OWNERS
AIRSTREAM
MANUAL
INTERSTATE
A MOTORHOME GUIDE

Advertisement

Table of Contents
loading

Related Manuals for Airstream NTERSTATE

Summary of Contents for Airstream NTERSTATE

  • Page 1 OWNERS AIRSTREAM MANUAL INTERSTATE A MOTORHOME GUIDE...
  • Page 2 INTRODUCTION 2007 INTERSTATE The Owners Manual for your new Airstream Motorhome is designed to respond to the most frequent inquiries regarding the operation, function and care of the many systems that make modern motor homing a joy. The Airstream Interstate Motorhome is integrated into a Sprinter Van, designed and manufactured by Daimler/Chrysler.
  • Page 3 Van as a motorhome, however, no information in the Airstream manual should be interpreted as advice or directions to disregard or void the warnings, cautions, or other information contained in the Sprinter’s manuals.
  • Page 4 INTRODUCTION Tire Safety (See pages C-3 through B-11 and the Tire Safety Manual Addendum) Properly maintained tires improve the steering, stopping, traction, and load-carrying capability of your vehicle. Underinflated tires and overloaded vehicles are a major cause of tire failure. Be sure to read the Tire Safety Manual Addendum included with your owner’s packet.
  • Page 5 Van as a motorhome, however, no information in the Airstream manual should be interpreted as advice or directions to disregard or void the warnings, cautions, or other information contained in the...
  • Page 6 INTRODUCTION 2007 INTERSTATE NOTES...
  • Page 7 A. WARRANTY AND SERVICE Warranty Warranty Explanation Service Reporting Safety Defects Maintenance Schedule B. DRIVING Loading Weighing Safety Check List Seat Belts Trailer Towing & Driving Tips Weighing the Motorhome C. SPRINTER VAN Component Identification Tire/Wheels Changing a Tire Installing a Wheel D.

  • Page 8: Warranty And Service

    first. In order to obtain cov- erage under this Limited Warranty, you must notify an authorized Airstream dealership or Airstream of the warrantable defect no later than ten (10) days following expiration of this Limited Warranty. Airstream’s obligation to repair or replace defective materials or workmanship is the sole obligation of Airstream under this Limited Warranty.

  • Page 9: Disclaimer Of Incidental And Consequential Damages

    The entire Limited Warranty provided by Airstream is set forth herein. Airstream will not be responsible for any additional representations or warranties made by any person or entity other than Airstream, and Airstream’s obligations are solely as set forth in the terms and conditions of this Limited Warranty.

  • Page 10: Warranty Explanation

    When you receive your Limited Warranty file it for safekeeping. Upon proof of purchase date to any Airstream Dealer Service Center, defects in materi- als or workmanship will be repaired or replaced without cost to the owner for a period of thirty six (36) months from the original purchase date, or 36,000 miles (57,937 kilome- ters), whichever occurs first.
  • Page 11 Paint and appearance items that show imperfections, damage to interior and exterior surfaces resulting from abrasion, collision or impact, and broken window glass is not covered by the Airstream Limited Warranty and should be brought to the attention of your Airstream dealer at the time of delivery and during pre-delivery inspection.
  • Page 12 When you take delivery of your new motorhome you will receive a complete checkout. Please contact your dealer if you need service. Major service under your Airstream Limited Warranty is available through our nationwide network of Airstream Dealer Service Centers.

  • Page 13: Reporting Safety Defects

    If you believe that your vehicle has a defect, which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Airstream, Inc. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
  • Page 14 WARRANTY AND SERVICE EVERY YEAR or 12,000 miles LP Tank Clean, neutralize and coat terminals with petroleum jelly. Seams Check and reseal, windows, lights and vents if necessary. Reseal with Bostik urethane sealant or equivalent as needed. APPLIANCES Appliances have maintenance schedules and advice in their respective Owners/ Operation Manuals.
  • Page 15 WARRANTY AND SERVICE MAINTENANCE RECORDS DATE DEALER SERVICE PERFORMED DATE DEALER SERVICE PERFORMED A - 8...

