  • Page 1 ® Industrial Data Acquisition and Control System MA1063 MAQ20-DORLY20 Hardware User Manual...
  • Page 2 ISO9001:2015-Registered QMS The information in this manual has been checked carefully and is believed to be accurate; however, Dataforth assumes no responsibility for possible inaccuracies or omissions. Specifications are subject to change without notice. The information, tables, diagrams, and photographs contained herein are the property of Dataforth Corporation.

  • Page 3: Table Of Contents

    MA1063 MAQ20-DORLY20 Hardware User Manual Table of Contents System Features ..........................1 System Description and Documentation ................... 2 Unpacking ............................4 Module Dimensions and I/O Connections ..................4 Installation ............................5 Building a System ..........................6 Maintaining a System ........................7 Expanding a System .........................
  • Page 4 MA1063 MAQ20-DORLY20 Hardware User Manual About Dataforth Corporation “Our passion at Dataforth Corporation is designing, manufacturing, and marketing the best possible signal conditioning, data acquisition, and data communication products. Our mission is to set new standards of product quality, performance, and customer service.” Dataforth Corporation, with more than a quarter ®...

  • Page 5: System Features

    MA1063 MAQ20-DORLY20 Hardware User Manual 1.0 System Features The MAQ20 Data Acquisition System encompasses more than 30 years of design excellence in the process control industry. It is a family of high performance, DIN rail mounted, programmable, multi- channel, industrially rugged signal conditioning I/O and communications modules.

  • Page 6: System Description And Documentation

    MA1063 MAQ20-DORLY20 Hardware User Manual Distributed Processing Enables Even More Functionality • Output modules are programmable for user-defined waveforms • Discrete I/O modules have seven high level functions:  Pulse Counter  Frequency Counter  Waveform Measurement  Time Between Events ...
  • Page 7 The MAQ20-DORLY20 module has 20 isolated SPST latching relay output channels that switch between 2A at 30VDC and 0.4A at 150VDC. Contact state readback on each channel verifies the physical output state.

  • Page 8: Unpacking

    If physical damage is noted, file a claim with the shipping carrier and contact the factory. 4.0 Module Dimensions and I/O Connections Figure 1: Module Dimensions Table 1: MAQ20-DORLY20 I/O Terminal Block Connections FIELD FIELD CONNECTION TERMINAL...

  • Page 9: Installation

    MA1063 MAQ20-DORLY20 Hardware User Manual The high density spring cage terminal blocks can accept the following wire sizes: Solid Wire AWG 25 to AWG 21 Stranded Wire AWG 24 to AWG 21 5.0 Installation The MAQ20 I/O module package has been designed for easy insertion into and removal from a system and can mate with DIN rails mounted flush on continuous panels or plates.

  • Page 10: Building A System

    MA1063 MAQ20-DORLY20 Hardware User Manual Figure 3: Possible System Configurations 6.0 Building a System An automated I/O module registration process reduces system setup to three basic steps: STANDARD SETUP PROCESS 1.) Install a MAQ20-BKPLx backbone in a DIN rail then insert a MAQ20-COMx module in the left- most position and apply power.

  • Page 11: Maintaining A System

    The system does not identify I/O modules by physical position on a backbone, only by registration sequence. MAQ20-940 ReDAQ Shape Software for MAQ20 provided by Dataforth shows a graphical representation of a system based on registration sequence and not by physical position. Tools within the software package allow the user to reassign Registration Numbers thereby making graphical representations match physical location for a single, local backbone.

  • Page 12: Expanding A System

    MA1063 MAQ20-DORLY20 Hardware User Manual CASE 2: I/O module is suspected faulty and is to be replaced with the same model number: Remove a single MAQ20 I/O module from any local or remote backbone position. Replace the module with another of the same model number. This module can be installed in any vacant local or remote backbone position.
  • Page 13 MA1063 MAQ20-DORLY20 Hardware User Manual STANDARD EXPANSION PROCESS 1.) Turn system power on and observe communications activity on the I/O modules. 2.) Add a single MAQ20 I/O module in any local or remote backbone position. Observe that the green Power LED is on and communications activity is seen on the TX and RX LEDs. Allow 1 second for registration.

