  • Page 1 AIRSTREAM AN AMERICAN LEGEND LAND YACHT MOTORHOME OWNERS MANUAL 2006...
  • Page 3 INTRODUCTION The Owners Manual for your new Airstream Motorhome is designed to respond to the most frequent inquiries regarding the operation, function and care of the many systems that make modern motor homing a joy. Airstream realizes our customers possess varying degrees of expertise in the area of repairing and maintaining the appliances in their motorhome.

  • Page 4: Table Of Contents

    DRIVING Black Tank Flush Exterior Water Service Loading Faucets Weighing Toilet Safety Check List Storage and Winterizing Airstream Dash Controls Drainage System Motorhome Towing & Driving Tips Weighing the Motorhome ELECTRICAL CHASSIS Battery Control Center 12-volt system Component Identification 12-Volt Wiring Diagrams...

  • Page 5: Warranty And Service

    30,000 miles, whichever comes first, and the application date of all warranties is that indicated on the owner's Limited Warranty. Defects in items covered under this Warranty will be corrected without cost upon the return, at the owner's expense, of the motorhome or defective part to an authorized Airstream dealer.

  • Page 6: Warranty

    Factory Service Center at the owner's expense. DEALER REPRESENTATION EXCLUDED The full extent of the basic Airstream Limited Warranty is set forth in detail in the folder, and in the explanation of the basic Airstream Limited Warranty covered in the Airstream Motorhome Owner's Manual.

  • Page 7: Warranty Explanation G

    CHANGES IN DESIGN Airstream Inc. reserves the right to make changes in design and improvements upon its product without imposing my obligation upon itself to install the same upon its products theretofore manufactured.
  • Page 8 Any warranty forms from these manufacturers should be completed promptly, preferably at time of purchase. Your motorhome chassis is pre-checked by its manufacturer before delivery to Airstream. All service to the chassis must be performed by the manufacturer according to the manufacturer's warranty and service policies.

  • Page 9: Service

    When you take delivery of your new motorhome you will receive a complete checkout. Please contact your dealer if you need service. Major service under your Airstream Limited Warranty is available through our nationwide network of Airstream Dealer Service Centers. An up-to-date list of Dealer Service Centers has been provided with your new motorhome.

  • Page 10: Maintenance Schedule

    WARRANTY AND SERVICE MAINTENANCE SCHEDULE Warning FAILURE TO MAINTAIN YOUR COACH CAN CAUSE PREMATURE AND UNEXPECTED PARTS BREAKAGE AND/OR ERRATIC OPERATION THAT MAY BE HAZARDOUS. SERIOUS INJURY COULD RESULT FROM FAILURE TO HEED THIS WARNING. Note: See chassis and appliance manufacturer's literature for further information. EVERY 1,000 MILES OR 60 DAYS Escape Window Check operation of latches and upper hinge.
  • Page 11 WARRANTY AND SERVICE MAINTENANCE RECORDS DATE DEALER SERVICE PERFORMED...
  • Page 12 WARRANTY AND SERVICE NOTES...

  • Page 13: Driving

    DRIVING LOADING Below is a sample of the weight information chart provided in all Airstream vehicles. This information can be found in your vehicle on the back of a wardrobe door. See specification section in this manual for weights and term definitions.

  • Page 14: Safety Check List

    DRIVING SAFETY CHECK LIST Your Airstream motorhome should be given a thorough safety check before a trip. Regular use of the following list will provide safe operation of your motorhome and will help you spot any malfunctioning equipment and correct the problem as soon as possible. The list is to help you and may not be all-inclusive.
  • Page 15 DRIVING INTERIOR CHECK LIST (BEFORE DRIVING OFF) 13. Check rear view mirror adjustment, inside and outside. Adjust curtains if necessary for maximum visibility. 14. Secure children in a Federally Approved Child Restraint Device. 15. Fasten your lap belts. 16. Check that step light goes out and that electric step has retracted. SAFETY SEAT BELTS In the forward driver's area of the motorhome, safety seat belts are provided for the use of the driver and the right front passenger.
  • Page 16 DRIVING DASH SWITCHES • Door Lock -The main door can be locked or unlocked from the drivers seat. Remember to hide an extra door key on the exterior in case of unexpected battery failure. • Auxiliary Start - The auxiliary start switch is intended to be used if the engine battery becomes too discharged to turn the engine over.
  • Page 17 GCWR. Vehicles should be properly equipped for towing trailers. Information on trailer hauling capabilities and special equipment required may be obtained from your Airstream dealer. To assist in attaining good handling of the vehicle/trailer combination it is important that the tongue load be maintained at approximately 10% of the loaded trailer weight, but not to exceed the hitch rating.
  • Page 18 DRIVING Procedure for Weighing A RV Vehicle should be weigh loaded as you normally travel. 1. Fill in first row from Specification Section of this manual. 2. Weigh vehicle as shown in row 2 (Scale Weight) and fill in blanks. 3.

