Gin Camino 2 Instructions

1. General
Folding and cross lines are available as an optional extra and should be attached to the wing
before inducing collapses. Be sure to attach the folding lines to both sides of the canopy for
symmetric collapses (front stall).
The additional cross line is used for large, asymmetric collapses and is only attached on one
side.
Please refer to the rigging diagrams at the end of this document.
WARNING: Familiarise yourself with the special operation and effect of folding and cross
lines described in the Camino 2 user manual.
2. Folding line riser
Attach the folding line riser (webbing) to the harness main carabiner. Then attach the maillon to
the other end of the folding line riser. Repeat on the other side.