  • Page 16: Weight Distribution

    DRIVING LOADING Below is a sample of the weight information chart provided in all Airstream vehicles. This information can be found in your vehicle on the back of a wardrobe door about 60” up from the floor. MOTORHOME WEIGHT INFORMATION VIN OR SERIAL NUMBER GVWR (GROSS VEHICULAR WEIGHT RATING) IS THE MAXIMUM PERMISSABLE WEIGHT OF THIS FULLY LOADED MOTORHOME.

  • Page 17: Safety Checklist

    SAFETY CHECK LIST Your Airstream motorhome should be given a thorough safety check before a trip. Regular use of the following list will provide safe operation of your motorhome and will help you spot any malfunctioning equipment and correct the problem as soon as possible.

  • Page 18: Seat Belts

    DRIVING 12. Check that front passenger’s seat is locked in position - both fore and aft adjust- ment and swivel mechanism. 13. The freedom of movement of the brake and accelerator pedals must not be impaired in any way 14. Check rear view mirrors adjustment, inside and outside. Adjust curtains if neces- sary for maximum visibility.

  • Page 19: Trailer Towing And Driving Tips

    Follow the guidelines below carefully to assure safe trailer operation. Ask your authorized sprinter or Airstream dealer if you require an explanation of informa- tion contained in the sky.
  • Page 20 Vehicles should be properly equipped for towing trailers. Information on trailer hauling capabilities and special equipment required may be obtained from your Airstream dealer. Loading a Trailer When loading a trailer, you should observe that neither the permissible GTW, nor the GVWR are exceeded.
  • Page 21 Please consider us- ing a trailer sway control system. For further information, see your authorized Sprinter or Airstream dealer. Towing a Trailer There are many different laws, including speed limit restrictions, having to do with trailer towing.
  • Page 22 DRIVING If the trailer has electric brakes, start your vehicle and trailer moving slowly, and then ap- ply only the trailer brake controller by hand to be sure the brakes are working properly. When towing a trailer, check occasionally to be sure that the load is secure, and that lighting and trailer brakes (if so equipped) are functioning properly.
  • Page 23 Tracking On a two-lane road cars will be lining up behind you because you travel at a lower speed. It is both courte- ous and sensible to signal, pull onto the shoulder, and let them pass. The BRAKE CONTROLLER (if so equipped) is activated when you apply the brakes of the tow vehicle.
  • Page 24 DRIVING briefly applying the trailer brakes with your manual control will help eliminate sway. WARNING : When stopping on a hill or slope, leaving your tow vehicle in gear is not enough for standstill safety. CHOCK THE TRAILER WHEELS to he double sure.

  • Page 25: Towing Your Motorhome

    DRIVING TOWING YOUR MOTORHOME The most common equipment is called “reach under hooks”. These allow the tow operator to lift on the front suspension of your motorhome without damaging the bumper or other body parts. Another choice is a wheeled dolly. In these, the front tires sit in a cradle supported by its own wheels.
  • Page 26 DRIVING Front Axle GAWR GVWR SCALE WEIGHT ___________ ___________ STEP 1 STEP 2 Front Axle GAW INDIVIDUAL WHEEL POSITION WEIGHT ___________ STEP 4 Left Front Wheel Position Calculated ___________ Right Front Wheel Position Step 1 minus Step 4 GAWR = Gross Axle Weight Rating GVWR = Gross Vehicle Weight Rating GCWR = Gross Combination Weight Rating Rear Axle GAWR...

