- Page 1 HME 95 Headset for general aviation Instruction manual...
-
Page 2: Table Of Contents
Sennheiser a world-leading company in this field. Please take a few moments to read these instructions carefully, as we want you to enjoy your new Sennheiser products quickly and to the fullest. -
Page 3: Important Safety Instructions
Important safety instructions • Please read these instructions carefully and completely before using the headset. • Make these instructions easily accessible to all users at all times. Always include these instructions when passing the headset on to third parties. • During flight operation, do not use the headset for telephone calls. -
Page 4: Delivery Includes
2 MZW 46 wind and pop shields 1 audio-in cable for mobile telephones, length 0.6 m, with two 2.5 mm jack plugs 1 audio-in cable for additional audio players, length 0.6 m, with two 3.5 mm jack plugs 1 instruction manual... -
Page 5: The Hme 95 Headset
• Noise-compensating boom microphone ensures excellent speech transmission • Flexible microphone boom • Separate left and right channel volume control • Peak level protection safeguards your ears from volume peaks above 110 dB • Excellent comfort resulting from soft ear pads and headband padding •... -
Page 6: Operating Elements
5.25 mm jack plug Headset cable Cable with headphone plug, Microphone boom ¼” (6.35 mm) jack plug Earpads 3.5 mm jack socket for connecting an Headband additional audio player (3-pin) 2.5 mm jack socket for connecting a mobile telephone (3-pin) Mono/stereo switch... -
Page 7: Preparing The Headset For Use
Preparing the headset for use Connecting the headset The headset’s operating control features two cables with one jack plug each. Connect the headset to the corresponding sockets of your intercom. Connector for connection to the ¼” (6.35 mm) jack plug headphone output 5.25 mm jack plug... -
Page 8: Connecting An Additional Audio Player
Connect the audio cable to the 2.5 mm jack socket (3-pin) on the operating control and to the corresponding jack socket on your mobile telephone (4-pin). You can adjust the volume of the mobile telephone via the headset’s operating control. However, the functions of the mobile telephone cannot be controlled via the headset’s operating control. -
Page 9: Adjusting The Microphone Sensitivity
Connect the audio cable to the 3.5 mm jack socket the operating control and to the corresponding jack socket on your audio player. Audio from the additional audio source and from the intercom are heard simultaneously through the headset. Adjusting the microphone sensitivity The microphone sensitivity has been factory pre-set to 80 mV/Pa as per RTCA DO-214. -
Page 10: Using The Headset
Using the headset Attaching the cable clip The cable clip allows you to attach the headset cable your clothing so that the cable doesn’t hinder or distract you. Guide the headset cable through the cable clip Attach the cable clip to your clothing. -
Page 11: Adjusting The Volume
Bend the microphone boom so that the microphone is placed at the corner of the mouth. Maintain a distance of approx. 2 cm between microphone and mouth. » Adjusting the volume CAUTION! Hearing damage due to high volume levels! The headset is capable of producing high sound pressure levels. -
Page 12: Folding Up The Headset
Turn the microphone boom flat as shown. Pull out the right earcup and then fold it in. Place the headset flat into the soft case as shown. The accessories can be transported in the cover of the soft case: –... -
Page 13: Care And Maintenance
Use a soft, slightly damp cloth to clean the headset from time to time. Replacing the ear pads You can replace the ear pads. Spare ear pads are available as accessories. Accessories are available from your Sennheiser partner. A list of suitable accessories can be found on our website at www.sennheiser.com >... -
Page 14: Replacing The Wind Shield
Repeat for the other ear cup. Replacing the wind shield You can replace the wind shield. The HME 95 is supplied with a spare wind shield. Carefully pull the wind shield from the microphone. -
Page 15: Specifications
225 Ω mono Nominal impedance 300 Ω stereo Sound pressure level stereo 100 dB at 1 kHz, 1V mono 97 dB at 1 kHz, 1 V THD at 94 dB SPL < 1 % Attenuation 13–34 dB passive attenuation Contact pressure... - Page 16 Transducer principle pre-polarized condenser microphone, noise-compensating Frequency response 350–6,000 Hz Output voltage 80 mV/Pa (factory pre-set) = 800 mV at 114 dB SPL (adjustable from 17–100 mV/Pa) 150–2,200 Ω Terminating impedance Supply voltage 8–16 V DC Connector assignment ¼” (6.35 mm) jack plug 5.25 mm jack plug...
-
Page 17: Manufacturer Declarations
In order to protect the environment, only dispose of exhausted batteries. WEEE Declaration Please dispose of this product by taking it to your local collection point or recycling centre for such equipment. - Page 18 Sennheiser electronic GmbH & Co. KG Am Labor 1, 30900 Wedemark, Germany www.sennheiser.com Printed in China, Publ. 05/10, 516577/A03...
