SPMXSE2130S
Spektrum FIRMA 130A Brushless Smart Sensored ESC
Spektrum FIRMA 130A Bürstenloser Smart-
Geschwindigkeitsregler mit Sensor
Variateur ESC SMART Crawler 130 A avec capteur sans
balais FIRMA Spektrum
Spektrum FIRMA 130A brushless con sensori smart ESC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Spektrum SMART FIRMA MARINE SPMXSE2130S and is the answer not in the manual?

Questions and answers

Summary of Contents for Horizon Hobby Spektrum SMART FIRMA MARINE SPMXSE2130S

  • Page 1 ® SPMXSE2130S Spektrum FIRMA 130A Brushless Smart Sensored ESC Spektrum FIRMA 130A Bürstenloser Smart- Geschwindigkeitsregler mit Sensor Variateur ESC SMART Crawler 130 A avec capteur sans balais FIRMA Spektrum Spektrum FIRMA 130A brushless con sensori smart ESC...
  • Page 2 SPMXSE2130S Scan the QR code and select the Manuals and Support quick links from the product page for the most up-to-date manual information. Scannen Sie den QR-Code und wählen Sie auf der Produktseite die Quicklinks Handbücher und Unterstützung, um die aktuellsten Informationen zu Handbücher. Scannez le code QR et sélectionnez les liens rapides Manuals and Support sur la page du produit pour obtenir les informations...
  • Page 3 NOTICE All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC. For up-to-date product literature, visit horizonhobby.com or towerhobbies.com and click on the support or resources tab for this product. Meaning of Special Language...
  • Page 4 Do not attempt disassembly, use with incompatible components or augment product in any way without the approval of Horizon Hobby, LLC. This manual contains instructions for safety, operation and maintenance. It is essential to read and follow all...
  • Page 5: System Specifications

    System Specifications Motor Type Sensored Brushless Constant/Peak 130A | 760A 1/8 Buggy Applications 1/8 Truggy LiPo Cells 2–4S LiPo BEC Output 6V / 7.4V @ 5A Programming Port PRG/FAN Port Wiring Diagram Switch Board On/Off Button Set Button Battery Leads Battery* Smart Wire Solder Tab...
  • Page 6 Throttle Signal Smart Throttle The Spektrum Firma ESC is compatible with Smart ™ Throttle. Smart Throttle combines throttle signals with telemetry data from the ESC on one normal three wire servo connector. Smart Throttle compatible receivers will detect a Smart Throttle ESC and automatically begin to send telemetry information to your transmitter.
  • Page 7 Installation and Wiring 1. Mount the ESC and power button with the included mounting tabs or double-sided foam tape. Select a location to mount the ESC with good ventilation for cooling. 2. Solder the ESC A wire to the A solder tab on the motor;...
  • Page 8 ESC and Transmitter Calibration 1. Begin with the transmitter and receiver binding com- plete. 2. Set your transmitter’s throttle channel to 100% travel and trim to neutral. 3. Turn on your transmitter and connect a battery to the ESC but don’t power it on. 4.
  • Page 9: Button Programming

    Button Programming Power on the transmitter. Connect battery to the ESC and power on the ESC. Hold set key for 1 second. Reset all programming items. Pres and hold the Green LED flashes. set button for 5 seconds. Release the set button to enter programming.
  • Page 10 More Programming Options The programmable items and their options can be found on the included programming card. Use the button pro- gramming, Smart ESC programming box (SPMXCA200) or the SmartLink USB updating and programmer applica- tion to make settings changes. Programming can also be done through Firma programming on specific computer transmitters.
  • Page 11 3. When the Smart logo is visible on the Main Screen of your transmitter, scroll to the Firma Programming page. 4. Follow the on-screen prompts as directed. (Turn wheel all the way to the Right and hold for 5 seconds, then all the way to the Left and hold for 5 seconds.) 5.
  • Page 12: Operation

    7. Once you choose an exit option you will hear the normal startup tones as the ESC reconnects with the 5Pro. Normal throttle control will only be restored after selecting one of the Exit options. IMPORTANT: You can access other transmitter menu functions away from the Firma Programming screen, but you cannot drive your until you Exit the Firma Program- ming screen.
  • Page 13: Programmable Features

