Dishwasher
User manual
DW60M9550F*/DW60M9530F*
DW9000M_DD68-00203A-01_EN.indd 1
2018-02-20
12:05:29

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DW60M9550F Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung DW60M9550F Series

Summary of Contents for Samsung DW60M9550F Series

  • Page 1 Dishwasher User manual DW60M9550F*/DW60M9530F* DW9000M_DD68-00203A-01_EN.indd 1 2018-02-20 12:05:29...

  • Page 2: Table Of Contents

    Contents Safety information What you need to know about safety instructions Important safety symbols Important safety precautions Instructions when using your dishwasher Instructions for protecting your children Instructions for installing your dishwasher Before you start Dishwasher at a glance Unsuitable items for the dishwasher Water reflector Basic use of racks Detergent guidelines...
  • Page 3 Cycle chart Appendix Transportation/relocation Protection against frost Disposing the dishwasher and helping the environment Specifications For standard test 14 place settings Product fiche English 3 DW9000M_DD68-00203A-01_EN.indd 3 2018-02-20 12:05:29...

  • Page 4: Safety Information

    If you have any questions or concerns, contact your nearest service center or find help and information online at www.samsung.com. Important safety symbols...

  • Page 5: Important Safety Precautions

    Important safety precautions To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic precautions, including the following: 1. This appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Page 6 Safety information 7. For use in Europe: Children of less than 3 years should be kept away unless continuously supervised. 8. CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal cut-out, this appliance must not be supplied through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by the utility.

  • Page 7: Instructions When Using Your Dishwasher

    Instructions when using your dishwasher This dishwasher is not designed for commercial use. It is intended for use in domestic households and in similar working and residential environments such as: • Shops • Offices and showrooms and by residents in establishments such as: •...
  • Page 8 Safety information Only use detergent and rinse aid formulated for domestic dishwashers. Do not use washing-up liquid. Do not use the strong acid cleaning agent. Do not fill the rinse aid reservoir with powder or liquid detergent. This will cause serious damage to the reservoir.

  • Page 9: Instructions For Protecting Your Children

    Instructions for protecting your children This appliance is not a toy! To avoid the risk of injury, keep children well away and do not allow them to play in or around the dishwasher or to use the controls. They will not understand the potential dangers posed by it.

  • Page 10: Instructions For Installing Your Dishwasher

    Safety information Instructions for installing your dishwasher Before setting up the appliance, check it for any externally visible damage. Under no circumstances should you use a damaged appliance. A damaged appliance could be dangerous. The dishwasher must only be plugged into the electricity supply via a suitable switched socket.
  • Page 11 Do not connect the appliance to the mains electricity supply by a multi-socket unit or an extension lead. These do not guarantee the required safety of the appliance (e.g. danger of overheating). This appliance may only be installed in mobile installations such as ships if a risk assessment of the installation has been carried out by a suitably qualified engineer.
  • Page 12 Safety information Always disconnect the dishwasher from the electrical supply for maintenance work (switch off at the wall socket and remove the plug). If the connection cable is damaged it must be replaced with a special cable, available from the manufacturer. For safety reasons, this must only be fitted by the service department or an authorised service technician.
  • Page 13 This product and its electronic accessories should not be mixed with other commercial wastes for disposal. For information on Samsung?? environmental commitments and product specific regulatory obligations e.g. REACH visit: samsung.com/uk/aboutsamsung/ samsungelectronics/corporatecitizenship/data_corner.html English 13 DW9000M_DD68-00203A-01_EN.indd 13...

  • Page 14: Before You Start

    Before you start Follow these instructions carefully to ensure proper installation of the dishwasher and to prevent accidents when washing dishes. Dishwasher at a glance 01 Cover top 02 Top nozzle 03 Lower nozzle 04 Salt storage 05 Water reflector 06 Dispenser 07 Control panel 08 Door...