  • Page 27: Sprinter Van

    Component Identification The Airstream Interstate Motorhome is integrated into a Sprinter Van, designed and manufactured by Daimler/Chrysler. Operation of the Sprinter, its engine, power train, and other related components are discussed in the Sprinter Operator’s Manual and other literature provide by Daimler/Chrysler. As a point of reference, those systems discussed in this literature are warranted by Daimler/Chrysler or their suppliers.
  • Page 28 Driving light system including lights, switch and harness Driver’s and passenger’s seat skirting Floor Mats Finish on the center console switch base. Airstream removes, send out for finish and reinstalls. Living Quarters: Interior furniture, wall panels to the rear of the cab seats.
  • Page 29 Van as a motorhome, however, no informa- tion in the Airstream manual should be interpreted as advice or directions to disregard or void the warnings, cautions, or other information contained in the Sprinter’s manuals.

  • Page 30: Proper Tire Inflation

    SPRINTER VAN PROPER TIRE INFLATION The level of air in your tires affects your vehicle’s overall performance. Not even the highest quality tire will perform well if it’s not inflated properly. The correct pressure varies from vehicle to vehicle and depends in part upon driver preference. Each vehicle has a recommended inflation pressure, usually found on a placard on the door section, door post, glove door, or fuel door.
  • Page 31 TIRES and WHEELS (partially excerpted from the Sprinter Van Operator’s Manual) Check tires regularly for even tread wear; tread depth (note legal requirements) and signs of external damage. Use only wheels and tires of the same size, make and pattern. Do not install tires that are not approved for the size and type of wheel installed on the vehicle itself.
  • Page 32 SPRINTER VAN Changing the Tire (partially excerpted from the Sprinter Van Operator’s Manual) If you get a flat tire while driving, gradually decrease your speed. Hold the steering wheel firmly and slowly move to a safe place on the side of the road. The pressure of the spare wheel always has to be checked regularly (at least after every tenth time at the filling station).

  • Page 33: Using The Jack

    Changing the Tire (continued) WARNING : do not change wheels on either a steep uphill or downhill grade. The vehicle may begin to move and fall from the jack, which could cause personal injury and property damage. SPARE WHEEL LOCATION The spare tire on the Mid Bath models is located as explained in the Dodge Sprinter Manual.

  • Page 34: Installing A Wheel

    SPRINTER VAN INSTALLING A WHEEL WARNING : different wheel bolts are required for pressed steel and light alloy wheels. Using incorrect wheel lug bolts for the wheels may result in dam- age to the vehicle or loosening of the wheels. This could cause an accident and personal injury.

  • Page 35: Tire Rotation

    TIRE ROTATION Front and rear tires perform different jobs and can wear differently depending on the types of roads driven, your driving habits, etc. To obtain the longest tire life you should INSPECT AND ROTATE your tires regularly. Many automotive dealers and tire dealers will perform a free tire inspection to look for uneven or abnormal tire wear.
  • Page 36 SPRINTER VAN TIRE SUPPORT Since motorhomes may sit for long periods it is important to properly support the tires if blocks are used for leveling. Extreme caution must be taken to ensure that the tires are fully supported when us- ing blocks to level motorhomes and/or RV’s.
  • Page 37 INCORRECT One tire or a portion of one tire is supporting the full load. Duals SPRINTER VAN Portion of two tires are supporting the full load. Singles CAUTION : Tires incorrectly supported, as shown above, may be damaged which could lead to casing failure resulting in serious injury or property damage. If, on previ- ous occasions, the tires have been incorrectly supported, a hidden damage may be present.

  • Page 38: Smoke Alarm

    CAMPING SAFETY Emergency Exit There are three avenues of escape from the motorhome in the event of an emergency, the driver’s and passenger doors, and the side cargo door. As always, safety should be one of your top priorities. Make sure you, and everyone traveling with you, can operate these doors and exit rapidly without light.

  • Page 39: Maintenance

    CAUTION : BEFORE USING THE ALARM HUSH FEATURE, IDENTIFY THE SOURCE OF THE SMOKE AND BE CERTAIN A SAFE CONDITION EXISTS. FLASHING L.E.D. LIGHT: This smoke detector is equipped with a flashing red indica- tor light. The light is located under the test button and will flash every 30-40 seconds to indicate that the smoke detector is receiving power.

