Speed Selection; Turbo Mode; Remote Control - Ego Power+ WDV0900E Operator's Manual

Power Button Indicator
Power Button
Meaning
Indicator
Standby
Solid green
The machine
runs properly.
Liquid level in
Flashing green the tank reaches
6 times, then the bottom tip
shuts off. of the liquid
sensors
Flashing green
Electronics error
continuously

SPEED SELECTION

Regular Speed Mode
◾
Every time the speed adjustment button is pressed, the
speed will toggle between low level and high level. The
speed indicator displays green lights corresponding to
the current speed level.
◾
The vacuum cleaner will save the last speed setting
and will revert to it upon restart.

TURBO MODE

◾
Press the TURBO button, the TURBO indicator will light
up green and the vacuum cleaner will start working
directly at TURBO speed, i.e. the highest speed.
◾
When in TURBO mode, press TURBO button again,
or press the speed adjustment button, the start/stop
button, or the power button – the TURBO indicator will
turn off and the vacuum cleaner will exit TURBO mode.
NOTE:
After exiting TURBO mode, the vacuum will
resume previously active regular speed.
SUCTION REGULATOR (Fig. I)
When vacuuming, the air flow at the end of the vacuum
hose can be controlled by turning the suction regulator.
Turn the regulator to expose the air outlet to decrease
the suction, or turn the regulator to cover the air outlet to
increase the suction.
10
56 VOLT LITHIUM-ION CORDLESS WET/DRY VACUUM CLEANER — WDV0900E
Action
No actions
required. The
vacuum cleaner
will turn off
automatically after
1 hour of inactivity
Normal operation.
Stop the vacuum
cleaner, remove
the battery pack,
and then empty the
dust tank.
Contact EGO
customer service
for help
This feature is especially useful when the vacuum hose
is sealed by carpets, cloths, etc. during suction, turn the
regulator to expose the air outlet, the suction will be
decreased.

REMOTE CONTROL

◾
The remote control could be positioned on the vacuum
hose during vacuuming (Fig. J1).
◾
When the vacuum cleaner is powered on, you may
start/stop the vacuum cleaner, or switch the machine
into TURBO mode by using the remote control.
NOTE:
The remote control cannot switch between regular
low or high speed.
◾
The remote control can also be used as a flashlight for
dark areas, especially when using the crevice nozzle.
Remote Control Pairing (Fig. J2)
The remote control was paired with the vacuum cleaner at
the factory. However, in cases when the remote control is
damaged or lost, follow below steps to pair your new remote
control with the vacuum cleaner.
1. Install the battery pack.
2. Press the power button to power up the vacuum
cleaner.
3. Long-press the start/stop button on the vacuum until
the power button indicator flashes green slowly.
4. Press the TURBO button or the start/stop button on the
remote control as soon as the power button indicator
starts flashing green slowing.
5. The power button indicator will flash green fast and
then shine solid green to indicate the pairing was
successful.
Remote Control Indicator
Remote
Control Meaning
Indicator
The remote
Flashing green
control battery
charge is nearly
fast
depleted.
The remote
Flashing green
control is
slowly
charging
The charging
of the remote
Solid green
control is
complete.
Action
Charge the remote
control.
No action needed.
Disconnect the
remote control and
charging cable
from power supply.
