INSTALLATION MANUAL
Two-Stage Variable Speed ECM
Residential Gas Furnaces
Models: TM9V*C Series
(96% AFUE Multi-position)
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Ductwork . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Gas piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Electrical power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Combustion air and vent system . . . . . . . . . . . . . . . . . . . . . . 22
Duct attachment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Combustible floor base accessory . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Furnace and coil attachment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Horizontal application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Typical attic installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Typical suspended furnace/crawl space installation . . . . . . . . . . . . . 7
Downflow venting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Side return cutout markings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Gas valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Left side supply gas pipe arrangement . . . . . . . . . . . . . . . . . . . . . . . 9
Gas piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Electrical wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Two-stage furnace with communicating AC or HP . . . . . . . . . . . . . . 12
Furnace control board - communications connections . . . . . . . . . . 13
Terminal screw wire connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Furnace with variable capacity AC or HP . . . . . . . . . . . . . . . . . . . . . 13
with two-stage variable speed furnace . . . . . . . . . . . . . . . . . . . . . . . 14
with two-stage variable speed furnace . . . . . . . . . . . . . . . . . . . . . . . 15
with two-stage variable speed furnace . . . . . . . . . . . . . . . . . . . . . . . 15
Unit clearances to combustibles . . . . . . . . . . . . . . . . . . . . . . . . . 4
Cabinet and duct dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Recommended filter sizes (high velocity 600 FPM) . . . . . . . . . . 8
Nominal manifold pressure - high fire . . . . . . . . . . . . . . . . . . . . 10
Nominal manifold pressure - low fire . . . . . . . . . . . . . . . . . . . . . 10
Ratings and physical/electrical data . . . . . . . . . . . . . . . . . . . . . 11
Maximum equivalent pipe length . . . . . . . . . . . . . . . . . . . . . . . . 23
High altitude pressure switches . . . . . . . . . . . . . . . . . . . . . . . . . 24
Elbow dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Equivalent length of fittings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
These high efficiency, compact units employ induced combustion, reli-
able hot surface ignition and high heat transfer aluminized tubular heat
exchangers. The units are factory shipped for installation in upflow or
horizontal applications and may be converted for downflow applica-
tions.
Johnson Controls Ducted Systems
List of sections
Start-up and adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Safety controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Normal operation and diagnostics . . . . . . . . . . . . . . . . . . . . 36
Replacement parts list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Replacement part contact information . . . . . . . . . . . . . . . . . 39
Wiring diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Start-up sheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
List of figures
furnace (hot heat pump or conventional) . . . . . . . . . . . . . . . . . . . . . 16
Typical condensate drain, vertical installation . . . . . . . . . . . . . . . . . 17
Upflow configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Downflow configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Horizontal left configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Horizontal right configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Home layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Termination configuration - single pipe . . . . . . . . . . . . . . . . . . . . . . . 26
Termination configuration - two pipe . . . . . . . . . . . . . . . . . . . . . . . . . 26
Termination configuration - two pipe (basement) . . . . . . . . . . . . . . . 26
Double horizontal combustion air intake and vent term . . . . . . . . . . 27
Double vertical combustion air intake and vent term . . . . . . . . . . . . 27
Downward venting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Direct vent air intake connection and vent connection . . . . . . . . . . . 27
Combustion airflow path through the furnace casing . . . . . . . . . . . . 28
Ambient combustion air . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Attic and crawl space combustion air termination . . . . . . . . . . . . . . . 30
Gas valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Reading gas pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Furnace control board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Wiring diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
List of tables
(all models) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Vent clearances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Estimated free area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Unconfined space minimum area . . . . . . . . . . . . . . . . . . . . . . . 28
Free Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Gas rate (ft3/h) at full input . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Inlet gas pressure range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Nominal manifold pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Default blower speeds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Airflow data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
These furnaces are designed for residential installation in a basement,
closet, alcove, attic, recreation room or garage and are also ideal for
commercial applications. All units are factory assembled, wired and
tested to assure safe dependable and economical installation and oper-
ation.
These units are Category IV listed and may not be common vented with
another gas appliance as allowed by the National Fuel Gas Code.
Assembled at a facility with
