Dataforth MAQ 20 Hardware User Manual

Industrial data acquisition and control system
Hide thumbs Also See for MAQ 20:
Table of Contents

Advertisement

Quick Links

Download this manual
MAQ
20
®
Industrial Data Acquisition
and Control System
MA1059
MAQ20-DIV20
MAQ20-DIVC20
Hardware User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MAQ 20 and is the answer not in the manual?

Questions and answers

Related Manuals for Dataforth MAQ 20

Summary of Contents for Dataforth MAQ 20

  • Page 1 ® Industrial Data Acquisition and Control System MA1059 MAQ20-DIV20 MAQ20-DIVC20 Hardware User Manual...
  • Page 2 ISO9001:2015-Registered QMS The information in this manual has been checked carefully and is believed to be accurate; however, Dataforth assumes no responsibility for possible inaccuracies or omissions. Specifications are subject to change without notice. The information, tables, diagrams, and photographs contained herein are the property of Dataforth Corporation.

  • Page 3: Table Of Contents

    MA1059 MAQ20-DIV20/-DIVC20 Hardware User Manual Table of Contents System Features ..........................1 System Description and Documentation ................... 2 Unpacking ............................4 Module Dimensions and I/O Connections ..................4 Installation ............................6 Building a System ..........................7 Maintaining a System ........................8 Expanding a System .........................
  • Page 4 MA1059 MAQ20-DIV20/-DIVC20 Hardware User Manual About Dataforth Corporation “Our passion at Dataforth Corporation is designing, manufacturing, and marketing the best possible signal conditioning, data acquisition, and data communication products. Our mission is to set new standards of product quality, performance, and customer service.” Dataforth Corporation, with more than a quarter ®...

  • Page 5: System Features

    MA1059 MAQ20-DIV20/-DIVC20 Hardware User Manual 1.0 System Features The MAQ20 Data Acquisition System encompasses more than 30 years of design excellence in the process control industry. It is a family of high performance, DIN rail mounted, programmable, multi- channel, industrially rugged signal conditioning I/O and communications modules. Instrument Class Performance •...

  • Page 6: System Description And Documentation

    MAQ20-mVxN, -VxN Voltage Input Module • MAQ20-IxN Process Current Input Module • MAQ20-IO, -VO Process Current Output and Process Voltage Output Module • MAQ20-BKPLx x Channel System Backbone for a complete listing of available modules and Refer to https://www.dataforth.com/maq20 accessories. 2 of 26...
  • Page 7 For details on installation, configuration, and system operation, refer to the manuals and software available for download from www.dataforth.com. This includes, but is not limited to: MA1036 MAQ®20 Quick Start Guide MA1040 MAQ®20 Communications Module Hardware User Manual MA1041 MAQ®20 milliVolt, Volt, and Current Input Module Hardware User Manual...

  • Page 8: Unpacking

    MA1059 MAQ20-DIV20/-DIVC20 Hardware User Manual 3.0 Unpacking Each MAQ20 Data Acquisition System component is shipped in electro-static discharge (ESD) protective packaging. Use appropriate ESD protection measures while unpacking. Check visually for physical damage. If physical damage is noted, file a claim with the shipping carrier and contact the factory.
  • Page 9 MA1059 MAQ20-DIV20/-DIVC20 Hardware User Manual Table 2: MAQ20-DIVC20 I/O Terminal Block Connections FIELD FIELD CONNECTION TERMINAL TERMINAL CONNECTION CH0 +IN CH0 V compliance CH1 +IN CH1 V compliance CH2 +IN CH2 V compliance CH3 +IN CH3 V compliance CH4 +IN CH4 V compliance CH5 +IN...

  • Page 10: Installation

    MA1059 MAQ20-DIV20/-DIVC20 Hardware User Manual 5.0 Installation The MAQ20 I/O module package has been designed for easy insertion into and removal from a system and can mate with DIN rails mounted flush on continuous panels or plates. To install a module: 1.

  • Page 11: Building A System

    MA1059 MAQ20-DIV20/-DIVC20 Hardware User Manual Figure 3: Possible System Configurations 6.0 Building a System An automated I/O module registration process reduces system setup to three basic steps: STANDARD SETUP PROCESS 1.) Install a MAQ20-BKPLx backbone in a DIN rail then insert a MAQ20-COMx module in the left- most position and apply power.

  • Page 12: Maintaining A System

    The system does not identify I/O modules by physical position on a backbone, only by registration sequence. MAQ20-940 ReDAQ Shape Software for MAQ20 provided by Dataforth shows a graphical representation of a system based on registration sequence and not by physical position. Tools within the software package allow the user to reassign Registration Numbers thereby making graphical representations match physical location for a single, local backbone.

  • Page 13: Expanding A System

    MA1059 MAQ20-DIV20/-DIVC20 Hardware User Manual there is communications activity on the TX and RX LEDs. Allow 1 second for registration. This module now has the same Registration Number as the one removed. CASE 2: I/O module is suspected faulty and is to be replaced with the same model number: Remove a single MAQ20 I/O module from any local or remote backbone position.
  • Page 14 MA1059 MAQ20-DIV20/-DIVC20 Hardware User Manual STANDARD EXPANSION PROCESS 1.) Turn system power on and observe communications activity on the I/O modules. 2.) Add a single MAQ20 I/O module in any local or remote backbone position. Observe that the green Power LED is on and communications activity is seen on the TX and RX LEDs. Allow 1 second for registration.