  • Page 40: Good Safety Habits

    CAMPING CLEANING YOUR DETECTOR: To clean your detector remove it from the mounting bracket as outlined in the begin- ning of this section. You can clean the interior of your detector (sensing chamber) by using your vacuum cleaner hose and vacuuming through the openings around the perimeter of the detector.

  • Page 41: What To Do When The Alarm Sounds

    WHAT TO DO WHEN THE ALARM SOUNDS: • Leave immediately by your escape plan. Every second counts, so don't waste time getting dressed or picking up valuables. • In leaving, don't open any inside door without first feeling its surface. If hot, or if you see smoke seeping through cracks, don't open that door! Instead use your alternate exit.

  • Page 42: What Is Carbon Monoxide

    CAMPING THIS CARBON MONOXIDE ALARM IS NOT Designed to detect smoke, fire or any gas other than carbon monoxide. To be seen as a substitute for the proper servicing of fuel-burning appliances. To be used on an intermittent basis, or as a portable alarm for spillage of combustion products from fuel-burning appliances.

  • Page 43: Symptoms Of Carbon Monoxide Poisoning

    The following conditions can result in potentially dangerous CO situations. 1. Excessive spillage or reverse venting of fuel burning appliances caused by outdoor conditions, such as: Wind direction and/or velocity: including high gusts of wind. Heavy air in the vent pipes (cold/humid air with extended periods between cycles). Negative pressure differential resulting from sue of exhaust fans.

  • Page 44: Operation

    The failure of any circuit component will cause the detector to display a continuous orange LED fault light and a short beep indicating failure. If this occurs, immediately contact your dealer or Airstream Customer Service for the name of the nearest detec- tor service center.

  • Page 45: Extended Stay

    Booklets are available which list these dumping stations. When you stop for the night, your Airstream motorhome is built to be safely parked in any spot that is relatively level and where the ground is firm. Your facilities are with you.

  • Page 46: Effects Of Prolonged Occupancy

    CAMPING EFFECTS OF PROLONGED OCCUPANCY Your motorhome was designed primarily for recreational use and short-term occu- pancy. If you expect to occupy the motorhome for an extended period, be prepared to deal with condensation and the humid conditions that may be encountered. The relatively small volume and tight compact construction of modern recreation vehicles mean that the normal living activities of even a few occupants will lead to rapid mois- ture saturation of the air contained in the trailer and the appearance of visible moisture,...

  • Page 47: About Molds

    ABOUT MOLDS What are molds? Molds are microscopic organisms that naturally occur in virtually every environment, indoors and out. Outdoors, mold growth is important in the decomposition of plants. Indoors, mold growth is unfavorable. Left unchecked, molds break down natural ma- terials, such as wood products and fabrics.
  • Page 48 CAMPING 1. You must have a plentiful supply of propane gas as the heat from the furnace warms the motorhome and keeps the fresh water lines and tank from freezing. 2. If your stay is longer than overnight, you should endeavor to have 120-volt elec- tricity available.
  • Page 49 The exterior of your Airstream Interstate motorhome has been painted by Carrera Designs, a company specializing in custom recreational vehicles, with a Sherwin- Williams automotive finish. Carrera Design provides samples of the paint for minor repairs and a use and care brochure with each motorhome as it leaves their facility. The brochure has a paint code sticker containing paint information.
  • Page 50 EXTERIOR How to Care for Your RV Finish Keeping your RV looking its best at all times involves keeping the paint finish clean and in good condition. This means periodic washing and polishing, as well as getting the paint finish repaired as soon as possible when the paint is damage or affected in anyway.
  • Page 51 PRECAUTIONS Careful maintenance for the first 60 days after the paint and clear coat are applied will ensure a long-lasting durable finish. Do not wax or polish for the first 60 days. First 30 days PARKING: Avoid parking under trees or near ocean salt spray. Ice or snow should not be scraped from the painted service: BRUSH OFF! If a motorhome sets more than 24 hours, remove any protective covering (bra) while not being driven.
  • Page 52 Push and hold the switch to open the holding tank dump valve. 5. Fiberglass Running Boards and fender skirts are installed by Airstream. 6. Refrigerator exhaust vent draws air from the refrigerator access door vent across the refrigera- tor-cooling unit.
  • Page 53 Curbside Exterior Features, Rear Bath NOTE: This is a basic explanation of the location and function of exterior features. More in depth explanations of certain feature’s care and maintenance is include in this manual in other sections. 1. Water Fill w/Lock is used to fill the fresh water tank. Use only clean fresh potable water.
  • Page 54 A portable satellite dish can also be used in the cable connection. 5. Fiberglass Running Boards and fender skirts are installed by Airstream. 6. Refrigerator exhaust vent draws air from the refrigerator access door vent across the refrigera- tor-cooling unit. Please keep free from obstructions.
  • Page 55 Curbside Exterior Features, Mid Bath NOTE: This is a basic explanation of the location and function of exterior features. More in depth explanations of certain feature’s care and maintenance is include in this manual in other sections. 1. Water Fill w/Lock is used to fill the fresh water tank. Use only clean fresh potable water.
  • Page 56 EXTERIOR PATIO AWNING OPERATION NOTICE: The sliding entrance door must be shut to extend the awning, without this happening the arm and the opening cover will contact the door. Once the awning is extended the sliding door will open and shut fine without any interference. 1.
  • Page 57 E. Unroll the awning completely moving the support arms each time when necessary. F. To use the carport position, drive ground stakes through the holes in the carport CAUTION foot and into the ground for support. . GROUND STAKES WILL NOT PREVENT THE AWNING FROM MOVING IN THE WIND! G.

