MOMENTUM True Wireless 4
True Wireless stereo earbuds
Model: MTW4, MTW4 R, MTW4 L, MTW4 C
Instruction manual
Use the search function, the navigation (left) or the following links:
Start
"Product overview"
"Getting started"
"Using the earbuds"
"FAQ/If a problem occurs ..."
"Specifications"
Sonova Consumer Hearing GmbH
Am Labor 1
30900 Wedemark
Germany
www.sennheiser-hearing.com
Version: 01/24 A01
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sennheiser MOMENTUM True Wireless 4
Summary of Contents for Sennheiser MOMENTUM True Wireless 4
- Page 1 MOMENTUM True Wireless 4 True Wireless stereo earbuds Model: MTW4, MTW4 R, MTW4 L, MTW4 C Instruction manual Use the search function, the navigation (left) or the following links: Start “Product overview” “Getting started” “Using the earbuds” “FAQ/If a problem occurs ...”...
-
Page 2: Important Safety Instructions
Preventing damage to health and accidents ▷ Protect your hearing from high volume levels. Permanent hearing damage may occur when earbuds are used at high volume levels for long periods of time. Sennheiser earbuds sound exceptionally good at low and medium volume lev- els. ▷... - Page 3 The earbuds can be used in the rain, for example. However, they are not suitable for immersion in water or for wearing in the shower. In case of permanent moisture/wetness, the ingress protection can be reduced and the product can be damaged. MOMENTUM True Wireless 4 | 3...
- Page 4 Hearing GmbH or companies commissioned by Sonova Consumer Hearing GmbH and is not processed. Using the “Sennheiser Smart Control” app, you can update the firm- ware of the product for free via an Internet connection. If the device on which the app is installed is connected to the Internet, the follow-...
-
Page 5: Package Contents
• the Sennheiser Smart Control app for configuring the earbuds and for additional functions – Google Play Store: click – Apple App Store: click • a list of accessories on the MOMENTUM True Wireless 4 product page at www.sennheiser-hearing.com/momentum-true-wireless-4 (to purchase online or contact your local Sonova Consumer Hear- ing partner: www.sennheiser-hearing.com/service-support) -
Page 6: Product Overview
Built-in rechargeable battery for charging the earbuds on the go Type plate Charging compartment for the left earbud Magnetic holders Charging compartment for the right earbud Charging contacts 6 | MOMENTUM True Wireless 4... - Page 7 Touch control panel Status LED Left earbud Right earbud Changeable silicone ear adapters Infra-red proximity sensor Magnetic holders Charging contacts Built-in rechargeable battery Changeable ear fins for a secure fit of the earbuds in the ears MOMENTUM True Wireless 4 | 7...
- Page 8 LED of the charging case displays the battery charge status or the charging process of the earbuds. If you close the lid of the charging case, the LED display goes off after 5 seconds. 8 | MOMENTUM True Wireless 4...
-
Page 9: Overview Of The Led Indications Of The Earbuds
• Charge the rechargeable batteries of the charging case and the earbuds until the LED display lights up again (at least 30 minutes) (> 16). Overview of the LED indications of the earbuds MOMENTUM True Wireless 4 | 9... -
Page 10: Notes On Voice Prompts
Bluetooth pairing mode was can- celled. Bluetooth pairing was successful. “Pairing successful” “Pairing failed” Bluetooth pairing was not success- ful. “Recharge headset” Rechargeable battery is almost empty. Recharge the rechargeable battery. “Call rejected” Incoming call rejected. 10 | MOMENTUM True Wireless 4... - Page 11 “Call ended” Call ended. “Mute on” Muting of the microphones during an active call. “Mute off” Muting of the microphones is can- celed. “Volume min” Volume set to minimum. “Volume max” Volume set to maximum. MOMENTUM True Wireless 4 | 11...
-
Page 12: Getting Started
We recommend charging the earbuds and the charging case for a complete charging cycle without interruption before using for the first time. 2. Selecting suitable ear adapters and ear fins for optimum fit of the earbuds in the ears Left Right 12 | MOMENTUM True Wireless 4... - Page 13 Bluetooth pairing mode. If the earbuds have not yet been paired with any Bluetooth device (the pairing list is empty), pairing mode remains permanently activated. ▷ Connect the earbuds to your smartphone via Bluetooth (> 20). MOMENTUM True Wireless 4 | 13...
