For product warranty registration, TOTO U.S.A. Inc. recommends online warranty registration.
Please visit our web site http://www.totousa.com. If you have questions regarding warranty policy or
coverage, please contact TOTO U.S.A. Inc.,
Customer Service Department, 1155 Southern Road, Morrow, GA 30260 (678) 466-1300 or (888) 295-8134
when calling from outside of U.S.A.
You are advised to record the following information to allow quick service.
Date of Purchase:
Name of Store:
Phone: (
)
0IM147501
Auto Flush Urinal
UE906 Series
2024.4
Instruction and Owner's Manual
Safety Precautions
Names of Parts
Mechanism of Operation
Maintenance
Periodic Inspection
Backup Battery Replacement
Troubleshooting
After Sales Service
Specifications
View Video
Installation and Adjusting the Urinal
https://vimeo.com/850235113?share
* Communication fees may apply.
* May not be available for some usage environments.
Please keep the installation and owner's manual for later use
. . .
P.2
. . .
P.6
. . .
P.7
. . .
P.8
. . .
P.13
. . .
P.14
. . .
P.18
. . .
P.30
. . .
P.31
Advertisement
Table of Contents
Related Manuals for Toto UE906 Series
Summary of Contents for Toto UE906 Series
- Page 1 Instruction and Owner's Manual Auto Flush Urinal UE906 Series For product warranty registration, TOTO U.S.A. Inc. recommends online warranty registration. Please visit our web site http://www.totousa.com. If you have questions regarding warranty policy or coverage, please contact TOTO U.S.A. Inc., Customer Service Department, 1155 Southern Road, Morrow, GA 30260 (678) 466-1300 or (888) 295-8134 when calling from outside of U.S.A.
-
Page 2: Safety Precautions
Safety Precautions WARNING Always observe these warnings Do not disassemble or modify the product Before use, read these "Safety Precautions" carefully to ensure proper use of the product. except as specified in this manual Doing so may cause problems such as water ·... - Page 3 CAUTION CAUTION Do not subject the urinal to strong force Make sure to wipe any urine, condensation, or impacts detergent, water, or other liquid that gets on the floor, clean with a well-wrung cloth Doing so may damage the urinal, which could result in injury or damage to property such as Leaving it on the floor may cause stains or household belongings caused by water leaks.
-
Page 4: Names Of Parts
Names of Parts Mechanism of Operation Wall mounted urinal The automatic flush operation of this product is described below. Detection Full flush Upper lid Backup battery A person approaching the urinal is Urinal is fully flushed after the detected by the sensor. person moves away from the urinal. -
Page 5: Maintenance
Prohibited Daily cleaning Clean with a cleaning sponge or brush. About CeFiONtect CeFiONtect is TOTO independently developed technology where bumps on the porcelain surface are smoothed, making dirt difficult to adhere and easy to remove. Components of detergent About surface coating agents or coating agent cover the CeFiONtect surface. - Page 6 Maintenance of the Urinal Maintenance of the Spreader (Main Unit) For light stains For light stains Wash the urinal with water, using a cleaning Wipe away the stains with a soft cloth that has been brush or sponge. soaked in cold or warm water and wrung out thoroughly. Spreader For heavy stains or scale For heavy stains...
-
Page 7: Periodic Inspection
Periodic Inspection Maintenance of the Drain Strainer Deterioration that occurs due to extended use of the product may cause safety problems. In order to prevent serious accidents due to deterioration over time and ensure that the When removing the drain strainer for cleaning, wear rubber product can be used longer, safely, and comfortably, perform the gloves. -
Page 8: Backup Battery Replacement
Because the flushing function will stop as soon as the Replacing the Backflow Prevention Mechanism photoelectric sensor starts flashing in 4-second cycle, refer to the following instructions to replace the backup battery. Make sure to replace the backflow prevention mechanism every six years. Failure to do so may cause water to flow backward into the water supply line and adversely affect people. - Page 9 Plugging/Unplugging the Connector New backup battery Controller Ask a contractor when replacing the backup battery. Backup battery Lock Plug the connector in until it locks. Push When unplugging the connector, Connector push the lock and pull the connector CAUTION Do not plug or unplug the out.
-
Page 10: Troubleshooting
Troubleshooting If a malfunction is suspected, first check to see if the water supply Symptom Situation Remedy Reference has been cut off. If there is no problem with the water supply, remove the upper lid and inspect the items indicated below. For Replace the backup battery. - Page 11 Removing/Installing the Upper Lid Installing the Upper Lid Temporarily fasten the fastening fixture. CAUTION Tool Used * Approximately 5 mm (3/16") adjustment of the fastening fixture can be Do not tighten the decorative bolt too performed on either the left or right side. strongly However, make sure to perform the rest of the procedure on the same side.
- Page 12 Install the upper lid to the urinal. Install the left side of the upper lid to the urinal. (1) Move the upper lid to the right until it is in Install a position where it will not interfere with Install the fastening fixture.
- Page 13 Water does not come out Installation Complete If the detection LED is flashing or you are not sure if it was flashing Check the connection of Backup battery the backup battery connector. Confirm that the fastening fixture is inside the long hole of the upper lid. Connector Open Closed...
- Page 14 Close the shutoff valve or master valve before performing the procedure. Flushed water is insufficient Water filter CAUTION If flushed water is insufficient, adjust the shutoff valve. Crescent wrench A lack of flushed water may reduce the flushing ability of the product and Spindle guide adversely affect the cleanliness.
- Page 15 The Detection LED Is Lit or Flashes Replacement Parts Backup battery Part Name Drain strainer <When the product is being used> <When the backup battery expires> (dry cell) · Detection LED flashes every four · Detection LED is not lit seconds Appearance <When power is turned ON (for 10...
-
Page 16: After Sales Service
Before requesting a repair, see "Troubleshooting" on P. 18! Wall mounted Part Replacement Type Self-generating · Parts and products removed during a free repair are the property of TOTO U.S.A. Inc. UE906EVG Minimum Retention Period for Maintenance Parts Part number UE906UVG...