  • Page 19: Chassis

    CHASSIS The Airstream motorhome is built on a chassis designed for motorhomes. Operation of the engine and other related components is discussed in the Chassis Owners and Drivers Manual supplied with each coach. If repairs are needed it can be difficult to determine which parts are the chassis, and which are Airstream's responsibility.

  • Page 20: Dash/Air Conditioner/Heater

    This service locater assistance can be especially helpful if you are traveling and an Airstream dealer is unavailable or a considerable distance away.
  • Page 21 Your chassis Owner’s Manual contains important cautions and information on tires and should be reviewed and followed for your safety. The tires installed on your Airstream motorhome are engineered to provide a proper balance of performance characteristics for normal vehicle operation.
  • Page 22 1000 miles during a trip for any signs of wear or possible failure. Please contact your dealer or Airstream Customer Service if you have any questions on the use of this equipment.
  • Page 23 CHASSIS TIRE CHANGING (cont) When removing a steel wheel rim to change a tire, loosen all wheel nuts approximately flush with end of stud, then tap clamp ring to loosen rim. Do not remove nuts until clamp rings are free or clamp ring may fly off of stud.
  • Page 24 CHASSIS TIRE ROTATION Front and rear tires perform different jobs and can wear differently depending on the types of roads driven, your driving habits, etc. To obtain the longest tire life you should INSPECT AND ROTATE your tires regularly. (See Tire Rotation Illustration below). Many automotive dealers and tire dealers will perform a free tire inspection to look for uneven or abnormal tire wear.
  • Page 25 CHASSIS TIRE SUPPORT Since motorhomes may sit for long periods of time it is important to properly support the tires if blocks are used for leveling. The following information is provided by the Michelin Technical Group. Extreme caution must be taken to ensure that the tires are fully supported when using blocks to level motorhomes and/or RV's.
  • Page 26 CHASSIS INCORRECT One tire or a portion of one tire is supporting the full load. Portion of two tires are supporting the full load. CAUTION : Tires incorrectly supported, as shown above, may be damaged which could lead to casing failure resulting in serious injury or property damage. If, on previous occasions, the tires have been incorrectly supported, a hidden damage may be present.
  • Page 27 CHASSIS TIRE INFLATION INFORMATION Warning: Your vehicle is equipped with a tire that is an all-steel radial. All- steel radial tires utilize steel cords in the sidewalls, and also require increased inflation pressures. Has such, they cannot be treated like normal light truck tires. Personnel trained, supervised and equipped according to Federal Occupational Safety and Health Administration (OSHA) regulations must perform tire service, including adjusting tire pressure.

  • Page 28: Electric Step

    CHASSIS ELECTRIC STEP (KWIKEE STEP SERIES 28) Manufacturer: Kwikee Products Company Division of Ashton Corporation P.O. Box 638 Drain, Oregon 97435 Phone: 503-836-2126 The step is easy and convenient to operate. Just inside the main door is a wall switch for the step. When traveling, leave the switch in the "ON"...
  • Page 29 CHASSIS MAINTENANCE AND LUBRICATION Clean all mud, salt, and road grime from step before lubricating. Lubricate all moving parts (bearings, pivot points, slides, clevis pin, and drive linkage ball) every 30 days with a good quality moisture and heat resistant penetrating grease. Kwik-Lube Spray Grease is specially formulated to lubricate Kwikee Electric Steps and is recommended for lubricating all moving parts.
  • Page 30 CHASSIS NOTES C-12...

