SMART REEF Smart A.T.O. Tosta Manual

Smart A.T.O.
Manual
（Tosta）
System connection
The outlet pipe must not be lower than the water surface,
otherwise the water will flow back from the fish tank back to
the bucket! !
← ←
Pipe
rack
Prevent
siphon
If a siphon occurs,
punch holes in
this position.
Pump
→
Bucket
*** If you unplug the power supply and still add water, it is
siphoning. You need to use scissors to cut a hole with a
diameter of 1 mm on the water pipe. After opening the hole,
water will flow out of the hole and flow back into the bucket
when the pump is running,This is normal.. After the pump
stops working,the small holes will draw in air and destroy
the siphon.
Ver.1.0
←
HIG HIG
MID MID
Smartreefs
LOW
A.T.O. Pause Lock
Freq. Buzzer
AUTO TOP OFF
Controller
Fish tank
Set-up Directions
· The main control has a water level detection
device, so the main control needs to be installed
in the transparent glass to work properly;
Installation of
the host
2
Power
Supply
· Please note that the internal and external
modules must be aligned, otherwise they cannot
be sensed normally.
Installation of
the host
4
· You can use a PE pipe(DN8)(commonly used
for RO water purifiers) to extend the water
inlet and outlet pipes, and you can directly put
the hose on a rigid pipe (at least 5cm is
appropriate).
1 2
· The installation site must be cleaned before
installation. Large algae or dirt may cause
abnormal sensing.
· Back filter is usually opaque. After cutting the
black opaque film on the glass with a knife, the
device can be used normally.
Installation of
the host
1
Installation of
the host
3
Water pipe
5
