / 78.7 in cable 1 pc. Bluetooth Adapter for Ropox Connect App 30-90591: Option, if the product needs to be remotely controlled via 1 pc. the Ropox Connect App TF 200.0066_uk / Rev 06...
- Page 25 If the Flexi frame has not been installed in accordance with these mounting instructions, the guarantee may become void. ➢ Only use Ropox original spare parts as replacement parts. If other spare parts are used, the guarantee may become void. TF 200.0066_uk / Rev 06...
-
Page 26: Cleaning And Maintenance
Check that all cables have been fitted correctly and are undamaged. After each inspection the service schedule shall be filled in. See item 13.4. Only use Ropox original spare parts as replacement parts. If other parts are used, the guarantee may become void. -
Page 27: Service Schedule, Operation And Maintenance
The user manual must be read before use Waste must be sorted – if possible, for recycling Ropox is the manufacturer of the product in question CE marking. This product meets the requirements for General Safety and Functionality of the current EU Directives and Standards UKCA marking. -
Page 28: Troubleshooting
Connect motor cable/cables − Move frame to Lowest/bottom position for “reset” Complaints We refer to our general Terms of sale and delivery on our homepage www.ropox.com. ROPOX A/S Ringstedgade 221 DK – 4700 Naestved Tel.: +45 55 75 05 00 E-mail: info@ropox.dk...