  • Page 31: Camping

    CAMPING SAFETY As always, safety should be one of your top priorities. Make sure you, and everyone traveling with you, can operate the main door and exit window rapidly without light. Warning: The roadside rear window is designed as an escape window. To escape, pull in on the two red latches at the bottom.
  • Page 32 CAMPING CAUTION : BEFORE USING THE ALARM HUSH FEATURE, IDENTIFY THE SOURCE OF THE SMOKE AND BE CERTAIN A SAFE CONDITION EXISTS. FLASHING L.E.D. LIGHT: This smoke detector is equipped with a flashing red indicator light. The light is located under the test button and will flash every 30-40 seconds to indicate that the smoke detector is receiving power.
  • Page 33 CAMPING CLEANING YOUR DETECTOR: To clean your detector remove it from the mounting bracket as outlined in the beginning of this section. You can clean the interior of your detector (sensing chamber) by using your vacuum cleaner hose and vacuuming through the openings around the perimeter of the detector. The outside of the detector can be wiped with a damp cloth.
  • Page 34 CAMPING WHAT TO DO WHEN THE ALARM SOUNDS: • Leave immediately by your escape plan. Every second counts, so don't waste time getting dressed or picking up valuables. • In leaving, don't open any inside door without first feeling its surface. If hot, or if you see smoke seeping through cracks, don't open that door! Instead use your alternate exit.
  • Page 35 CAMPING ALARM CONDITION If the COSTAR senses unsafe levels of CO, the RED L.E.D. will light up and the alarm will sound. The alarm condition will be signified by a repetitive alarm-sounding pattern of approximately 4.5 seconds on 1.5 second off. Immediate evacuation is required. Pushing the test button will silence the alarm once for approximately 4 minutes.
  • Page 36 The failure of any circuit component will cause the detector to display a continuous orange LED fault light and a short beep indicating failure. If this occurs, immediately contact your dealer or Airstream Customer Service for the name of the nearest detector service center.

  • Page 37: Overnight Stop

    Booklets are available which list these dumping stations. When you stop for the night, your Airstream motorhome can be safely parked in any spot that is relatively level and where the ground is firm. Your facilities are with you. You are self- contained. Try to pick as level a parking spot as possible.
  • Page 38 CAMPING WINTER TRAVELING (Cont.) Some states do not allow LPG to be turned on while moving. While traveling in these states you must use your common sense. How cold is it? How long will it be before you can turn the heat back on? Is the temperature dropping or rising? Remember, the wind chill factor when driving 50 MPH will cause the interior of the motorhome to cool much faster than when it is parked.

  • Page 39: Extended Stay

    CAMPING EXTENDED STAY Making a long trip is not very different from making a weekend excursion. Since everything you need is right at hand, you are at home wherever you go. When packing for an extended trip, take everything you need, but only what you need. Some models are equipped with Hydraulic Leveling Jacks that can be deployed.
  • Page 40 CAMPING EFFECTS OF PROLONGED OCCUPANCY Your motorhome was designed primarily for recreational use and short-term occupancy. If you expect to occupy the motorhome for an extended period, be prepared to deal with condensation and the humid conditions that may be encountered. The relatively small volume and tight compact construction of modern recreation vehicles mean that the normal living activities of even a few occupants will lead to rapid moisture saturation of the air contained in the motorhome and the appearance of visible moisture, especially in cold weather.
  • Page 41 CAMPING TIPS TO CONTROLLING CONDENSATION (continued) The natural tendency would be to close the vehicle tightly during cold weather. This will actually compound the problem. Simply put, you need to remove some of the warm air, and allow some cool outside air to get inside the vehicle, so the furnace will not recycle the humid interior air.
  • Page 42 CAMPING SLIDE OUT OPERATION The slide out room on the Land Yacht Low Profile models is designed for easy deployment. A momentary switch located on the microwave cabinet operates the room. To extend or retract the room, push and release the switch. The room will slide into position and stop automatically. It is not necessary, and could be harmful to hold the switch down during room operation.

  • Page 43: Exterior

    EXTERIOR The sidewalls and roof of your Airstream Land Yacht motorhome are laminated fiberglass with a gel coat exterior finish. No paint means the small mars and scratches can be polished out or repaired using gel coat. We recommend this be done professionally since excessive polishing can remove the gel coat.
  • Page 44 EXTERIOR Occasionally you might find the latch catch, item 3 in the diagram below, out of time. This simply means it has been bumped and has flipped to the closed position when the door is still open. To re-time, hold the door handle in the open position, then pull out and down on the latch catch.
  • Page 45 EXTERIOR KEYLESS DOOR LOCK Operation The dead bolt portion of your motorhome may be controlled by radio signals produced by the key fob shown below. One characteristic of this system is the one second delay after a pad has been depressed.

