SMART REEF Smart A.T.O. TINY+ Manual

Smart A.T.O.
Manual
（TINY+）
System connection
← ←
Pipe
Prevent
rack
siphon
***
If a siphon occurs,
punch holes in
this position.
DC
pump
→
Bucket Bucket
The outlet pipe must not be lower than the water
Warning
surface, otherwise the water will flow back from
the fish tank back to the bucket! !
** The water outlet should not be aligned with the probe.
*** If you unplug the power supply and still add water, it is
siphoning. You need to open a hole with a diameter of 1mm
on the water pipe. After opening the hole, water will flow
out of the hole and flow back into the bucket when the pump
is running,This is normal.. After the pump stops working,
the small holes will draw in air and destroy the siphon.
Ver.1.0
SMART REEF
←
** Magnetic
controller
Probe
Fish tank Fish tank
The function of
the controller
Meaning of the
indicator light
Power
supply
Set-up Directions
1、Install the probe with a water level lower
Step
than the probe or in the middle of the probe.
2、After turning on the power, press and hold
1
the multi-function button for 6 seconds. You
can let go when you hear the sound of "DiDiDi",
and the initialization is successful.
3、The system will automatically add water
to the high level sensing point.
4、Let the water level below the low level
sensing point to see if the system will auto-
matically add back the water.
Notice
the probe during the test, it may be caused by
3
residual water droplets on the probe. As long as the
probe is cleaned, it will return to normal.
Buzzer
Water shortage, or running error (Red)
High level sensing point (Blue)
low level sensing point
Level
Smartreefs
+ Water shortage
TINY
Pause (White flashing )
Pause
Multi-function button
Need to be cleaned or replaced (Red)
High level sensing point (Yellow)
low level sensing point
Water shortage (Lights off)
If you quickly lower the water level or pick up
(Green)
(Lights off )
(Green)
Step
2