    Programmable Features 1. Running Mode 2. Max Reverse Force (%) 3. LiPo Cells 4. Cutoff Voltage 5. BEC Voltage 6. Motor Rotation 7. Punch (Level) 8. Initial Throttle Force (%) 9. PWM Drive Frequency (K) 10. Drag Brake Force (%) 11.
  • Page 15 LED Indicator LED Code ESC turned On, LED indicator Throttle trigger is in the neutral is Off zone ESC is operating in forward, Red LED illuminated reverse or brake Red and Green LED ESC is at full throttle, full brake, illuminated or full reverese LVC protection activated.
  • Page 16: Troubleshooting Guide

    Troubleshooting Guide Problem Error Possible and LED Solution Mode Causes Indicator Battery voltage Verify the bat- Motor won’t is below the tery is charged. operate. LED LVC has been LVC setting. flashes red activated for Verify the ESC once with a non smart ESC settings settings are...
  • Page 17 Verify the motor is not dam- aged; If a motor is damaged it ESC is not get- may still func- ting adequate tion but draw airflow. excessive cur- rent, resulting in over current Motor won’t protection. operate. LED The ESC has flashes green exceeded the Reduce the...
  • Page 18 Verify all wiring Poor wiring connections connection be- are solid and tween the ESC well insulated, and motor. re-flow any cold solder joints. Check for parts rubbing, bent Motor stutters shafts, rusted at start-up. Excessive bearings, tight drag on drive gears, or any- system.
  • Page 19 1-YEAR LIMITED WARRANTY What this Warranty Covers – Horizon Hobby, LLC, (Horizon) warrants to the original purchaser that the product purchased (the “Product”) will be free from defects in materials and work- manship for a period of 1 year from the date of purchase. ...
  • Page 20 THIS WARRANTY IS THE PURCHASER’S SOLE AND EXCLU- SIVE REMEDY. Limitation of Liability – HORIZON SHALL NOT BE LIABLE FOR SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES, LOSS OF PROFITS OR PRODUCTION OR COM- MERCIAL LOSS IN ANY WAY, REGARDLESS OF WHETHER SUCH CLAIM IS BASED IN CONTRACT, WARRANTY, TORT, NEGLIGENCE, STRICT LIABILITY OR ANY OTHER THEORY OF LIABILITY, EVEN IF HORIZON HAS BEEN ADVISED OF THE...
  • Page 21 website at www.horizonhobby.com, submit a Product Support Inquiry, or call the toll free telephone number referenced in the Warranty and Service Contact Information section to speak with a Product Support representative. Inspection or Services – If this Product needs to be inspect- ed or serviced and is compliant in the country you live and use the Product in, please use the Horizon Online Service Request submission process found on our website or call Horizon to...
  • Page 22 Warranty Requirements – For Warranty consideration, you must include your original sales receipt verifying the proof- of-purchase date. Provided warranty conditions have been met, your Product will be serviced or replaced free of charge. Service or replacement decisions are at the sole discretion of Horizon.
  • Page 23: Warranty And Service Contact Information

    Warranty and Service Contact Information Country Contact Horizon Hobby Address Information Purchase Horizon Service servicecenter.ho- Center rizonhobby.com/ (Repairs and RequestForm/ Repair Requests) United 2904 Research Rd. productsupport@ Horizon Product States of Champaign, Illinois, horizonhobby.com. Support America 61822 USA (Product Techni-...
  • Page 24 • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Horizon Hobby, LLC 2904 Research Rd., Champaign, IL 61822 Email: compliance@horizonhobby.com...
  • Page 25: Compliance Information For Canada

    EU Compliance Statement: Firma 130A Brushless 1:8 Scale Smart Sensored ESC (SPMXSE2130S): Hereby, Horizon Hobby, LLC declares that the device is in compliance with the following: EU EMC Directive 2014/30/EU; RoHS 2 Directive 2011/65/ EU; RoHS 3 Directive - Amending 2011/65/EU Annex II 2015/863.
  • Page 26 Instructions for disposal of WEEE by users in the European Union This product must not be disposed of with other waste. Instead, it is the user’s responsibility to dispose of their waste equipment by handing it over to a designated collections point for the re- cycling of waste electrical and electronic equipment.
  • Page 27 ® © 2023 Horizon Hobby, LLC. Firma, the Firma Logo, IC5, EC3, and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC. The Spektrum trademark is used with permission of Bachmann Industries, Inc. All other trademarks, service marks and logos are property of their respective owners.