- Page 14 “Sennheiser Smart Control” Smart Control The Sennheiser Smart Control app allows you to use all functions and settings of the earbuds and to e.g. adjust the sound to your liking using the equalizer (> 21). – Google Play Store: click –...
-
Page 15: Using The Earbuds
The earbuds feature an Eco mode that allows for longer battery life (> 35) and a battery protection mode that ensures gentle charging and thus longer battery life (> 35). You can activate both modes via the Smart Control app. MOMENTUM True Wireless 4 | 15... - Page 16 (> 38). • Clean the USB-C socket of the charging case. • Charge the rechargeable batteries of the charging case and the earbuds until the LED display lights up again (at least 30 minutes). 16 | MOMENTUM True Wireless 4...
- Page 17 Charging case is charging case are green fully charged. fully charged. At least one earbud Charging case has a flashes has a charging charging error/bat- error/battery error tery error (> 40). (> 40). MOMENTUM True Wireless 4 | 17...
-
Page 18: Information On The Bluetooth Wireless Connection
If you want to connect to this Bluetooth device again later, you have to pair the earbuds again. Using the Smart Control app (“Connections”), you can view the list of paired devices and selectively connect and disconnect devices (> 21). 18 | MOMENTUM True Wireless 4... - Page 19 Stream 2 Stream 1 fr Stream 1 fr Stream 2 en Stream 1 zh Stream 1 zh Stream 2 cs Stream 2 de Stream 2 en Stream 3 it Stream 3 it Stream 3 en MOMENTUM True Wireless 4 | 19...
-
Page 20: Pairing The Earbuds With A Bluetooth Device
If neces- sary, repeat the steps described above. If the earbuds are not paired with any Bluetooth device (the pairing list is empty), pairing mode is permanently active. 20 | MOMENTUM True Wireless 4... -
Page 21: Installing The Smart Control App
To be able to adjust the settings of the earbuds to your individual needs and to fully use all functions of the earbuds, you require the free Sennheiser Smart Control app on your smartphone. The earbuds can only be paired with Bluetooth devices when connected to the Smart Control app. - Page 22 (> 42). Establishing a connection to Auracast™ transmitters The “Auracast” function in the Sennheiser Smart Control app allows you to select and change the connection to an Auracast™ transmit- ter. You can connect to several Auracast™ transmitters at the same time.
- Page 23 You can tell by the blue tick ( ) and the digital signal symbol ( ▷ In the list, tap the transmitter you want to play. The transmitter’s audio data is played through your earbuds. MOMENTUM True Wireless 4 | 23...
- Page 24 L. The ear adapters must fit snugly in the ear canal and com- pletely seal your ears. You can use the Fit Test function in the Smart Control app to test the fit of the earbuds in your ears. 24 | MOMENTUM True Wireless 4...
-
Page 25: Inserting The Earbuds Into The Ears
The Smart Pause function automatically stops music playback when you remove an earbud from the ear (> 30). MOMENTUM True Wireless 4 | 25... -
Page 26: Switching The Earbuds On
You can wake up the earbuds from idle mode by touching their touch control panels 1x or by briefly inserting them into the charging case. Switching the earbuds off The earbuds do not have to be switched off explicitly. 26 | MOMENTUM True Wireless 4... -
Page 27: Adjusting The Volume
You can also adjust the volume using the connected Bluetooth device. If you have activated the voice assistant (> 30) and then change the volume of the earbuds, the volume of the voice assistant is adjusted accordingly and saved permanently. MOMENTUM True Wireless 4 | 27... - Page 28 Tap the touch control panel of the left earbud 3x. The active noise cancellation ANC is activated or deactivated. ON/OFF 3 x L You can also activate or deactivate the active noise cancella- tion ANC via the Smart Control app (> 21). 28 | MOMENTUM True Wireless 4...
- Page 29 The Transparency Mode set in the Smart Control app is activated. You can hear ambient sounds without having to remove the ear- buds from your ears. To deactivate the Transparency Mode: ▷ Tap the touch control panel of the left earbud 1x. MOMENTUM True Wireless 4 | 29...
