Summary of Contents for LINOVISION POE-SWR608G
- Page 1 User Guide 8GE+4G SFP Web Smart PoE industrial switc This document applies to 8GE +4G SFP Web Smart PoE industrial switch. Unless otherwise specified, 8GE+4G SFP is used as an example in the product diagram.
- Page 2 Packing List When using the Switch for the first time, carefully open the packing box. The packing box should contain the following items: PoE Switch *1 User Manual *1 Wall Mount Accessory *1 Terminal *1 Din Rail Mount Accessory *1 Note: Precision devices are built in the device, please handle them carefully to avoid violent vibration, which may affect the performance of the device.
-
Page 3: Table Of Contents
Directory Chapter 1 Introduction To The User Guide ..............3 1.1 Use ........................3 1.2 User Manual Overview ..................3 Chapter 2 Product Introduction ..................4 2.1 Product Overview ....................4 2.2 Product Features ....................4 2.3 Product Advantage ....................5 Chapter 3 Product Appearance Description ..............6 3.1 Front panel ...................... -
Page 4: Chapter 1 Introduction To The User Guide
Chapter 1 Introduction To The User Guide Thank you for purchasing our 8GE +4G SFP Web Smart PoE industrial switch, The device adopts storage and forwarding, fanless, low power consumption design, has the advantages of easy to use, compact and beautiful, simple installation, etc. The product is designed to meet Ethernet standards, with lightning protection, static protection mechanism, operating temperature range of -20°C to 60°C, stable performance, safety and reliability, can be widely used in intelligent transportation, telecommunications, security, financial securities, customs and other broadband data transmission... -
Page 5: Chapter 2 Product Introduction
Chapter 2 Product Introduction 2.1 Product Overview 8GE +4G SFP is an Web Smart PoE industrial switch developed by our company. It provides 8*10/100/1000Mbps adaptive RJ45 ports and 4*1000Mbps SFP Slots. 1-8 ports support PoE powering with a maximum port output of 30W. support static routing function, provide perfect security policy, QoS policy, and rich VLAN function, with the ring network function, you can set up a ring network, the switches through the form of the ring through the form of the ring network topology, its redundancy, high reliability and other features can make the ring network in a link... -
Page 6: Product Advantage
technology; Support static convergence and dynamic convergence (LACP) 2 convergence modes, effectively increase the link bandwidth, improve the reliability of the link, and at the same time can achieve load balancing, link backup; Flexible and convenient management and maintenance Supports various management modes, such as Console, Telnet, and SSH;... -
Page 7: Chapter 3 Product Appearance Description
Chapter 3 Product Appearance Description 3.1 Front panel The front panel consists of 8*10/100/1000Mbps adaptive RJ45 ports, 4*1000Mbps SFP slots and related indicators, as shown below: Figure 3-1 Front panel of the 8GE +4G SFP Switch 8GE+4G SFP Port description: ... -
Page 8: Led Indicator
3.2 LED Indicator The LED indicators of the Switch are shown in the following table. Users can monitor the work and running status of the Switch conveniently and quickly through the following indicators: Color Function Off: No Power supply. Green Light: Indicates the Switch has power. -
Page 9: Chapter 4 Installation Guide
Chapter 4 Installation Guide This chapter helps users correctly install and safely use Switches. 4.1 Installation Precautions Precautions: To avoid equipment damage and personal injury, observe the following precautions: The Switch room should be dry and ventilated, free from corrosive gases and strong electromagnetic interference. -
Page 10: Installation
Ensure the stability of the workbench and good grounding; Check whether cables and connectors required for installation are in place (less than 100m). The product does not provide installation components. Prepare components of the selected installation type, such as screws, nuts, and tools, to ensure reliable installation. ... - Page 11 Figure 4-2 Schematic diagram of industrial machine guide rail installatio2...
-
Page 12: Appendix: Technical Specifications
Appendix: Technical Specifications 8GE+4G SFP Web Smart PoE industrial switch Model IEEE802.3 IEEE802.3u IEEE802.3ab IEEE802.3z IEEE802.3x, 、 、 、 、 IEEE802.1X IEEE802.1q IEEE802.1p IEEE802.1d IEEE802.1w, 、 、 、 、 Standard IEEE802.3ad IEEE802.3af IEEE802.3at 、 、 10BASE-T:UTP category 3,4,5 cable（≤100m） 100BASE-TX:UTP category 5, 5e cable（≤100m） Network Media(Cable) 1000BASE-X:UTP category 5e, 6 cable（≤100m）...
