https://wiki.teltonika-networks.com/view/QSG_RUT301
QSG RUT301
Main Page
>
RUT Routers
This Wiki page contains the online version of the Quick Start Guide (QSG) for the RUT301
Ethernet Router. Here you will find an overview of the various components on the front and back
of a RUT301 device, hardware installation instructions, first login information, device specifications,
and general safety information. It is highly recommended to acquaint yourself with the Quick Start
Guide before using the device. You can also locate a printed version of the Quick Start Guide in the
packaging box of your device.
Contents
•
1 Safety information
-
1.1 General
-
-
-
-
•
•
•
•
•
•
•
Safety information
Before starting operating the device, please review recommendations and precautions to minimize
the possibility of accidents. Safety precautions presented are supplementary and subject to the local
safety regulations. When various operations are executed on the device, the user must fully follow
the safety instructions and recommendations provided with the device.
General
Input voltage range
Max power consumption 3.8 W
Power adapter
* Order code dependant.
>
RUT301
> QSG RUT301
Technical specifications
9-30 VDC
Bundled accessories specifications*
Input: 0.45A@100-240 VAC, Output: 9 VDC, 1A, 4-pin plug

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RUT301 and is the answer not in the manual?

Questions and answers

Related Manuals for Teltonika RUT301

Summary of Contents for Teltonika RUT301

  • Page 1: Table Of Contents

    RUT301 > QSG RUT301 This Wiki page contains the online version of the Quick Start Guide (QSG) for the RUT301 Ethernet Router. Here you will find an overview of the various components on the front and back of a RUT301 device, hardware installation instructions, first login information, device specifications, and general safety information.
  • Page 2 RUT301 ethernet router must be used in compliance with any and all applicable national and international laws and with any special restrictions regulating the utilization of the communication module in prescribed applications and environments. CE Declaration of Conformity С настоящото TELTONIKA NETWORKS декларира, че този RUT301 е в...
  • Page 3 TELTONIKA NETWORKS b'dan tiddikjara li dan RUT301 jikkonforma mar- [MT] Maltese rekwiżiti essenzjali u dispożizzjonijiet oħra tad-Direttivi 2014/30/EU, 2014/35/EU, 2011/65/ЕU, 2009/125/EC TELTONIKA NETWORKS erklærer herved at denne RUT301 er i samsvar med de [NO] grunnleggende kravene og andre bestemmelser i Direktivene 2014/30/EU, Norwegian 2014/35/EU, 2011/65/ЕU, 2009/125/EC...
  • Page 4 This sign on the package means that all used electronic and electric equipment should not be mixed with general household waste. Hereby, TELTONIKA NETWORKS declares that this RUT301 is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://wiki.teltonika-networks.com/view/RUT301_CE/RED.

  • Page 5: Operating Conditions

    Operating conditions Operating temperature: -40° to +75° Celsius Humidity should be in the range of 10% to 90% (non-condensing). Only use the device in dry environments. Out of direct sunlight Away from heat source, corrosive substances, salts, and flammable gases Attention: operation outside the permissible range can considerably shorten the service life of the device.

  • Page 6: Front View

    POWER SOCKET PINOUT Video Quick Start Guide Need some help setting up your new Teltonika Networks RUT301 industrial ethernet router? Watch our quick start guide video and follow the step by step instructions to easily set up your new router...

  • Page 7: Hardware Installation

    Hardware installation Configure your computer LAN (Windows) 1. Ensure the Network connection is Enabled. Go to Start — Control Panel — Network and Internet — Network and Sharing Center. Click on the Change adapter settings in the left panel, then right-click on Network Adapter, and...

  • Page 8: Login To Device

    Login to device 1. To enter the router's Web interface (WebUI), type http://192.168.1.1 into the URL field of your Internet browser. 2. When prompted for authentication enter the username admin and enter the password located on the device information label/engraving.
  • Page 9 3. After logging in, you must set a new password for security reasons. You will not be able to interact with the router’s WebUI until the default password is changed. The new password must consist of a minimum of 8 characters.