-
Page 30: Using The Voice Assistant/Voice Dialing
(> 27), the volume of the voice assistant is adjusted accordingly and saved permanently. Using the Smart Pause function The earbuds automatically detect whether you are wearing the ear- buds in your ear or removing them. 30 | MOMENTUM True Wireless 4... -
Page 31: Controlling Music Playback
Tap the touch control panel of the left earbud 2x. Left touch control panel Function Tap 2x Plays the previous track in the playlist Playing the next track ▷ Tap the touch control panel of the right earbud 2x. MOMENTUM True Wireless 4 | 31... - Page 32 If you are playing music when you receive a call, the music pauses until you end the call. Right or left touch control Function panel Tap 1x Accepts a call Tap 2x Ends a call Voice prompt “Call ended” 32 | MOMENTUM True Wireless 4...
-
Page 33: Displaying The Battery Charge Status
(depending on the device and operating system used). The Smart Control app also displays the charge status of the rechargeable batteries of the earbuds and the charging case. MOMENTUM True Wireless 4 | 33... -
Page 34: Adjusting Sound Effects/The Equalizer
(> 40). (> 40). Adjusting sound effects/the equalizer To be able to use the sound effects/the equalizer, you require the Smart Control app (> 21). 34 | MOMENTUM True Wireless 4... -
Page 35: Battery Protection Mode
This mode requires an audio source (player or Bluetooth device) that supports aptX™ Adaptive and audio material in High Resolution qual- ity. If the “High Resolution Audio” mode is activated via the Smart Con- trol app, the Bluetooth transmission range may be slightly reduced. MOMENTUM True Wireless 4 | 35... - Page 36 Moisture and dirt can damage the electronics of the charging case and the earbuds! If moisture and dirt get inside the charging case, this can impair its function. ▷ Do not place the earbuds in the charging case when they are wet or dirty. 36 | MOMENTUM True Wireless 4...
- Page 37 The earbuds are magnetically pulled into the charging compart- ments. ▷ Close the lid of the charging case. MOMENTUM True Wireless 4 | 37...
- Page 38 12 hours before re-attaching them to the earbuds. ▷ Clean the charging contacts on the earbuds and in the charging case from time to time, e.g. with a cotton swab. 38 | MOMENTUM True Wireless 4...
- Page 39 For reasons of hygiene, you should replace your ear adapters (> 24) and ear fins (> 25) from time to time. Spare ear adapters and spare ear fins can be found on the MOMENTUM True Wireless 4 product page at www.sennheiser-hearing.com.
-
Page 40: Information On The Built-In Rechargeable Battery
(> 35). Installing firmware updates Firmware updates can be downloaded free of charge from the Inter- net using the Sennheiser Smart Control app. ▷ Make sure that the rechargeable batteries are fully charged before updating (> 16). - Page 41 5. Contact your Sonova Consumer Hearing partner to solve the problem (> 41). Current list of frequently asked questions (FAQ) Visit the MOMENTUM True Wireless 4 product page at www.sennheiser-hearing.com There you will find a current list of frequently asked questions (FAQ) and suggested solutions.
- Page 42 Both earbuds connect to each other within 15 seconds. The earbuds are successfully reset to the factory settings and paired. ▷ Reconnect your earbuds to your Bluetooth device or an Aura- cast™ transmitter (> 20). 42 | MOMENTUM True Wireless 4...
- Page 43 FAQ/If a problem occurs ... Connected MOMENTUM True Wireless 4 | 43...
-
Page 44: Specifications
1.5 hours for full charge able batteries approx. 8 minutes for 1 hour of music playback (ambient temperatures < 15 °C or > 30 °C and Qi wireless charging increase the charging time) 44 | MOMENTUM True Wireless 4... - Page 45 GFSK, π/4 DQPSK, 8DPSK Profiles AVRCP, A2DP, HFP, TMAP, PBP Output power 10 mW (max) Codec aptX™, aptX™ Adaptive/Lossless, AAC, SBC, Auracast™ Broadcast Audio, LC3 Device name MOMENTUM TW 4 Number of active connec- tions MOMENTUM True Wireless 4 | 45...
-
Page 46: Manufacturer Declarations
Recycle electrical and electronic equipment and batteries/recharge- able batteries at the end of their operational lifetime in order to make contained recyclable materials usable and to avoid littering the envi- ronment. 46 | MOMENTUM True Wireless 4... - Page 47 The Qi logo is a trademark of the Wireless Power Consortium. Other product and company names mentioned in the user documen- tation may be the trademarks or registered trademarks of their respective holders. MOMENTUM True Wireless 4 | 47...