  • Page 15: Unsuitable Items For The Dishwasher

    CAUTION • Do not wash items that are covered with ash, sand, wax, lubricating grease, or paint. These materials will damage the dishwasher. Ash does not dissolve and will spread inside the dishwasher. • Remove food remains such as bones, fruit seeds, etc. and waste such as toothpicks, paper napkins, etc.

  • Page 16: Basic Use Of Racks

    Before you start Basic use of racks Height adjustment You can adjust the height of the upper rack so that the lower rack can accommodate larger sized dishes. Depending on the height of the upper rack, the lower rack can accommodate plates up to 31 cm in diameter, and the upper rack can accommodate plates up to 19 cm in diameter.
  • Page 17 To remove the upper rack To remove the upper rack, pull the upper rack to the front until it is fully extended, and then lift it slightly to remove. See the figures above for the illustrated steps. CAUTION • Do not operate the dishwasher without the upper rack. Otherwise, noises occur and the dishwasher does not operate properly.
  • Page 18 Before you start Into the Zone Booster+ areas For more effective cleaning, load large items into the left side of the lower rack— the Zone Booster+ areas. The Zone Booster+ function supplies more powerful water jets to the Zone Booster+ areas. Make sure pot handles and other items do not interfere with the rotation of the nozzles and the water reflector.
  • Page 19 Using the glass support The glass support is especially suited for wine glasses. Hang wine glasses onto the pegs of the glass support. Fold the glass support back when it is not being used. CAUTION Do not adjust the level of the upper rack with the glass support propped up.

  • Page 20: Detergent Guidelines

    Before you start Detergent guidelines All dishwasher cycles require detergent in the detergent compartment. Apply detergent as appropriate for the selected cycle to ensure best performance. WARNING • Do not consume dishwasher detergent. Avoid breathing in detergent fumes. Dishwasher detergent contains irritants and caustic chemicals that can induce respiratory conditions.
  • Page 21 2. Apply the recommended amount of detergent to the main compartment. 3. Close the flap, and then press down to lock. NOTE This dishwasher has no separate compartment for tablet detergent. 4. For best results, apply a small amount (about 8 g) of detergent onto the door. The additional detergent will activate during the pre-wash process.
  • Page 22 Before you start Rinse aid Rinse aid improves the drying performance of the dishwasher. When the Rinse Refill indicator lights up on the control panel, refill with rinse aid. Only use liquid rinse aid. Powdered rinse aid will clog the compartment opening and cause the dishwasher to malfunction.

  • Page 23: Salt Storage

    Salt storage CAUTION • Use dishwasher-specific salt only. Do not use any other type of salt or solvent. This may damage the salt storage and the water softening system. • To prevent corrosion due to an excessive amount of salt or salty water, always fill the salt storage immediately before a washing cycle gets started.

  • Page 24: Touchpad Responsiveness

    Before you start Touchpad responsiveness To prevent the touch-enabled controls from losing responsiveness, follow these instructions. • Touch the centre of each button with one finger. • Do not touch more than one button at a time, except as directed. •...

  • Page 25: Built-In Installation Under The Sink

    You can install the dishwasher under the sink. To do this, follow the instructions below. WARNING Samsung Electronics is not responsible for any product failure or damage that may arise from your installation of the free-standing model under the sink.
  • Page 26 Before you start 4. If necessary, remove both the plastic part and the weight balance on the rear side. To do this, remove the marked screws in the left-sided figure. CAUTION • The weight balance on the rear is heavy. Use caution to remove it. •...
  • Page 27 Installation The installation procedure may differ depending on the model. STEP 1 Select a location Select a location that meets the following conditions. • The location must have a solid floor that can support the weight of the dishwasher. • The location must be near a sink with easy access to the water supply, drain system, and electrical outlet.
  • Page 28 Before you start STEP 2 Check the water line • The water line pressure must be between 0.05 and 0.8 MPa. • Make sure that the water temperature does not exceed 60 °C. Hot water over 60 °C may cause the dishwasher to malfunction. •...
  • Page 29 STEP 4 Level the dishwasher You can adjust the height of the dishwasher up to 30 mm using the levelling legs. 1. While slightly lifting the front or rear (or both in turns) of the dishwasher, turn the levelling legs to adjust the height.
  • Page 30 Before you start STEP 5 Connect the drain hose 1. Detach the hose holder from the dishwasher, and then cut off the protruding part from the holder as shown. 2. Fix the holder to a wall by tightening the 2 screws (Ø4 X 12). 3.
  • Page 31 STEP 6 Final check 1. Remove all foam, paper packaging, and unnecessary parts from inside the dishwasher. 2. Turn the circuit breaker on. 3. Open the water supply valve to supply water to the dishwasher. 4. Plug in and turn the dishwasher on. Then, select and run the Quick cycle. 5.

