BEFORE YOU BEGIN
BEFORE YOU BEGIN
Observe all local plumbing and building codes.
Before installation, unpack the new sink and inspect it
for damage.
Inspect the waste and supply tubing; replace if
necessary.
CAUTION: Risk of personal injury or product
damage.
Cast iron sinks are very heavy. Get
help when lifting the sink into place.
For a replacement installation, make sure the existing
RECOMMENDED TOOLS AND MATERIALS
RECOMMENDED TOOLS AND MATERIALS
·
Sealant
·
Pencil
·
Tape Measure
·
Putty Knife
·
Sharp Knife or Scissors
·
Saber Saw or Keyhole Saw
1008270-K01-A
SELF-RIMMING ENAMELED CAST IRON SINK
cutout is the same size or smaller than the cutout for
the new sink. This sink is not intended for undercounter
installation.
Please leave these instructions with the consumer; they
contain important care, cleaning, and warranty
information.
WARNING
PRODUCT WEIGHT: 60KG.
BEFORE YOU INSTALL NEW SINK, PLEASE
BUILD A PROPER STRUCTURE TO SUPPORT
THE SINK.
·
Drill and 13mm Drill Bit
·
Safety Glasses
·
Masking Tape
·
Rags or Paper Toweling
·
Pipe wrench
-1-
BROOKFIELD
EXECUTIVE CHEF
K-17250K-1S/2S/3S/4S
K-17251K-1S/2S/3S/4S
Copyright
2004 Kohler Co.
C
Advertisement
Related Manuals for Kohler BROOKFIELD EXECUTIVE CHEF K-17250K-1S
Summary of Contents for Kohler BROOKFIELD EXECUTIVE CHEF K-17250K-1S
- Page 1 Drill and 13mm Drill Bit · · Pencil Safety Glasses · · Tape Measure Masking Tape · · Putty Knife Rags or Paper Toweling · · Sharp Knife or Scissors Pipe wrench · Saber Saw or Keyhole Saw Copyright 2004 Kohler Co. 1008270-K01-A...
- Page 2 ß ROUGHING-IN BROOKFIELD K-17250K-4S K-17250K-3S K-17250K-1S 102mm 35mm R. 102mm 102mm 51mm 51mm 95mm 254mm 470mm K-17250K-2S 203mm 41mm 51mm 159mm 159mm 35mm 838mm 13 mm 220mm OUTLET EXECUTIVE CHEF K-17251K-4S K-17251K-1S 102mm 64mm 51mm 51mm 102mm 216mm 470mm K-17251K-2S 51mm 38mm 324mm...
- Page 3 INSTALL THE NEW SINK INSTALL THE NEW SINK Check the desired sink location for clearance between the backsplash wall, faucet, fixture, and cabinet. Position and trace the template on the countertop as directed on the template. Drill a 13mm pilot hole on the inside of the cut line. Cut out the countertop opening with a saber or keyhole saw.
- Page 4 Kohler Co. disclaims all implied warranties including merchantability and fitness for a Kohler Co. will, at its election repair, replace, or make particular purpose. Kohler Co. disclaims any appropriate adjustment where Kohler Co. inspection liability for special, incidental, or consequential discloses any such defects occurring in normal usage damages.
