TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTION ......................4 INSTALLATION INSTRUCTIONS ........................13 WHAT IS IN THE PACKAGE ..............................13 BEFORE THE INSTALLATION ..............................13 WINDOW REQUIREMENTS ..............................14 INSTALLATION OVERVIEW ..............................14 OPERATION INSTRUCTIONS ........................20 GET TO KNOW YOUR AC .................................20 ADJUST YOUR AC DIRECTION ..............................21 GET TO KNOW THE FEATURES .............................22 CARE &...
IMPORTANT SAFETY INSTRUCTION READ THESE SAFETY PRECAUTIONS BEFORE INSTALLATION AND OPERATION. For your safety, it is important that you read and follow the instructions in this manual to minimize the risk of personal injury, fire or electrical shock. Inside you will find many helpful hints on how to use and maintain your air conditioner properly. Just a little preventive care on your part can save you a great deal of time and money over the life of your air conditioner.
Page 5
IMPORTANT SAFETY INSTRUCTION (Continued) contact a qualified service technician. CAUTION • This appliance is not intended for use by • When the air filter is to be removed, do not touch persons (including children) with reduced physical, sensory or mental capabilities or lack the metal parts of the unit.
Page 6
IMPORTANT SAFETY INSTRUCTION (Continued) OPERATION OF CURRENT DEVICE WARNING The power supply cord contains a current device ELECTRICAL INFORMATION that senses damage to the power cord. To test your power supply cord do the following: The complete electrical rating of your new room air conditioner is stated on the serial plate.
Page 7
IMPORTANT SAFETY INSTRUCTION (Continued) • Be sure the air conditioner has been securely • Be aware that the refrigerants may not contain and correctly in stalled according to the an odor. installation instructions in this manual. Save • Compliance with national gas regulations shall this manual for possible future use in removing be observed.
Page 8
IMPORTANT SAFETY INSTRUCTION (Continued) CAUTION: IMPORTANT NOTE: Read this manual carefully before installing or operating Risk of fire your new air conditioning unit. Make sure flammable materials to save this manual for future reference. Explanation of symbols displayed on the unit This symbol shows that the operation manual should be read carefully.
Page 9
IMPORTANT SAFETY INSTRUCTION (Continued) used, the secondary circuit shall be checked WARNING for the presence of refrigerant. (For using R290/R32 refrigerant only) • Marking to the equipment continues to be visible and legible. Markings and signs that are illegible should appropriate fire extinguishing equipment be corrected.
Page 10
IMPORTANT SAFETY INSTRUCTION (Continued) DETECTION OF FLAMMABLE WARNING REFRIGERANTS (For using R290/R32 refrigerant only) • Under no circumstances, should potential sources of ignition be used in the searching for or detection of refrigerant leaks. A halide torch components, the casing is not altered in such (or any other detector using a naked flame) a way that the level of protection is affected.
Page 11
IMPORTANT SAFETY INSTRUCTION (Continued) DECOMMISSIONING WARNING • Before carrying out this procedure, it is essential (For using R290/R32 refrigerant only) that the technician is completely familiar with the equipment and all its detail. It is recommended good practice that all refrigerants are recovered •...
Page 12
IMPORTANT SAFETY INSTRUCTION (Continued) • The recovered refrigerant shall be returned to WARNING the refrigerant supplier in the correct recovery cylinder, and the relevant Waste Transfer (For using R290/R32 refrigerant only) Note arranged. Do not mix refrigerants in recovery units and especially not in cylinders. LABELLING If compressors or compressor oils are to be removed, ensure that they have been evacuated...
5/8 in Screws and Safety Lock (3 Types) 3/8 in Screws BEFORE THE INSTALLATION Top Rail The installation must be carried out in (will be preinstalled on 4PACH8000) M a n u a l strict accordance with the instructions in this manual.
INSTALLATION INSTRUCTIONS (Continued) WINDOW REQUIREMENTS INSTALLATION OVERVIEW 16.5in (419mm) LEFT RIGHT Your air conditioner is designed to install in Safety Lock and 5/8in Screws standard double hung windows with opening Top Rail and 3/8in Screws widths of 23 to 36 inches (584mm to 914mm) Frame Assembly (Left) and a minimum height of 16.5 inches (419 mm).