  • Page 14: Maq20 I/O Module Registration

    Refer to MA1040 MAQ20 Communications Module Hardware User Manual for details. The MAQ20-DORLY20 Address Map is found at the end of this manual. An excerpt from the Address Map is shown below. Channel Data is stored starting at address 1000.
  • Page 15 Registration Number of 4. Write data to the discrete output channels to control the relays. The MAQ20-DORLY20 module with s/n 1234567-89 has an address offset of 2000 * 4 = 8000 Assume the factory default setting of standard logic polarity.
  • Page 16 MA1063 MAQ20-DORLY20 Hardware User Manual Figure 4: MAQ20-940 ReDAQ Shape for MAQ20 Main Configuration Screen To view the registration sequence, double-click on the MAQ20-COMx graphic to obtain the listing shown in Figure 5. Figure 5: Module Registration using MAQ20-940 ReDAQ Shape for MAQ20...
  • Page 17 MA1063 MAQ20-DORLY20 Hardware User Manual Registration Numbers are listed in the left column. The column title Slot Number is the same as the Registration Number and refers to the position where the software has registered the I/O module. Slot Number or Registration Number will not necessarily be the same as the physical position of the module in the system.

  • Page 18: Writing Discrete Output Channels

    150Vrms in the case of inadvertent wiring errors. The basic circuit topology is shown in Figure 6 below. Figure 6: Relay Output Circuit Topology The MAQ20-DORLY20 Address Map is found at the end of this manual. An excerpt from the Address Map is shown below. Page 14 of 34...
  • Page 19 MA1063 MAQ20-DORLY20 Hardware User Manual NOTE: When a module is registered in a system, addresses are offset by 2000 * R, where R is the Registration Number. Refer to Section 9.0 for further details on Registration Number. Address Range 1000 - 1299: Module Data, Advanced Output Function Selection (TBD)

  • Page 20: Setting Default Outputs

    5, 16, 17, and 18 and then read back the states of the output channels using the block read decimal equivalent. The MAQ20-DORLY20 module with s/n 1234567-89 has an address offset of 2000 * 4 = 8000 Note that channels are numbered starting at zero, so the 20 output channels are CH0 – CH19.
  • Page 21 20-digit value representing channel states is written to or read from registers 149 (LSB) and 148 (MSB). The MAQ20-DORLY20 Address Map is found at the end of this manual. An excerpt from the Address Map is shown below.
  • Page 22 MA1063 MAQ20-DORLY20 Hardware User Manual Address Range 100 - 699: Module Configuration Start Read/ Number of Data Contents Description Data Range Address Write Registers type Default Relay Decimal Equivalent of States at Power Relay Default States at Up, Block 0 to 15...
  • Page 23 10 through channel 19 relay contacts to open using block write. The MAQ20-DORLY20 module with s/n 1234567-89 has an address offset of 2000 * 4 = 8000 Note that channels are numbered starting at zero, so the 20 output channels are CH0 – CH19.

  • Page 24: Alternate Output Mode Description And Configuration (Preliminary)

    MA1063 MAQ20-DORLY20 Hardware User Manual 12.0 Alternate Output Mode Description and Configuration (Preliminary) The standard output contact form presented at the field terminal blocks is 20 channels of SPST. The following advanced output functions can be configured with external field terminal block wiring and controlled by writing to designated registers in the module address map.

  • Page 25: Cross Point Matrix Mode - (Preliminary. Not Currently Implemented)

    MA1063 MAQ20-DORLY20 Hardware User Manual Figure 8: DPDT Mode Field Terminals and Wiring 12.3 Cross Point Matrix Mode – (Preliminary. Not Currently Implemented) This mode operates the 20 relays as a 4 by 5 cross point switch. Figure 9: Cross Point Matrix Field Terminals and Wiring...
  • Page 26 MA1063 MAQ20-DORLY20 Hardware User Manual Figure 10: Cross Point Matrix Field Terminals and Wiring with Splice Connections Page 22 of 34...