  • Page 58: Periodic Maintenance

    EXTERIOR CARE OF FABRIC A. VINYL FABRIC. Mildew will not form on the awning material itself, but may form on the dust allowed to accumulate on the canopy. A mild detergent (soap & water) will keep your awning looking new. Once cleaned make sure the awning is rinsed thoroughly and is dried before storing.
  • Page 59 The interior of your Airstream motorhome has been designed to take a limited amount of space and provide you with all the comfort, convenience, durability and appear- ance possible. An understanding of the operational procedures and maintenance techniques of the interior appointments will add to your pleasures, as well as to the long life of your motorhome.
  • Page 60 If a substance is found on the coating that cannot be removed by normal washing pro- cedures, Airstream recommends using DX 330 Acryli-Clean made by PPG Industries. Follow all directions and warnings on the product container. Acryli-Clean should be used by trained personnel only, using the proper equipment under controlled condi- tions.

  • Page 61: Lpg System

    LPG service center or Airstream Service Center. CAUTION : Moisture in the LPG tank will cause a malfunction of the regulator in controlling proper pres- sure.

  • Page 62: Basic Rules For Safety

    PLUMBING LPG Regulator The LPG regulators used on Airstream motorhomes are designed for low-pressure ser- vice, with a normal outlet pressure setting of 11.5 inches water column. Only personnel trained in the proper procedures, codes, standards, etc., should service regulators.
  • Page 63 LP gas regulators must always be installed with the diaphragm vent facing downward. Regulators that are not in compartments have been equipped with a protective cover. Make sure that regulator vent faces downward and that cover is kept in place to minimize vent blockage that could result in excessive gas pressure causing fire or explosion.

  • Page 64: Water System - Self-Contained

    PLUMBING WATER SYSTEM - SELF-CONTAINED The fresh water system consists of a city water hook up, fresh water tank fill, fresh water tank and drain valve, water-pump, pump filter, hot and cold water lines, water heater, fresh water line drain valves, and faucets. To operate the system: Turn the water heater by-pass valves to normal flow position.

  • Page 65: Water Pump And Strainer

    WATER PUMP AND STRAINER Manufacturer: Shur-Flo 1740 Markle Street Elkhart, Indiana 46514 Phone: 219-294-7581 The water pump and strainer are located inside the rear cargo door on the Rear Bath Model. The Mid Bath model has the pump under the galley and can be ac- cessed by opening the lower galley door.