  • Page 46: Roof Ladder

    EXTERIOR ROOF LADDER Lifting up on the bottom section of the ladder will release the hinge and allow the ladder to be pivoted down to use position. The ladder a two pins that inserted snuggly into the nylon sockets. To store, pop the ladder bottom out of the nylon sockets and fold the ladder upward at its hinge, as it nears vertical, the slot in the hinge will fall into a locked position and hold the ladder up.

  • Page 47: Shades

    INTERIOR The luxurious interior of your Airstream motorhome has been designed for comfort, convenience, durability and appearance. An understanding of the operational procedures and maintenance techniques of the interior appointments will add to your pleasures, as well as to the long life of your motorhome.

  • Page 48: Bathroom

    INTERIOR Hardwood Flooring Daily care for the planked hardwood floor is by vacuuming. Occasionally waxing with a non- water base wax will help extend the life of the floor. CAUTION : Warn occupants of the vehicle when fresh wax has been applied, just like a home, the floor will be slippery.
  • Page 49 The dealer will be able to give you the cleaning code and part number for the fabrics used in your particular motorhome. The following are the cleanability code instructions for the various fabrics used in the Airstream motorhomes:...

  • Page 50: Drapes

    INTERIOR Drapes Use the following procedures to remove drapery panels for cleaning Front Wrap Around Drapes 1. Remove screws securing rear end of drapery track bracket to wall, both roadside and curbside. 2. Remove the plastic end cap. 3. Slide draperies to the rear until they are clear of track. 4.

  • Page 51: Plumbing

    Replace any regulator that has had water in the spring case, or shows evidence of external corrosion, or corrosion inside the spring case. Closely examine regulators directly connected to the container valve by means of a solid POL adapter (horizontal mounting) for signs of corrosion. (An Airstream Service Center is recommended for this service.)
  • Page 52 PLUMBING BASIC RULES FOR SAFETY Warning: DO NOT store LP containers within vehicle. LP containers are equipped with safety devices that vent gas should the pressure become excessive. Warning: DO NOT use cooking appliances for comfort heating. Cooking appliances need fresh air for safe operation. Before operation open overhead vent or turn on exhaust fan and open window.
  • Page 53 PLUMBING LP TANK The regulator at the L.P. tank is under a black plastic cover. The protective cover certainly helps to keep the vent on the regulator from getting clogged by wasps or ice, but should still be checked regularly to make sure the vent remains clear.

  • Page 54: Water System

    PLUMBING WATER SYSTEM - SELF-CONTAINED The fresh water system consists of a water fill, fresh water tank, water-pump, pump filter, hot and cold water lines, water heater, drain valves, and faucets. To operate the system: Turn the water heater by-pass valves to normal flow position. The by-pass valves are located under the lavatory cabinet in the 33’...
  • Page 55 PLUMBING WATER PUMP AND STRAINER The water pump and strainer are located under the rear bed and can be accessed by opening the door at the bed footboard. The strainer should be visually checked for accumulation of sand or debris that could affect water flow.

  • Page 56: Water Pump

    PLUMBING WATER PUMP Manufacturer: Aquatec 17422 Pullman Street Irvine, CA 92614 Phone: 800-975-9995 Phone: 949-225-2200 Fax: 949-225-2222 Web site: www.aquatec.com Aquajet RV Series. This revolutionary pump employs state-of-the-art electronics to automatically control motor speed -the pump actually adjusts its speed as you open and close water fixtures. The Aquajet RVs exclusive soft start feature eliminates annoying rapid cycling, and its exclusive 5-valve design can deliver twice the flow and pressure conventional RV industry pumps.

  • Page 57: City Water Hookup

    PLUMBING CITY WATER HOOKUP Use a high-pressure hose of at least ½ " diameter. It should be one that is tasteless, odorless and non- toxic designed for RV use. The city water inlet is a standard garden hose thread. We suggest you carry two lengths of hose.

