Installation Instructions

NUTP51 / NUTP81 / NUTP71
Continuous Tape
Item no.
NUTP51-W100LED927
NUTP51-W100LED930
NUTP51-W100LED942
NUTP81-W100LED930
NUTP81-W100LED942
NUTP71-W100LED927L
NUTP71-W100LED930L
NUTP71-W100LED942L
IMPORTANT: Please read before installation
• Always turn off power prior to installation or replacement.
• Continuous Tape Light contacts are very fragile, handle with care.
• Do not turn on Tape Light while on the spool, may cause the tape light to overheat and melt or ignite.
• Do not press directly on the LEDs themselves, as it may cause damage.
• Do not use the product in a potentially combustive environments.
• Do not cover this product as the covering may cause the tape light to overheat and melt or ignite.
• Do not operate with the tape light tightly coiled.
• Do not route the cord or tape light through walls, doors, windows or any like part of the building structure.
• Do not use if there is any damage to the light or cord insulation. Inspect periodically.
• Continuous Tape Series is cULus Listed for Damp Location.
• Secure the tape light using only the 3M™ tape, hangers, clips, or NATHR-680 Aluminum Channel (sold separately). Do not secure this
product or its cord with staples, nails, or like means that may damage the insulation or permanently attach to the building structure.
• Wire leads and accessories are not rated for in-wall installation unless otherwise noted.
• Attached wire leads and connections are field-cuttable.
• Tape light, attached wire leads, and additional extension cables, connectors, etc., are not rated for in-wall installation unless otherwise noted.
• Do not install in environment where LED chips are exposed to direct sunlight as damage to the phosphor will occur.
• Do not install in environment where excessive heat may exist (ex. close proximity to the fireplace, etc.)
• See operating temperature on spec sheet.
InstallatIon InstructIons:
1. Decide where you want to place the LED tape light.
2. The tape light has a 3M™ self-adhesive backing, ensure the surface area that you intend to adhere the tape light to is clean and dry. Simply remove the backing strip and carefully lay the tape
light in place working from one end to the other ensuring there are no raised sections.
3. Using a lint-free cloth gently press between the LEDs on the tape to remove any air bubbles and activate the adhesive, make sure you do not press on the LEDs themselves as this could dam-
age the joint.
WIrIng InstructIons to DrIver:
1. Only use with Class 2 24V power supply.
2. Driver may have a male plug and the LED Tape Light may have a the female connector. Plug male connector into female connector together. Some drivers will require connecting + and - wire
together.
PolarIty: Continuous Tape has + and - markings. These must be connected to + and - of the driver leads or another tape lead.
6505 Gayhart Street, Commerce, CA 90040
Tel 323.767.2600 | www.noralighting.com | e-mail: nora@noralighting.com
© 2019 Nora Lighting, Inc. All rights reserved. Instructions subject to change without notice.
DescrIPtIon
Hybrite Continuous Tape, 100' (32' Max Run), 27K
Hybrite Continuous Tape, 100' (32' Max Run), 30K
Hybrite Continuous Tape, 100' (32' Max Run), 42K
High-Output Continuous Tape, 100' (20' Max Run), 30K
High-Output Continuous Tape 100' (20' Max Run), 42K
Standard Continuous Tape 100' (64' Max Run), 27K
Standard Continuous Tape 100' (64' Max Run), 30K
Standard Continuous Tape 100' (64' Max Run), 42K
READ PRIOR TO ATTEMPTING INSTALLATION
ALWAYS TURN OFF MAIN POWER BEFORE INSTALLATION
INSTALLATION SHOULD BE CARRIED OUT BY YOUR LOCAL ELECTRICIAN
043019P1
IS-NUTP51_NUTP81_NUTP71R01