  • Page 66: City Water Hookup

    PLUMBING CITY WATER HOOKUP Use a high-pressure hose of at least ½ “ diameter. It should be a tasteless, odorless and non- toxic hose designed for RV use. The city water inlet is a standard garden hose thread. We suggest you carry two lengths of hose. 3.

  • Page 67: Galley Faucet

    GALLEY FAUCET MODEL 67315C Manufacturer: United States Canada Moen Incorporated Moen Inc. 25300 Al Moen Drive 2816 Bristol Circle North Olmstead, OH. 44070-8022 Oakville, Ontario L6H5s7 www.moen.com For US customer service, warranty, and a local parts outlets contact Moen at 1-800- BUY-MOEN (289-6636).
  • Page 68 PLUMBING GALLEY FAUCET SERVICE CAUTION : Always turn water OFF before remov- ing existing faucet or disassembling the valve. Open faucet handle to relieve water pressure and ensure that complete water shutoff has been accomplished. 1. Remove red/blue plug bottom (3) from front of lever handle, remove screw (2) and lever handle (1).

  • Page 69: Drain Valve Locations

    PLUMBING DRAIN VALVE LOCATIONS The fresh water system has three drain valves. On the Rear Bath the drain valves are accessible by opening the rear cargo doors. There are two low point water line drain valves and the fresh water tank drain valve located in this area.

  • Page 70: Troubleshooting

    Ann Arbor, MI 48103 313-769-6000 The RV toilet in your Airstream is a design that has been used for many years. In normal use, when you are hooked up to city water, both pedals are depressed together. This dumps the sewage and flushes fresh water down the side of the bowl. Water will continue to run into the bowl for a short time after the pedals are released.

  • Page 71: Maintenance

    PROBLEM: Foot pedal operates harder than normal or the blade sticks. REMEDY: a. Apply a light film of Silicone spray to blade. b. Check closet bolt tightness. If closet bolts are over tightened, the mechanism may be distorted. PROBLEM: Bowl will not hold water; i.e., water leaks from bowl down into the holding tank.

  • Page 72: Storage And Winterizing

    Twice a year, or after a long storage period, we suggest you take your unit into your Airstream dealer for a check-up and cleaning of the gas operated appliances. The main consideration in winterizing is to guard against freezing damage to the hot and cold water systems, the waste drain system (including the traps), the waste hold- ing tanks, the water heater and the battery.
  • Page 73 STORAGE AND WINTERIZING (continued) For additional winterizing protection, add non-toxic antifreeze (approved for drinking water systems) to your water lines using the following procedure: 1. Reconnect all lines except the hose to the pump inlet port. Close all drain valves (See Step 3) *2.

  • Page 74: Drain And Waste System

    PLUMBING DRAIN AND WASTE SYSTEM The drain and waste system of your motorhome includes either a combina- tion gray/black waste holding tank (Rear Bath) or separate grey and Black tanks (Mid Bath) made from molded plastic. The tanks enables you to use the toilet, sink, and wet bath drain for several days away from disposal facilities.
  • Page 75 PLUMBING Drain Systems Cleaning There are many deodorizers on the market in tablet, liquid, and powder form. These not only combat odor, but also stimulate the bacteria that works to dissolve the solids in your tank. Picking a deodorizer with lubricating qualities will help ease the slide valve operation.

  • Page 76: Electrical Systems

    ELECTRICAL SYSTEMS 12-VOLT SYSTEM The major portion of electrical power in your Airstream is 12-volt. The 12-volt current powers just about every thing except for the air conditioner and microwave oven. The refrigerator’s electronic energy selection is also powered by 12 volt.

  • Page 77: Power Circuits

    12V POWER CIRCUITS The current in the converter system is 12 volts direct current (12VDC) negative grounded. Power sources that supply 12VDC current to the system are House Battery and Converter. These power sources above are electrically connected to the 12-volt distribution fuse panel that distributes current to interior branch circuits.