  • Page 15: Maq20 I/O Module Registration

    The system does not identify I/O modules by physical position on a backbone, only by registration sequence. MAQ20-940 ReDAQ Shape Software for MAQ20 provided by Dataforth shows a graphical representation of a system based on registration sequence and not by physical position.
  • Page 16 MA1059 MAQ20-DIV20/-DIVC20 Hardware User Manual NOTE: When a module is registered in a system, addresses are offset by 2000 * R, where R is the Registration Number. Address Range 1000 - 1299: Module Data Start Read/ Number of Data Contents Description Data Range Address...
  • Page 17 MA1059 MAQ20-DIV20/-DIVC20 Hardware User Manual vacant positions between I/O modules. The system graphic shows a 24-position backbone regardless of the backbone or combination of backbones used in a system. Figure 4: MAQ20-940 ReDAQ Shape for MAQ20 Main Configuration Screen To view the registration sequence, double-click on the MAQ20-COMx graphic to obtain the listing shown in Figure 5.

  • Page 18: Reading Discrete Input Channels

    MA1059 MAQ20-DIV20/-DIVC20 Hardware User Manual Registration Numbers are listed in the left column. The column title Slot Number is the same as the Registration Number and refers to the position where the software has registered the I/O module. Slot Number or Registration Number will not necessarily be the same as the physical position of the module in the system.
  • Page 19 MA1059 MAQ20-DIV20/-DIVC20 Hardware User Manual Figure 6: MAQ20-DIV20 Discrete Input Circuit Topology The MAQ20-DIVC20 module has 20 discrete input channels, each with a +24VDC compliance voltage, for interfacing to relay contacts, solid state switches, or other devices that require an excitation.
  • Page 20 MA1059 MAQ20-DIV20/-DIVC20 Hardware User Manual Figure 7: MAQ20-DIVC20 Discrete Input Circuit Topology MAQ20-DIV20 and MAQ20-DIVC20 Address Map is found at the end of this manual. An excerpt from the Address Map is shown below. NOTE: When a module is registered in a system, addresses are offset by 2000 * R, where R is the Registration Number.
  • Page 21 MA1059 MAQ20-DIV20/-DIVC20 Hardware User Manual Address Range 1000 - 1299: Module Data Start Read/ Number of Data Contents Description Data Range Address Write Registers type DI0 - DI19 Standard Logic 0 = Input < Threshold Discrete Input 1 = Input > States, Binary Discrete Input States.
  • Page 22 MA1059 MAQ20-DIV20/-DIVC20 Hardware User Manual A read from register address 8000 + 1018 = 9005 returns a value of 1 indicating signal > threshold A read from any other register address 9000-9019 returns a value of 0 indicating signal < threshold The data in registers 1000 –...

  • Page 23: Reset Functions

    MA1059 MAQ20-DIV20/-DIVC20 Hardware User Manual 11.0 Reset Functions Two types of firmware reset are supported in the MAQ20 I/O modules: Standard Reset is used to put the module in a user-defined state. The parameters listed below will be set to the last state saved to EEPROM. Parameters stored in EEPROM are not affected.

  • Page 24: Module Identification And Status Registers

    MA1059 MAQ20-DIV20/-DIVC20 Hardware User Manual 12.0 Module Identification and Status Registers Module identification including model number, serial number, date code and firmware revision are stored in registers at addresses 0 – 41. I/O modules in a system are identified in general by their model number (MAQ20-DIOH, MAQ20- VDN, etc.) and uniquely by their Serial Number printed on the side label (1234567-89).
  • Page 25 MA1059 MAQ20-DIV20/-DIVC20 Hardware User Manual LED Function and Troubleshooting Tips: Normal operation: BLUE, solid lit LED Off: Abnormal power situation  Verify that a MAQ20-COMx is present in the system.  Verify that the MAQ20-COMx module has 7-34VDC power connected and turned on. ...

  • Page 26: Specifications

    MA1059 MAQ20-DIV20/-DIVC20 Hardware User Manual 14.0 Specifications MAQ20-DIV20 & -DIVC20 DISCRETE INPUT MODULE Typical at Ta = +25°C and +24V system power Model Number, Input MAQ20-DIV20 10 to 120 VDC / VAC Input, 24VDC Nominal 10 to 24 VDC Input, 24VDC Compliance Voltage MAQ20-DIVC20 Per Channel Number of Channels...

  • Page 27: Maq20-Div20 & Maq20-Divc20 Address Map

    MA1059 MAQ20-DIV20/-DIVC20 Hardware User Manual 15.0 MAQ20-DIV20 & MAQ20-DIVC20 Address Map The table in this section outlines the MAQ20-DIV20 and MAQ20-DIVC20 address space. Data in these registers contains all permanent and user settable information for module configuration, status, operation of all functions, data read/write, and data storage. Table columns list the following information: Start Address: Start address for the specified quantity of addresses.
  • Page 28 MA1059 MAQ20-DIV20/-DIVC20 Hardware User Manual Table 5: MAQ20-DIV20 & MAQ20-DIVC20 Address Map Address Range 0 - 99: Module Information Start Read/ Number of Data Contents Description Data Range Address Write Registers type Characters, Device MAQ20-DIV20 Numbers, "-" ASCII Description and Space Characters, Serial Number S1234567-89...
  • Page 29 MA1059 MAQ20-DIV20/-DIVC20 Hardware User Manual Address Range 1000 - 1299: Module Data Start Read/ Number of Data Contents Description Data Range Address Write Registers type DI0 - DI19 Standard Logic Discrete Input 0 = Input < States Threshold 1 = Input > Binary Discrete Input States.
  • Page 30 MA1059 MAQ20-DIV20/-DIVC20 Hardware User Manual DATAFORTH WARRANTY To view the current Dataforth Corporation Warranty, please click on the link below for the Dataforth Standard Terms and Conditions of Sale Applying to Products Sold by Dataforth Corporation. The Warranty in its entirety is Section 3. Please check this link periodically for updates.

This manual is also suitable for:

Ma1059Maq20-div20Maq20-divc20
