- Page 1 HME 95 Bedienungsanleitung Instruction Manual Notice d‘emploi Istruzioni per l‘uso Instrucciones de uso Gebruiksaanwijzing...
-
Page 2: Table Of Contents
Sennheiser a world-leading company in this field. Please take a few moments to read these instructions carefully, as we want you to enjoy your new Sennheiser products quickly and to the fullest. -
Page 3: Important Safety Instructions
Only replace those parts of the headset whose replacement is described in this manual. All other parts of the headset must be replaced by your Sennheiser agent. Protect the headset from humidity. Use only a slightly damp cloth to clean the headset. For information on how... -
Page 4: Delivery Includes
Improper use means using the headset other than as described in these instructions, or under operating conditions which differ from those described herein. Delivery includes Delivery of the HME 95 headset includes: 1 HME 95 headset 1 soft case 1 cable clip 2 MZW 46 wind and pop shields 1 audio-in cable for mobile telephones, length 0.6 m,... -
Page 5: The Hme 95 Headset
The HME 95 headset The HME 95 headset features closed, dynamic, circumaural stereo headphones. Features Outstanding transmission quality for clear communica- tions Good passive attenuation of ambient noise Foldable design for space-saving storage and transporta- tion Noise-compensating boom microphone ensures excellent... -
Page 6: Operating Elements
Operating elements » Headset Microphone sensitivity control Headphone cable Microphone boom Earpads Headband Operating control integrated in the cable Cable with microphone plug, 5.25 mm jack plug Cable with headphone plug, ¼” (6.35 mm) jack plug 3.5 mm jack socket for connecting an additional audio player 2.5 mm jack socket for connecting a mobile telephone... -
Page 7: Preparing The Headset For Use
The 2.5 mm jack socket telephone. For this purpose, the microphone plug connected to the aircraft radio/intercom. A suitable adapter for your mobile telephone with 2.5 mm jack socket is available from your Sennheiser agent. DANGER! Danger of accident due to reduced attention! - Page 8 Note: For the latest list of compatible mobile telephones, please refer to the “Cell Phone Compatibility” section on our website www.sennheiser.com. Search under “Products”, “Aviation” and “more info …”. Connect the audio cable to the 2.5 mm jack socket the operating control and to the corresponding jack socket on your mobile telephone.
-
Page 9: Connecting An Additional Audio Player
Connecting an additional audio player The 3.5 mm jack socket to an additional audio player (e.g. MP3 player) through the headset. DANGER! Danger of accident due to reduced attention! Listening to music or operating an audio device limits your attention and may cause accidents. -
Page 10: Adjusting The Microphone Sensitivity
Adjusting the microphone sensitivity The microphone sensitivity has been factory pre-set to 40 mV/Pa as per RTCA DO-214. To change the input sensitivity of the microphone: Use a suitable slotted screwdriver. Turn the microphone sensitivity control Switching between mono and stereo mode The mono/stereo switch mono and stereo mode, depending on the intercom system. -
Page 11: Using The Headset
Using the headset Attaching the cable clip The cable clip allows you to attach the headphone cable to your clothing so that the cable doesn’t hinder or distract you. Guide the headphone cable Attach the cable clip Adjusting the headset Wear the headset so that –... -
Page 12: Adjusting The Volume
Bend the microphone boom placed at the corner of the mouth. Maintain a distance of approx. 2 cm between microphone and mouth. Adjusting the volume CAUTION! Hearing damage due to high volume levels! The headset is capable of producing high sound pressure levels. -
Page 13: Folding Up The Headset
Folding up the headset space-saving transportation, the headset can be folded up in different ways: To fold up the headphones as Rotate the earcups by 90° and turn the microphone boom flat as shown. To fold up the headphones as Tuck the earcups between the headband as shown. -
Page 14: Care And Maintenance
Care and maintenance CAUTION! Liquids can damage the electronics of the headset! Liquids entering the housing of the headset can cause a short-circuit and damage the electronics. Only use a soft, slightly damp cloth to clean the headset. Do not use any solvents or cleansing agents. -
Page 15: Replacing The Wind Shield
Replacing the wind shield You can replace the wind shield. The HME 95 is supplied with a spare wind shield. Carefully pull the wind shield Slide-on the new wind shield securely over the microphone. Specifications General data Weight without cable... - Page 16 Nominal impedance Sound pressure level stereo mono THD at 94 dB SPL Attenuation Contact pressure Microphone incl. preamplifier Type Transducer principle Frequency response Output voltage Terminating impedance Supply voltage Connector assignment ¼” (6.35 mm) jack plug 1 Audio Hi left 2 Audio Hi right 3 Audio Lo 225 Ω...
-
Page 17: Accessories And Spare Parts
Cat. No. 523889 523843 523844 044740 515297 514127 523897 Accessories and spare parts Accessories/Spare parts Earpads (1 pair) Audio-in cable (3.5 mm), length 0.6 m, 2 x 3.5 mm jack plug Audio-in cable (2.5 mm), length 0.6 m, 2 x 2.5 mm jack plugs Cable clip Wind shield Wind shield (any number of items) -
Page 18: Manufacturer Declarations
Manufacturer declarations Warranty regulations The guarantee period for this Sennheiser product is 3 years from the date of purchase. Excluded are accessory items, rechargeable or disposable batteries that are delivered with the product; due to their characteristics these products have a shorter service life that is principally dependent on the individual frequency of use. - Page 19 Before putting the device into operation, please observe the respective country-specific regulations! WEEE Declaration Your Sennheiser product was developed and manufactured with highquality materials and components which can be recycled and/or reused. This symbol indicates that electrical and electronic equipment must be disposed of separately from normal waste at the end of its operational lifetime.
- Page 20 Sennheiser electronic GmbH & Co. KG 30900 Wedemark, Germany Phone +49 (5130) 600 0 Fax +49 (5130) 600 300 www.sennheiser.com Printed in China Publ. 06/07 516577/A02...