  • Page 58: Exterior Water Service

    PLUMBING EXTERIOR WATER SERVICE On the side of the 26’ and 30’ motorhomes is a large utility compartment with a keyed door. A spigot and garden hose female connector is inside. On the 33’ model in the roadside rear utility compartment on the left rear lower side is a water hose connector marked "black tank flush"...
  • Page 59 PLUMBING MICROTECH™ FILTER INSTALLATION/REPLACEMENT 1. Install a new filter by wetting the outlet ports with water and then inserting into the round filter ports on the faucet head and pushing the filter and head together. Both outlet ports must be fully inserted into the filter ports.
  • Page 60 PLUMBING OPERATING INSTRUCTIONS Controlling The Water The PureTouch system has two options for water delivery, unfiltered stream and filtered water. STREAM MODE: Unfiltered water in regular stream flow When the water is turned on at the faucet, the spout will always begin operating in the regular stream mode. FILTERED WATER MODE: Filtered water dispensed though the separate filtered water outlet.
  • Page 61 PLUMBING Moen Two Handle Lavatory Faucet Moen Model 4720 Canada Moen Inc. Moen Inc. 25300 AL Moen Dr 2816, Route Bristol, Oakville North Olmstead, OH. 44070-8022 Ontario, L6H5S7 1-800-Buy-Moen (289-6636) 1-800-465-6130, Toronto: 905- 829-3400 Care Instructions for the Non-Tarnish Finish As with any fine polished surface, your faucet will retain its shine for years to come with proper care.
  • Page 62 PLUMBING DRAIN AND HIGH PRESSURE WATER VALVES Your Land Yacht motorhome has several water line, tank drain, and shut off valves. Drain Valves On the 30’ and 33’ models 3 valves are located under the double bed behind the hinged door. If you have a twin bed model, these 3 valves would be located under the curbside twin bed behind the lower access door at the front edge of the bed base.
  • Page 63 313-769-6000 Canada, L4T 1G3 The RV toilet in your Airstream is a design that has been used for many years. In normal use, when you are hooked up to city water, both pedals are depressed together. This dumps the sewage and fresh water and flushes down the side of the bowl. Water will continue to run into the bowl for a short time after the pedals are released.
  • Page 64 PLUMBING Toilet (26 Ft Model) Sealand Traveler Lite Model 111 Sealand Technology, Inc P.O. Box 38 13128 State RT. 226 Big Prairie, Ohio 44611 (800-321-9886) The Traveler toilet should be cleaned regularly for maximum sanitation and operational efficiency. You can clean that just as you would a household toilet. Do not use caustic chemicals, such as drain opening types, as they will damage the seals.
  • Page 65 PLUMBING Sealand Technology is ready to assist you in the event service is required. Before calling, please have the following information available. 1. Toilet Model Number 2. Serial Number 3. Part Number, Description, and Quantity. For the name of the nearest authorized service center please call 1-800-321-9886 between the hours of 8:00 AM and 5:00 PM, Eastern Time.

  • Page 66: Storage And Winterizing

    Instructions for draining the water system are explained in the following paragraphs on winterizing. Twice a year, or after a long storage period, we suggest you take your unit into your Airstream dealer for a check-up and cleaning of the gas operated appliances...
  • Page 67 PLUMBING For additional winterizing protection, add non-toxic antifreeze (approved for drinking water systems) to your water lines using the following procedure: 1. Reconnect all lines except the hose to the pump inlet port. Close all drain valves (See Step 3) *2.
  • Page 68 PLUMBING DRAIN AND WASTE SYSTEM The drain and waste system of your motorhome includes waste holding tanks made from molded plastic. The MAIN HOLDING TANK enables you to use the toilet for several days away from disposal facilities. The wastewater from the sink, shower, and bath and lavatory drain into the AUXILIARY HOLDING TANK.
  • Page 69 PLUMBING When Parked and Connected to Sewer Outlet When you are in a park and connected to a sewer outlet, keep the main holding tank dump valve closed and empty the tank every few days or whenever it becomes almost full. ONLY BY SENDING A LARGE VOLUME OF LIQUID THROUGH THE MAIN HOLDING TANK AT A TIME WILL TOILET PAPER AND OTHER SOLIDS COMPLETELY WASH AWAY.

  • Page 70: Battery Control Center

    See your Chassis Drivers Manual for further information on chassis items. A diagram is in this section shows where Airstream picks up power for automotive accessories. The diagrams for these fuse panels are shown later in this section.