Page 15
1. Install the top rail on 4PACH12000. to the rear of (5/16 "). This is necessary The top rail is preinstalled on 4PACH8000. for proper condensed water utilization and drainage. If you are not using the Side Panels for any reason, this pitch to the rear must be maintained.
Page 16
INSTALLATION INSTRUCTIONS (Continued) 5. The AC unit is done. STEP 2 INSULATE YOUR WINDOW LEFT RIGHT What you need: Cut the seal foam to the width of your window, Before you rush to the next installation phase, and stick it of the underside. please first confirm the following installation is in place: The upper and lower frame strips of the...
Page 17
INSTALLATION INSTRUCTIONS (Continued) 2. Properly position the bottom bar BEHIND the STEP 3 inside window sill. LIFT THE AC INTO THE WINDOW LEFT RIGHT What you need: 1. Together with your helper, lift the assembled Properly position the bottom bar behind AC into the window frame.
Page 18
INSTALLATION INSTRUCTIONS (Continued) 3. Close the window down onto the AC, and pull 1. Drive locking screws. the panels to the side of the window. Follow the below instructions and drive the screws. Drive 1/ 2" (12.7 mm) locking screws through the frame lock and into the sill (Only wooden windows).
Page 19
INSTALLATION INSTRUCTIONS (Continued) THE FINAL DETAILS ONE MORE THING 1. If AC is Blocked by Storm Window. Add wood as shown in Caution illustration on page 18, or remove storm window before air conditioner is installed. If Storm Window Frame must remain, be sure the drain holes or slots are not caulked or painted shut.
OPERATION INSTRUCTIONS GET TO KNOW YOUR AC NOTE: The following two types of product appearance for reference only, The machine you purchase may be a little different. Status Display Power Button Rear Condenser Vents Display (Electronic control panel only) Front Intake Grille (The filter is behind this) Feature Selection (Electronic control panel only)
OPERATION INSTRUCTIONS (Continued) ADJUST YOUR AC DIRECTION CAUTION Do not stick your fingers in the air outlet, it may cause an injury. FOUR-WAY ADJUSTMENT (UP OR DOWN, LEFT OR RIGHT) The louvers will allow you to direct the air flow Up or Down and Left or Right throughout the room as needed.
OPERATION INSTRUCTIONS (Continued) GET TO KNOW THE FEATURES WARNING • To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT SAFETY INSTRUCTIONS before operating this appliance. • Please always wait 3 minutes when turning unit off then on again, and when changing from cool to fan and back to cool.
Page 23
OPERATION INSTRUCTIONS (Continued) 5. CHECK FILTER FEATURE To operate on COOL mode • Choose Cool Mode to set the cooling function. Press Check filter button to initiate this feature. Use the - or + buttons to choose the desired This feature is a reminder to clean the Air Filter temperature.
Page 24
OPERATION INSTRUCTIONS (Continued) 10. DISPLAY To operate on DRY mode • In this mode, the air conditioner will generally operate in the form of a dehumidifier. Since the conditioned space is a closed or sealed area, some degree of cooling will occur. Shows the set temperature in ”°F"...
CARE & MAINTENANCE CHECK THE AIR FILTER ONCE A MONTH TO SEE IF CLEANING IS NECESSARY The air filter should be checked at least once a month to see if cleaning is necessary. Trapped particles in the filter can build up and cause an accumulation of frost on the cooling coils.
Set temperature too low. Increase set temperature. The design and specifications are subject to change without prior notice for product improvement. Any updates to the manual will be uploaded to the Perfect Aire website (www.perfectaire.us), please check for the current version.
Page 28
SCAN CODE TO LEAVE A REVIEW THANK YOU FOR YOUR PURCHASE! We’d love to hear how you are enjoying your Perfect Aire product! Please take a minute to tell us (and others) about your experience. Thanks (again!) 5401 Dansher Road...