  • Page 32: Operations

    Operations Control panel DW60M9550** DW60M9530** Press to turn the dishwasher on or off. When a cycle is complete, 01 POWER all other indicators turn off with “0” on the display. Then, the dishwasher turns off automatically. Press to select a cycle according to the soil level of your dishes. 02 Cycle bar The corresponding cycle indicator turns on.
  • Page 33 Select this option to increase the main-wash temperature to improve the cleaning performance for loads containing stubborn, 06 Hi-Temp Wash baked-on food. This is available only with the Auto, ECO, and Intensive cycles. With this selected, the water temperature increases to 73 °C in the final rinse for high temperature sanitization.
  • Page 34 Operations Indicators Lights up if Control Lock is activated, and blinks if Control Lock indicator any button except for the POWER button is pressed. Lights up if Self Clean is activated, and blinks for Self Clean indicator 5 seconds every 20-22 cycles. The cycle counter disappears when the Self Clean cycle is complete, or (applicable models only) the dishwasher reaches the 23...

  • Page 35: Cycle Overview

    Cycle overview This cycle detects the level of soil and automatically initiates the 01 Auto optimal cycle, which is appropriate for all levels of soiled items. This cycle reduces power and water consumption, which is 02 ECO appropriate for normally soiled items. To reduce the cycle time, select the Speed Booster option.

  • Page 36: Simple Steps To Start

    Operations Simple steps to start 1. Open the door, and then load the dishwasher. Make sure dishes are empty. 2. If applicable, put the dishes in the lower rack. If adding the Zone Booster+ option, put the dishes in the left side of the lower rack. 3.

  • Page 37: Settings

    Settings You can change the sound settings or display brightness to your preference. To change the settings, press the Sanitize and Delay Start buttons simultaneously for 3 seconds. Press Sanitize to navigate through sub menus, and press Delay Start to confirm your changes.
  • Page 38 Operations Water softener Press Sanitize until 'L0 - L5' is displayed. Select a water hardness level from Level 0 to Level 5 (default: L3), and then press Delay Start. NOTE If the water hardness level in your area is 0, you do not need to use dishwasher-specific salt.
  • Page 39 Auto Door To improve drying performance, the door opens automatically in the drying process. ‘0’ will be displayed when the current cycle is complete. Press Sanitize until ‘A1’ or ‘A0’ is displayed to enter Auto Door mode. Then, press Delay Start to enable (A1) or disable (A0) the Auto Door function.
  • Page 40 Operations Delay Start You can delay the cycle starting time up to 24 hours in 1-hour increments. To increase the delay time, press Delay Start. The hour displayed indicates the time at which the cycle will start. 1. Open the door, and then load the dishwasher. 2.

  • Page 41: Maintenance

    Maintenance Cleaning Keep the dishwasher clean to improve performance, reduce unnecessary repairs, and lengthen the lifecycle. Exterior Clean spills on the surface of the dishwasher as they occur. Use a soft, damp cloth on the control panel to gently wipe away spills and dust. CAUTION •...
  • Page 42 Maintenance Nozzles To prevent the nozzles from being clogged or if the nozzles are clogged, remove and clean each nozzle. Use caution when removing the nozzles as they may break. Upper nozzle 1. Open the door, and then pull out the upper rack to reveal the upper nozzle.
  • Page 43 Filter We recommend cleaning the filter every month. 1. Open the door, and then remove the lower rack first. 2. Turn the filter handle counter clockwise to unlock the filter cover. 3. Remove the filter cover, and then the cylindrical micro filter underneath. English 43 DW9000M_DD68-00203A-01_EN.indd 43 2018-02-20...