  • Page 71: Interior Lights

    ELECTRICAL SYSTEM 12-Volt Operation ve to do is make sure the two coach batteries and engine battery does not run The only thing you ha down. In normal usage there isn't any problem, since you would normally drive part of the day and be plugged into a campground at night.
  • Page 72 ELECTRICAL SYSTEM Primary Battery Control Center Circuit Locations Front Driver’s Side Exterior Compartment...
  • Page 73 ELECTRICAL SYSTEM Fuse Panel, Coach Front Roadside Exterior Compartment CIRCUIT COLOR MAX AMP DESCRIPTION Spare Gray Power Awning Purple Bedroom lights, Television, Fan Yellow Bath & vanity lights, furnace, water heater Brown Aisle, galley, under hood, lights Blue Bath fan, refrigerator, TV booster, RS reading lights, Fan Storage compartment lights Black...
  • Page 74 ELECTRICAL SYSTEM...
  • Page 75 ELECTRICAL SYSTEM...
  • Page 76 ELECTRICAL SYSTEM EXTERIOR WORKHORSE FUSE BLOCK The 10-amp ALT/START must be a circuit breaker. Airstream functions only, see Workhorse manual for all chassis protections. SIZE NAME CIRCUITS PROTECTED HORN Horn CTSY Dome lights GAGES See Workhorse manual AUX PWR PK LPS...

  • Page 77: Monitor Panel

    The monitor system has been calibrated at the factory and should never need another calibration. If you feel the system is not operating correctly, please contact CATCON Products or a local Airstream dealer. The following instructions are provided for qualified service technicians.
  • Page 78 ELECTRICAL SYSTEM MICROPULSE SYSTEMS MONITOR OPERATION INSTRUCTIONS This example shows the monitor reporting the following: Fresh Water = 1/8 to Empty Gray Water 1 = Empty to 5/8 Gray Water 2 = 3/4 Black Water = Empty to 5/8 LP Gas = 1/4 Battery = Empty to 5/8 On all diagrams the Letters R=Red, Y=Yellow, G=Green, Blank=no LED lit.

  • Page 79: Tv Antenna

    ELECTRICAL SYSTEM TV ANTENNA Manufacturer: Winegard Company 3000 Kirkwood Street Burlington, Iowa 52601 Phone: 800-843-4741 Raising Antenna to Operating Position Turn elevating crank in "UP" direction until some resistance to turning is noted. Antenna is now in operating position. Check to make sure switch on front TV jack is on.
  • Page 80 ELECTRICAL SYSTEM Maintenance Lubrication To lubricate the elevating gear apply a liberal amount of silicone spray lubricant to the elevating gear with the lift in the down position, then run the lift up and down a few times to distribute lubricant over gears. Lubricating Rotating Gear Housing In the event that rotating the antenna becomes difficult, lubricating the bearing surface between the rotating gear housing and the base plate can restore normal operation.

  • Page 81: 110-Volt Power

    ELECTRICAL SYSTEM SOLAR POWER The 5 watt system installed in your motorhome primarily function is as a battery maintainer. Memory functions in radios, locks and the circuit boards in some safety devices each draw power in the milliamp range. If a charge source is not available, even these miniscule power drains will run your chassis batteries down in a few days.
  • Page 82 ELECTRICAL SYSTEM 110-VOLT SWITCHOVER BOX To protect linemen from an unexpected shock the generator must: be wired through a switchover box. Two automatic switchover boxes are located in the trunk storage area behind a false panel on the roadside of the area.

  • Page 83: Switch-Over Box

    ELECTRICAL SYSTEM SWITCHOVER BOX (cont.) When you have the optional 50 amp service, the red wire shown on the following diagram will be providing power to the rear air conditioner whether you are plugged into city power or operating the generator.
  • Page 84 ELECTRICAL SYSTEM 110-Volt Breaker Panel, 30 AMP H-15...
  • Page 85 ELECTRICAL SYSTEM 110-VOLT BREAKER PANEL, 50 AMP H-16...
  • Page 86 ELECTRICAL SYSTEM Automatic Energy Select Switch (AESS) Front a/c is priority. Rear a/c will cool, if cool mode is selected, when front a/c has finished its cooling process. Front a/c will come back on as its thermostat detects the need to cool and the rear a/c will shut off. A/C fan (powered by 12-volt) on both units will run even if the other is cooling on the 120-volt circuit.
  • Page 87 ELECTRICAL SYSTEM NOTES H-18...

