Introduction
FEATURES:
• Encodes 1ch USB audio to Dante® digital signal
• Decodes a Dante® digital signal to USB audio
• Selectable USB audio between USB Type-B and USB-C inputs
• Compliant with USB Audio Device Class Specification V1.0
• Supports 44.1 & 48 KHz sample rates @ 16 Bit
• Configurable Dante® device latency (supports 1, 2 or 5ms configurable using Dante® Controller)
• Supports AES67 RTP audio transport
• Features Class 0 IEEE 802.3af PoE for powering of product from any PoE switch
• Supports power via 5V USB for when network switch does not support PoE
Front Panel
1
DA11USB
Dante USB Audio Encoder / Decoder
Connections:
Dante® Audio Input - RJ45 socket connects Dante® network and powers device via PoE
1
USB-B Connection - Connect to PC via USB-B to USB-A cable provided to provide bi-directional 2ch audio
2
USB-C Connection - Connect to PC via USB-C cable provided to provide bi-directional 2ch audio
3
USB Selection Switch - Select the USB connection method between USB-B and USB-C
4
Contact:
support@blustream.com.au
DA11USB
Quick Reference Guide
Our DA11USB has been designed to both encode 2ch USB audio to a Dante®
digital signal, and decode a Dante® digital signal to 2ch USB audio. The DA11USB
features both USB Type-B and USB-C connections selectable via local dip-switch
and is a plug & play device that is powered using PoE (Power Over Ethernet) or via
5V from the USB device. The DA11USB also supports AES67 RTP audio transport.
Rear Panel
2
3
DA11USB
Dante USB Audio Encoder / Decoder
USB-B
USB-C
|
support@blustream-us.com
Side Panel
4
USB-B USB-C
USB-B
USB-C
|
support@blustream.co.uk
DA11USB
QUICK REFERENCE GUIDE
01
Advertisement
Table of Contents
Related Manuals for Bluestream DA11USB
Summary of Contents for Bluestream DA11USB
- Page 1 Quick Reference Guide Introduction Our DA11USB has been designed to both encode 2ch USB audio to a Dante® digital signal, and decode a Dante® digital signal to 2ch USB audio. The DA11USB features both USB Type-B and USB-C connections selectable via local dip-switch and is a plug &...
- Page 2 By default the DA11USB is shipped with its network settings set to obtain an IP Address automatically. This means that if a DHCP server is present on your network, it will provide the DA11USB with an IP Address. If no DHCP server is present then the DA11USB will receive a default IP Address in the 169.254.xxx.xxx range.
- Page 3 QUICK REFERENCE GUIDE Advanced Dante Settings It is also possible to change the settings of the DA11USB under the “Device Info” screen in the Dante Controller software. To do so, select the “Device Config” menu. Here we can adjust the sample rate of the DA11USB. Please note that Dante products can only transmit or receive audio from other Dante products that are set up with the same sample rate.
- Page 4 USB-B Specifications Package Contents Audio Input/Output Connectors: 1 x RJ45, female (100 Mbps Dante® network) • 1 x DA11USB 1 x USB Type B, female • 1 x USB-A to USB-B 1m cable 1 x USB Type C, female •...
