56 volt lithium-ion cordless wet/dry vacuum cleaner

Advertisement

Do not use non-rechargeable batteries in place of
rechargeable batteries.
Do not use modified or damaged batteries.
Use only with the specified battery packs and
chargers
BATTERY PACK
BA1400, BA2800, BA4200,
BA1400T, BA2800T, BA4200T,
BA5600T, BA6720T
Save these instructions. Refer to them frequently and
use them to instruct others who may use this machine.
If you lend someone this machine, lend them these
instructions also to prevent misuse of the product and
possible injury.

SPECIFICATIONS

Voltage
Dust Tank Capacity
Speed Mode
Max. Air Flow (L/min)
Max. Suction Power (Pa)
Charging
Temperature
Remote
Max. Charging
Control
Voltage
Max. Charging
Current
Weight (Without battery
pack)
Recommended Operating
Temperature
Recommended Storage
Temperature
PACKING LIST (FIG. A1 & A2)

RECOMMENDED ACCESSORIES

WARNING:
Use only accessories listed below. Use
of accessories that do not meet the original equipment
specifications may lead to improper performance and
compromised safety.
8
56 VOLT LITHIUM-ION CORDLESS WET/DRY VACUUM CLEANER — WDV0900E
CHARGER
CH2100E, CH5500E,
CH7000E
56 V
34 L
Low
High
TURBO
1900
2500
3100
10000
15900
24800
0°C - 45°C
5 V
1 A
12.1 kg
-5°C - 40°C
-20°C - 70°C
PART NAME
Dust Bags (5 pcs)
Standard Filter
DESCRIPTION
KNOW YOUR WET/DRY VACUUM CLEANER
(FIG. A1 & A2)
ASSEMBLY
CONNECTING/DISCONNECTING THE VACUUM HOSE
To connect, push the end of the hose into the suction inlet
port or the blowing outlet port until you hear a "click"
(Fig. B1).
To disconnect, press and hold the hose-release buttons to
remove the hose (Fig. B2).
CONNECTING/DISCONNECTING THE EXTENSION
TUBES (FIG. C)
Connect one or two extension tubes to the vacuum hose
according to your needs.
To connect, insert the narrow end of the extension tube
into the vacuum hose as far as you can until the extension
tube is secured in place.
To disconnect, pull the extension tube from the vacuum
hose.
The second extension tube is connect/disconnected to the
first tube in the same fashion.
INSTALLING/REMOVING THE NOZZLES
Choose a suitable nozzle to install onto the vacuum
hose directly or onto the extension tube according to
your needs (Fig. D1)
To connect the nozzle to the extension tube, insert the
nozzle into the extension tube as far as you can until it
is secured in place. To disconnect, pull the nozzle from
the extension tube.
To connect the nozzle to the vacuum hose directly,
align the knob on the nozzle with the groove in the
vacuum hose, insert the nozzle into the vacuum hose
until you hear a "click". To disconnect, press and hold
the release button to remove the nozzle.
Crevice Nozzle (Fig. D2)
The dark areas could be easily cleaned when using the
crevice nozzle combined with the integrated light of the
remote control.
MODEL NUMBER
AVG0905
AVF0900
