NOTE:
During normal operation, the remote control
indicator will light one time when the TURBO button or the
start/stop button is pressed once.
Recharging the Remote Control (Fig. J3)
Periodically the battery inside the remote control will need
to be recharged.
WARNING:
For this rechargeable Li-ion battery inside
the remote control, please be aware of below:
◾
Risk of fire and burns.
◾
Do not open, crush, heat above 60°C or incinerate.
◾
Do not short circuit.
◾
If bulges severely, discontinue use.
1. Open the USB-C port cover.
2. Connect the USB-C end of the included charging cable
to the USB-C port in the remote control.
3. Connect the other end of the charging cable to a
compatible USB power adapter/charger (not included).
It may take up to 2h to charge a fully discharged
battery.
4. When finished charging, disconnect the charging cable
and close the USB-C port cover to protect the USB-C
port from contamination.
WORKING WITH THE VACUUM CLEANER
Wet Vacuuming Operation
◾
Do not use the dust bag during wet vacuuming
operation.
◾
Turn off the vacuum cleaner immediately when the
dust tank is full. Empty the dust tank into a suitable
receptacle or drain.
◾
Clean the interior of the dust tank, the filter, and
accessories periodically, more often when used to pick
up wet, sticky materials.
Dry Vacuuming Operation
◾
Make sure the filter is completely dry after wet
vacuuming or use a second dry filter for dry
vacuuming. Damp or wet filters will get clogged with
dust or get moldy.
◾
To reduce exposure to silica dust, use dust bag.
◾
Turn off the vacuum cleaner immediately when the
dust bag or dust tank is full.
◾
Empty the dust tank into a suitable receptacle or drain.
Blower Operation
WARNING:
Always wear eye protection when using
this machine as a blower.
56 VOLT LITHIUM-ION CORDLESS WET/DRY VACUUM CLEANER — WDV0900E
WARNING:
Do not blow flammable or combustible
materials, such as gasoline, or use in areas where such
materials may be present. Fire could result.
WARNING:
Do not direct the airflow in the direction
of people or pets.
MAINTENANCE
WARNING:
To prevent serious personal injury,
remove the battery pack from the product before servicing,
cleaning, changing attachments, or removing material from
the unit.

GENERAL MAINTENANCE

Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types of
commercial solvents and may be damaged by their use.
Use a clean cloth to remove dirt, dust, oil, grease, etc.
WARNING:
Do not at any time allow brake fluids,
gasoline, petroleum-based products, penetrating oils, etc. to
come in contact with plastic parts. Chemicals can damage,
weaken or destroy plastic which may result in serious
personal injury.
T
WARNING:
o reduce the risk of fire, personal injury,
and product damage due to a short circuit, never immerse
your machine, battery pack or charger in fluid or allow a
fluid to flow inside them. Corrosive or conductive fluids,
such as seawater, certain industrial chemicals, and bleach
or bleach containing products, etc., can cause a short
circuit.

EMPTYING THE DUST TANK

1. Remove the drain port cap to empty liquid in the dust
tank into a suitable receptacle or drain, if available.
2. Remove the power head assembly from the dust
tank.
3. Remove the dust bag if the dust bag is installed.
4. Clear all dirt or debris from the dust tank and clean
with mild soap and water.
5. Allow the dust tank to dry before reassembling the
power head assembly.

FILTER MAINTENANCE

Filter Self-Cleaning System
1. Connect the vacuum hose to the suction inlet port of
the vacuum cleaner and install the other end of the
hose onto the filter self-cleaning plug (Fig. K1).
2. Install the battery pack, press the power button to
power on the machine.