  • Page 78: Converter Cooling System

    ELECTRICAL SYSTEMS CONVERTER COOLING SYSTEM The 7300 electronic fan cooling system is the key to long life and trouble-free opera- tion. The fan is never on more than required to cool electronic components in the converter. You may never hear the fan operate. Converter The converter transforms 120-volt alternating current (AC) into 12-volt direct current (DC).
  • Page 79 12-Volt Operation The only thing you have to do is make sure the house battery does not run down. In normal usage, there isn’t any problem, since you would normally be plugged into a 110 volt shoreline at night or when camping. When you’re plugged into city power or running the generator, with the battery disconnect turned to “USE”, the con- verter charges the battery and carries much of the load.

  • Page 80: Monitor Panel

    The monitor system has been calibrated at the fac- tory and should never need another calibration. If you feel the system is not operating correctly, please contact CATCON Products or a local Airstream dealer. The following instructions are provided for qualified service technicians.
  • Page 81 Interstate 12-Volt circuit diagram 12 Volt Fuse Panel CIRCUIT 1 REFRIGERATOR (MID BATH) UNUSED (REAR BATH) CIRCUIT 2 SUB WOOFER (MID BATH) UNUSED (REAR BATH) CIRCUIT 3, 20 AMP, PINK (2) CURBSIDE READING LIGHTS FURNACE CLOSET LIGHT COOK TOP IGNITION CURBSIDE LOUNGE FLUORESCENT LIGHT GALLEY LOCKER FLUORESCENT LIGHT SEWER LIGHT...
  • Page 82 ELECTRICAL SYSTEMS TV ANTENNA Manufacturer: Winegard Company 3000 Kirkwood Street Burlington, Iowa 52601 Phone: 800-843-4741 Raising Antenna to Operating Position Turn elevating crank in “UP” direction until some resistance to turning is noted. Antenna is now in operating position. Check to make sure switch on front TV jack is on. Rotating Antenna Make sure antenna is in “UP”...
  • Page 83 Maintenance Lubrication To lubricate the elevating gear apply a liberal amount of silicone spray lubricant to the elevating gear with the lift in the down position, then run the lift up and down a few times to distribute lubricant over gears. Lubricating Rotating Gear Housing In the event that rotating the antenna becomes difficult, lubricating the bearing surface between the rotating gear housing and the base plate can restore normal operation.
  • Page 84 Standard Package - The radio and the two rear speakers are supplied and installed by Airstream. The dash speakers are supplied and installed by the chassis manufacturer. Upgrade package - Airstream removes the standard chassis dash speakers and re- places them with upgraded speakers and adds a powered subwoofer with the Audio Upgrade option.
  • Page 85 Entertainment System Pictured below are several outlets located inside the Entertainment Cabinet on the Rear Bath and inside the roof locker on the Mid Bath. Their function is listed below. A. INTERIOR 110-VOLT OUTLET provides power to 110-volt appliances such as televisions, electronic phones, and other devices as you may choose.
  • Page 86 ELECTRICAL SYSTEMS • The iPod starts playback from where it has been previously paused. • Note: While the iPod is connected to the dash receiver via the adapter connection cable, all the buttons on the iPod do not function. • The text information of the tracks, categories, etc.

  • Page 87: 110-Volt Power

    110-VOLT POWER The 110-volt system works very much like your home. When you’re plugged into city power, or start your generator, power is supplied to the 110-volt circuit breakers. The circuit breakers are located on the converter, accessed by opening the brown con- verter door.
  • Page 88 ELECTRICAL SYSTEMS 110-Volt Circuit Diagram 20 20 TEST 1 2 3 4 5 1 2 3 4 MID BATH REAR BATH Circuit 1. 30 Amp, Main Circuit 1. 30 Amp, Main Circuit 2. 20 Amp, AES Circuit 2. 20 Amp, Converter Circuit 3.
  • Page 89 GENERATOR IMPORTANT NOTE: MAKE SURE TO READ AND UNDERSTAND THE GENERATOR OWNER’S MANUAL BEFORE OPERATING THE GENERATOR. Observe all operating instructions and warnings as well as all recommended maintenance schedules and procedures. The onboard generator makes your RV fully self-contained. It allows you access to 120 volts when there is no shore power available, but keep in mind that carbon monoxide is deadly! NEVER sleep in the RV with the generator running! Before you start and use the generator inspect the exhaust system.