  • Page 44: Long-Term Care

    Maintenance 4. Remove any dirt and impurities from the micro filter and the filter cover. 5. Rinse them with running water, and then dry well. 6. Reinsert the filter, and then the filter cover. 7. Turn the filter handle clockwise to lock. CAUTION Make sure the filter cover is closed properly.

  • Page 45: Troubleshooting

    Troubleshooting Checkpoints If you encounter an issue to check with the dishwasher, first check the table below and try the suggestions. Symptom Possible Cause Action • Make sure the door is latched and completely closed. The door is not completely •...
  • Page 46 Troubleshooting Symptom Possible Cause Action • Select a cycle according to An incorrect cycle was selected. the soil level of the dishes as instructed in this manual. • Clean the filters. The filters are clogged or not • Make sure the filters are correctly fastened.
  • Page 47 Symptom Possible Cause Action The dishwasher makes a sound when the dispenser cover is • This is normal. open and the drain pump is operating. The dishwasher is too • Make sure the dishwasher is noisy. The dishwasher is not level. level.

  • Page 48: Information Codes

    Samsung service centre. Pump operation check • Functional check. Turn off the dishwasher and restart. If the issue continues, contact a Samsung service centre. If any information code keeps appearing on the screen, contact a local Samsung service centre. English DW9000M_DD68-00203A-01_EN.indd 48...

  • Page 49: Cycle Chart

    Cycle chart Soil Level Auto Intensive Delicate Daily55' Quick Amount of Very light to Normal Heavy Light Normal Light food remains Heavy Prewash  Prewash  Prewash  Prewash  Mainwash  Mainwash  Mainwash  Mainwash  Mainwash  Mainwash ...

  • Page 50: Appendix

    Appendix Transportation/relocation Make sure the dishwasher is empty with no loose parts. First, drain the dishwasher as follows. 1. Open the door, and then turn the dishwasher on. 2. Select and run the ECO cycle. 3. Press START, and then close the door. 4.

  • Page 51: Specifications

    Specifications MODEL (Free Standing) DW60M9550F*, DW60M9530F* Power 220-240 V ~ , 50 Hz Water pressure 0.05-0.8 Mpa Wash capacity 14 place settings Rated power 2000-2300 W Dimension 598 X 600 X 845 (mm) (Width x Depth x Height) Weight (Unpacked) 54.0 kg •...

  • Page 52: For Standard Test

    For standard test NOTE The diagrams below show the proper way to load the baskets based on the European Standards (EN50242: 2016). • Washing capacity: 14 place settings • Position of upper basket: Low • Programme: ECO • Rinse aid setting: 6 •...

  • Page 53: Product Fiche

    Product fiche REGULATION (EU) No 1059/2010 NOTE “ * ” Asterisk(s) means variant model and can be varied (0-9) or (A-Z). Supplier SAMSUNG Model name DW60M9550F* DW60M9530F* Rated Capacity (place setting) Energy efficiency class A+++ Eco label Annual energy consumption, (AE...
  • Page 54 Memo English DW9000M_DD68-00203A-01_EN.indd 54 2018-02-20 12:05:37...
  • Page 55 Memo English 55 DW9000M_DD68-00203A-01_EN.indd 55 2018-02-20 12:05:37...
  • Page 56 QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT 0330 SAMSUNG (7267864) www.samsung.com/uk/support IRELAND 0818 717100 www.samsung.com/ie/support (EIRE) DD68-00203A-01 DW9000M_DD68-00203A-01_EN.indd 56 2018-02-20 12:05:37...