  • Page 88: Appliances

    Note: Review the air conditioning literature supplied in your Owner's Packet before proceeding. The roof air conditioner used on Airstream motorhomes is one of the most popular on the market today. In your Owner's Packet is a set of literature covering all operating and maintenance instructions. If the literature is misplaced, please contact the air conditioner manufacturer or your Airstream dealer for replacement.
  • Page 89 120-volt shoreline. Operating instructions are located in your Owners Packet. If they should become misplaced new literature can be ordered direct from the manufacturer or your Airstream dealer. The manufacturer also offers a detailed service guide for your furnace.
  • Page 90 APPLIANCES REFRIGERATOR (See warning at top of page I-1) Manufacturer: Dometic Sales Corporation 2320 Industrial Parkway P.O. Box 490 Elkhart, Indiana 46514 Phone: 219-295-5228 Review all Dometic Literature supplied in your Owner's Packet or stored in the refrigerator prior to operating. In an absorption refrigerant system ammonia is liquefied in the finned condenser coil at the top rear of the refrigerator.

  • Page 91: Microwave Oven

    201-5112-0055 219-295-5228 Airstream has used two different methods of holding the ovens in place. The most common is a setscrew configuration where two bolts apply downward pressure on top of the range. The bolts can be found in the cabinet directly above the oven, and out toward the front. Back them out a few turns and the front of the oven can be lifted up and out over the lower ledge.

  • Page 92: Water Heater

    APPLIANCES WATER HEATER (See warning at top of page J-1) Manufacturer: Atwood Mobile Products 4750 Hiawatha Drive P.O. Box 1205 Rockford, Illinois 61105 Phone: 815-877-7461 Note: Review the water heater literature supplied in your Owner's Packet before proceeding, Warning: Hydrogen gas can be produced in a hot water system served by this heater that has not been used for a long period of time (generally two weeks or more).
  • Page 93 APPLIANCES HIGH VOLUME ROOF VENT (OPTIONAL) Manufacturer: FAN-TASTIC VENT CORP. 4349 S. Dort Hwy. Burton, MI 48529 1-313-742-0330 1-800-521-0298 The optional high-volume roof vent system is designed to quickly exhaust stale, hot air and draw in fresh air. It's great to use when the outside temperature really doesn't call for air conditioning, but heat has built up in your coach.
  • Page 94 APPLIANCES AUTOMATIC SATELLITE SYSTEM (Option) The satellite system comes with an owner’s manual. The manufacturer requests that technical and warranty questions be directed to them. KING DOME SATELLITE SYSTEMS Technical Support: 1-800-982-9920 Website: www.kingcontrols.com...

  • Page 95: Specifications

    SPECIFICATIONS Coach NOTE: The weights and measurements in this manual are derived from the best information available at time of this manuals publishing. Please refer to the weight information label placed in your unit and your chassis Owner’s Manual for weights specific to your RV. 26 FT 30 FT 30 ft S/O...
  • Page 96 SPECIFICATIONS NOTE: The weights and measurements in this manual are derived from the best information available at time of this manuals publishing. Please refer to the weight information label placed in your unit and your chassis Owner’s Manual for weights specific to your RV. The Unit Base Weight (UBW) and the Net Carrying Capacity (NCC) is not the same as the Unloaded Vehicle Weight (UVW) and the Cargo Carrying Capacity (CCC) shown on the Weight Information tag in your vehicle.
  • Page 97 INDEX Air Conditioner......... C-2, I-1 Faucets ..........G-8 Alignment..........C-4 Fabrics, Cleaning ........F-3 Antenna ..........H-10 Filter, Water..........G-8 Appliances ..........I-1 Flooring ........... F-2 Automotive Fuses......H-1, H-3 Furnace ............J-2 Auxiliary Heater ......B-4, C-3 Fuses ..........H-3 Auxiliary Start Switch ......B-4 Gas, LP ..........
  • Page 98 Tank Capacities ........J-1 Tank Drain..........G-12 Tank, Holding..B-1, D-7, G-4, G-18, J-1 Tank, Sewage ........G-19 Tank, Water ..........G-4 Tank, LPG ..........G-1 Tires ...........C-3 Tire Inflation........C-3, C-9 Airstream Land Yacht Gas Owner’s Manual © Airstream, Inc. 2005...