  • Page 90: Air Conditioner

    Note: Review the air conditioning literature supplied in your Owner’s Packet before proceeding. The roof air conditioner used on Airstream motorhomes is one of the most popular on the market today. In your Owner’s Packet is a set of literature covering all operat- ing and maintenance instructions.
  • Page 91 120-volt shoreline. Operating instructions are located in your Owners Packet. If they should become misplaced new literature can be ordered direct from the manufacturer or your Airstream dealer. The manufacturer also offers a detailed service guide for your furnace.
  • Page 92 APPLIANCES REFRIGERATOR WARNING : Most LP gas appliances used in recreational vehicles are vented to the outside of the vehicle. Check the exterior areas of your unit for clearance in these areas. Turn all gas operated appliances off when parked close to a gasoline pump, it is possible that gasoline fumes could enter these types of appliances and ignite from the burner flame or automatic igniters, CAUSING A FIRE OR AN EXPLOSION.

  • Page 93: Microwave Oven

    fire or explosion causing property damage, personal injury, or death. The manual should be reviewed prior to operating the appliance. If this manual has not been provided with your motorhome, contact the manufacturer listed at the top of the page or Airstream Customer Service to obtain it. APPLIANCES MICROWAVE OVEN Only federally certified technicians are permitted to service microwave ovens.

  • Page 94: Water Heater

    APPLIANCES WATER HEATER WARNING : Most LP gas appliances used in recreational vehicles are vented to the outside of the vehicle. Check the exterior areas of your unit for clearance in these areas. Turn all gas operated appliances off when parked close to a gasoline pump, it is possible that gasoline fumes could enter these types of appliances and ignite from the burner flame or automatic igniters, CAUSING A FIRE OR AN EXPLOSION.

  • Page 95: High Volume Roof Vent

    HIGH VOLUME ROOF VENT Manufacturer: FAN-TASTIC VENT CORP. 2083 S. Almont Ave. Imlay City, MI 48444 1-810 724 3818 1-800 521 0298 The optional high-volume roof vent system is designed to quickly exhaust stale, hot air and draw in fresh air. It’s great to use when the outside temperature really doesn’t call for air conditioning, but heat has built up in your coach.

  • Page 96: Specifications

    SPECIFICATIONS Coach NOTE: The weights and measurements in this manual are derived from the best information available at time of this manuals publishing. Please refer to the weight information label placed in your unit and your chassis Owner’s Manual for weights specific to your RV.
  • Page 97 CHASSIS (continued) Gross Axle Weight Rating (GAWR) is a maximum permissible weight on an axle. Gross Trailer Weight (GTW) is a maximum permissible trailer weight to be towed. Trailer Tongue Weight Rating (TWR) is the maximum permissible weight of the trailer tongue.
  • Page 98 INDEX Air Conditioner ... I-1 Alignment ... C-3 Antenna ... H-7, H-11 Appliances... I-1 Bathroom...F-1 Battery Disconnect... H-1 Bottled Gas ... G-1 Breaker Panel, 110-Volt... H-13 Cab Seats... B-2 Cabinets ... B-2, F-1 Camping ... D-1 Capacities... J-1 Carbon Monoxide Alarm ...A-7, D-4 Caution ...
  • Page 99 Water Hookup ... G-4, G-6 Water Pump ... G-5 Water Strainer ... G-5 Water System ... G-4 Water Valves ... G-4, G-8 Weighing ...B-1, B-11 Wet Bath...F-1 Winterizing ... G-12 Winter Traveling ... D-11 Airstream Interstate Owner’s Manual © Airstream, Inc. 2007...
