Nora Lighting NEX-712-LED Installation Instructions

Installation Instructions
NEX-712-LED
LED Exit & Emergency Combo with Remote Capability and Self-Diagnostics
WARNING - This equipment is intended to be installed only by qualified personnel. The installation must
be made in accordance with the current edition to the National Electric Code and all applicable state and
local building codes. The final installation must be approved by the appropriate qualified electrical/building
inspector(s). Improper installation may result in a fire or electrical hazard. Be sure the electrical power to the
circuit has been disconnected before installing this electrical system.
1. Review the diagrams thoroughly before beginning.
2. All electrical connetions must be in accordance with local codes, ordinances, and the National Electric code.
3. Disconnect power at fuse or circuit breaker before installing or servicing.
4. Do not use outdoors.
5. Do not mount in hazardous locations, or near gas or electric heaters.
6. Do not let power cords touch hot surface.
7. Equipment should be mounted in locations and at heights where it will not be subjected to tampering and by unauthorized personnel.
8. The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
9. Do not use this equipment for other than intended use.
10. All servicing should be performed by a qualified personnel only.
11. Allow battery to charge for 24 hours before full duration test.
12. Maximum mounting height is 17'-6".
MAINTENANCE
Always disconnect power at fuse or circuit breaker before installing or servicing, servicing should be performed only by qualified personnel.
BATTERY: Should be tested periodically and replaced when it no longer meets the required duration of 30 seconds or 90 minutes. Battery needs to be recharged if product is kept in stock over 9 months.
OPERATION
1. Apply AC power to the unit, the indicator should show red.
2. Push the test switch, the LED indicator turns off and the LED board stays on.
3. After releasing the test switch, LED indicator turns back to red.
ROUTINE TESTING
National Electric Code (NEC) and NFPA life safety code regulations require that routine tests need to be performed as below:
Once every month, perform 30 seconds duration test, push in and hold the test switch to perform a full 90-minute test.
Disconnect AC power supply and switch to emergency mode, the unit should stay on 90 minutes minimum.
Page 1 of 3
6505 Gayhart Street, Commerce, CA 90040
Tel 323.767.2600 | www.noralighting.com | e-mail: nora@noralighting.com
© 2024 Nora Lighting, Inc. All rights reserved. Instructions subject to change without notice.
IMPORTANT SAFEGUARDS
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
READ PRIOR TO ATTEMPTING INSTALLATION
ALWAYS TURN OFF MAIN POWER BEFORE INSTALLATION
INSTALLATION SHOULD BE CARRIED OUT BY YOUR LOCAL ELECTRICIAN
AVERTISSEMENT - Cet équipement est destiné à être installé uniquement par du personnel qualifié.
L'installation doit être faite en conformité avec l'édition actuelle du Code national de l'électricité et toutes
étatiques et locales codes du bâtiment applicables. L'installation finale doit être approuvée par l' inspecteur
en électricité / bâtiment qualifié approprié(s). Une mauvaise installation peut entraîner un incendie ou un
risque électrique. Soyez sûr de la puissance électrique vers le circuit a été coupée avant l'installation de ce
système électrique.
TROUBLESHOOTING GUIDE
If LED heads or LED indicator do not illuminate, check the following:
1. Check AC supply - verify that unit has 24 hours of AC voltage.
2. Unit is shorted or battery is not connected.
3. Battery voltage too low. Allow luminaire to recharge for 24 hours and then re-test.
4. If above troubleshooting do not solve your problem, contact factory for assistance.
013124P1
IS-NEX-712-LED-R02
