DA11ABL-WP-US-V2
Introduction
FEATURES:
• Dante® network wall plate interface for Bluetooth and analog L/R audio inputs, and L/R audio outputs
• Converts 2ch Bluetooth, or un-balanced audio sources to Dante® audio
• Converts 2x Dante® audio channels to un-balanced audio outputs
• Adjustable input sensitivity from +24dBu to -28dBV and output gain from +20dBu to -28 dBV via web GUI or API
• Dante® Audio Supports 44.1, 48, 88.2 & 96 KHz sample rates @ 16, 24 & 32 Bit
• Configurable Dante® device latency (supports 2, 3, 4, 5 or 10ms configurable using Dante® Controller)
• Supports AES67 RTP audio transport
• Features Class 0 IEEE 802.3af PoE for powering of product from any PoE switch
• Supports power via 12V DC adapter (not included) for when network switch does not support PoE
• White magnetic faceplate surround and US Decora style backbox compatibility
• In-built web-GUI for configuration and control
Bluetooth
Bluetooth 5.0 technology allows for up to 2x simultaneous connections from source audio devices, where the
selected devices audio is received and sent into the Dante network.
To connect a Bluetooth enabled device to the DA11ABL-WP-V2, press the Pair button on the unit, go to the
Bluetooth settings of the source audio device, and enable Bluetooth connectivity. The DA11ABL-WP-US-V2 will
appear in the list of available devices.
Contact:
support@blustream.com.au
Quick Reference Guide
The DA11ABL-WP-US-V2 is a multi-input / output wall plate to convert Bluetooth and
analog audio within a digital Dante® networked audio system. The DA11ABL-WP-US-V2
converts 2 input channels of Bluetooth or unbalanced audio to Dante® digital audio, and 2
channels of Dante® audio to 2 x output channels of unbalanced audio.
The DA11ABL-WP-US-V2 is a plug & play device that is powered using PoE (Power over
Ethernet), or via 12V power supply, offers support for AES67 RTP audio transport and
magnetic faceplate design allows installation into most single-gang US junction boxes.
The DA11ABL-WP-US-V2 is the ideal BYOD interface to allow any Bluetooth device to
stream audio wirelessly to a Dante® audio system.
|
support@blustream-us.com
DA11ABL-WP-US-V2
|
support@blustream.co.uk
QUICK REFERENCE GUIDE
01
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Bluestream DA11ABL-WP-US-V2
Summary of Contents for Bluestream DA11ABL-WP-US-V2
- Page 1 Dante® audio to 2 x output channels of unbalanced audio. The DA11ABL-WP-US-V2 is a plug & play device that is powered using PoE (Power over Ethernet), or via 12V power supply, offers support for AES67 RTP audio transport and magnetic faceplate design allows installation into most single-gang US junction boxes.
- Page 2 Dante products that are set up with the same sample rate. A mismatch in sample rate may stop audio from transmitting. Under the “Device Config” screen we can also adjust the latency of the DA11ABL-WP-US-V2 from 2, 3, 4, 5 or 10 milliseconds.
- Page 3 Web Interface Module The DA11ABL-WP-US-V2 features an in-built Web GUI which can be used for control and configuration of the device. By default the device is set to DHCP, however if a DHCP server (eg: network router) is not installed the device will receive a link local address in the 169.254.xxx.xxx range.
- Page 4 Connections Bluetooth LED - Illuminates when a Bluetooth connection is active Power LED - Illuminates when the DA11ABL-WP-US-V2 is powered on Audio In - Analog audio 3.5mm L/R stereo input jack. Connect to analog audio souce device for audio input Audio Out - Analog audio RCA L/R output.