  • Page 27: Differential Multiplexer Mode - (Preliminary. Not Currently Implemented)

    MA1063 MAQ20-DORLY20 Hardware User Manual 12.4 Differential Multiplexer Mode – (Preliminary. Not Currently Implemented) Differential multiplexing is useful for precision measurements. This mode operates the 20 relays as a multiplexer with 10 differential inputs and 1 differential output. Switching action is break-before- make.

  • Page 28: Multiplexer Mode - (Preliminary. Not Currently Implemented)

    MA1063 MAQ20-DORLY20 Hardware User Manual 12.5 Multiplexer Mode – (Preliminary. Not Currently Implemented) This mode operates the 20 relays as a 20:1 multiplexer. Switching action is break-before-make. Multiplexer control allows any combination of switches to be closed or open. Figure 12: Multiplexer Field Terminals and Wiring 12.6 Null Mode –...

  • Page 29: Other Multiplexer Modes - (Preliminary. Not Currently Implemented)

    MA1063 MAQ20-DORLY20 Hardware User Manual 12.7 Other Multiplexer Modes – (Preliminary. Not Currently Implemented) Utilizing the 20 SPST relays presented at the field terminal blocks and relay control by either bitwise manipulation or block writing, many different functions can be realized to suit specific application needs.

  • Page 30: Reset Functions

    Refer to the MAQ20-DORLY20 Address Map for further details on what parameters are affected by resets and what default values are. Table 2: Parameters Affected by Standard Reset and Reset-to-Default...

  • Page 31: Module Identification And Status Registers

    Module identification including model number, serial number, date code, and firmware revision are stored in registers at addresses 0 – 41. I/O modules in a system are identified in general by their model number (MAQ20-DORLY20, MAQ20-VDN, etc.) and uniquely by their Serial Number printed on the side label (1234567-89).
  • Page 32 Normal operation: Off Alarm Condition Detected: RED, solid lit.  This function is not implemented in the MAQ20-DORLY20 module The following troubleshooting tips can be used to further diagnose and fix system problems:  Remove and reinstall MAQ20 I/O module and/or MAQ20-COMx module to verify proper insertion into Backbone.

  • Page 33: Specifications

    MA1063 MAQ20-DORLY20 Hardware User Manual 16.0 Specifications MAQ20-DORLY20 RELAY OUTPUT MODULE Typical at T = +25°C and +24V system power Model Number, Input / Output MAQ20-DORLY20 60W per channel (2A at 30V to 0.4A at 150V) Number of Channels Output Configuration...

  • Page 34: Maq20-Dorly20 Address Map

    MA1063 MAQ20-DORLY20 Hardware User Manual 17.0 MAQ20-DORLY20 Address Map The table in this section outlines the MAQ20-DORLY20 address space. Data in these registers contains all permanent and user settable information for module configuration, status, operation of all functions, data read/write, and data storage. Table columns list the following information: Start Address: Start address for the specified quantity of addresses.
  • Page 35 MA1063 MAQ20-DORLY20 Hardware User Manual Table 4: MAQ20-DORLY20 Address Map Address Range 0 - 99: Module Information Start Read/ Number of Data Contents Description Data Range Address Write Registers type Characters, Device MAQ20-DORLY20 Numbers, "-" and ASCII Description Space Characters,...
  • Page 36 MA1063 MAQ20-DORLY20 Hardware User Manual Address Range 100 - 699: Module Configuration Start Read/ Number of Data Contents Description Data Range Address Write Registers type Default Relay Decimal Equivalent of States at Power Relay Default States at 0 to 15...
  • Page 37 MA1063 MAQ20-DORLY20 Hardware User Manual Address Range 1000 - 1299: Module Data, Advanced Output Function Selection (TBD) Start Read/ Number of Data Contents Description Data Range Address Write Registers type DO0 - DO19 Standard Logic 0 = Relay Open Relay States,...
  • Page 38 MA1063 MAQ20-DORLY20 Hardware User Manual DATAFORTH WARRANTY To view the current Dataforth Corporation Warranty, please click on the link below for the Dataforth Standard Terms and Conditions of Sale Applying to Products Sold by Dataforth Corporation. The Warranty in its entirety is Section 3. Please check this link periodically for updates.
